  • Page 1 RT2620 4/7/04 1:41 PM Page 2 IMPORTADOR Comercializadora Thomson de México, S.A. de C.V. Álvaro Obregón No. 151. Piso 13. Col. Roma. Delegación Cuauhtémoc C.P . 06700. México, D.F. Telefono: 52-55-11-020360 RFC: CTM-980723-KS5 EXPORTER Thomson Inc. P .O. Box 1976 Indianapolis, IN 46206 - 1976 ©...
  • Page 2 RT2620 4/7/04 1:41 PM Page 3 u s e r m a n u a l RT2620 It is important to read this instruction book prior to using your new product for the first time. Es importante leer este manual antes de usar por vez primera su euipo.

  • Page 3: Fcc Information

    Subchapter J. Applicable at the date of manufacture. Technical Specification Product: Dolby Digital Audio video receiver Brand: RCA Model: RT2620 Electrical current consumption Power Supply: 120V ~ 60Hz Power consumption: 100 Watts IMPORTER Comercializadora Thomson de México, S.A. de C.V.

  • Page 4: Table Of Contents

    RT2620 4/7/04 1:41 PM Page 5 Table of Contents FCC Information Table of Contents Getting Started Unpacking the Receiver ... . .2 Unpacking the Speakers ... . .2 Inserting Batteries into Remote Control .3...

  • Page 5: Getting Started

    PHONES One pair of “AAA” batteries one audio cable (two wires) with red and One external AM loop white RCA connectors; antenna one Video cable • 6 speaker wires including: 1 X green/grey striped wire for center speaker Center Speaker...

  • Page 6: Inserting Batteries Into Remote Control

    RT2620 4/7/04 1:41 PM Page 7 Inserting Batteries into Remote Control Install batteries as follows: 1. Remove the battery compartment door by applying thumb pressure on battery door and then lift the door out and off the cabinet. 2. Insert 2 “AAA” (R03) batteries into the battery compartment according to the + and - signs in the compartment and replace the compartment door.

  • Page 7: Connecting To Audio-Visual Components

    SAT receiver and DVD player. S-video provides the best connection for the video portion of the signal. Composite video (yellow RCA connector) can also be used. It is important that the same type of cable (S-video or composite) that is connected from the Home Theatre to the TV is used to connect the SAT receiver or DVD player to the Home Theatre.

  • Page 8: Rt2620 En 4/7/04 1:41 Pm

    RT2620 4/7/04 1:41 PM Page 9 Digital Connections Read instructions carefully when connecting components to the receiver. Digital Input Jacks can accept Dolby Digital (AC-3) or PCM signals when compatible components are connected. OPTICAL DIGITAL IN (AUDIO) Optical Fiber Cable...

  • Page 9: Connecting The Speakers

    RT2620 4/7/04 1:41 PM Page 10 Getting Started Connecting the Speakers Speakers There are 6 speakers equipped with the unit (2 front, 1 center, 2 rear, 1 subwoofer). In order to enjoy good surround effects, all six speakers need to be connected to the receiver.

  • Page 10: Positioning Your Speaker

    It is not recommended to place the rear speakers and subwoofer near the TV set. Courtesy Dolby Laboratories Front Speaker Placement Even if you can't duplicate this ideal home theater setup exactly, the suggestions for speaker placement that follow will help you get good results. Getting Started...

  • Page 11: Preferred Surround Placement

    RT2620 4/7/04 1:41 PM Page 12 Getting Started Preferred surround placement Location If possible, place surround speakers to either side of the listening area, not behind it. Courtesy Dolby Laboratories Height If space permits, install surrounds 2-3 feet above viewers. This helps to minimize localization effects.

  • Page 12: Test Tone / Channel Balance

    RT2620 4/7/04 1:41 PM Page 13 Test Tone / Channel balance Channel balance Your receiver is equipped with a test signal generator for balancing the channels. As the signal "travels" from channel to channel, adjust the level controls until each channel plays at the same loudness level.

  • Page 13: Operating Your Receiver

    RT2620 4/7/04 1:41 PM Page 14 Operating Your Receiver Receiver Controls ON/STANDBY 1. ON/STANDBY Turns the unit on and off. When the system is turned on, the unit will go to the mode it was in before powered off. 2. Display Displays current status of the receiver.

  • Page 14: Your Remote Control

    (see relevant section on page 3.) You can test it by pressing any button. 1. ON•OFF Turns the receiver and other RCA auxiliary components on and off. (see page 14 “Using the Remote to Control Additional Components”). 2. Source Buttons Selects various audio/ video sources.

  • Page 15: Display

    RT2620 4/7/04 1:41 PM Page 16 Operating Your Receiver Display DVD / VCR / SAT / TUNER / TAPE / CD / TV • An arrow points to the current source mode. • Dolby Digital audio input for signal format.

  • Page 16: Switching The Unit On/Off

    RT2620 4/7/04 1:41 PM Page 17 Switching the unit on and off • To switch on the receiver, press the STANDBY/ON button on the main unit once, or the ON•OFF button on the remote control. ON/STANDBY • Standby: when the receiver is in tuner mode, press the STANDBY/ON button once to enter standby mode.

  • Page 17: Using The Remote To Control Additional Components

    Using the Remote to Control Additional Components You can use your remote to control most of RCA branded VCRs, satellites, cable boxes or TVs. Press the corresponding source button on the remote control to operate options on other components.

  • Page 18: Using The Receiver To Play A Source

    RT2620 4/7/04 1:41 PM Page 19 Using the receiver to play a source After having properly connected a source (DVD, CD, VCR) to the receiver, you can partly control them through the receiver. Playing a DVD with the receiver 1. Connect a DVD player to the receiver (see connecting your receiver for details).

  • Page 19: Operating The Radio

    RT2620 4/7/04 1:41 PM Page 20 Operating your Receiver Operating the Radio The receiver has a built-in tuner that allows for AM/FM radio function. Manual tuning 1. Connect the FM and AM antenna accordingly (see "Connecting the Antenna" on page 5 section for details) 2.

  • Page 20: Storing Radio Stations

    RT2620 4/7/04 1:41 PM Page 21 Storing radio stations The receiver can store up to 40 radio stations in memory. You can enter every single radio station yourself or the receiver can store all available radio stations automatically in an ascending order.

  • Page 21: Advanced Sound Control

    RT2620 4/7/04 1:41 PM Page 22 Advanced Sound Control Sound Enhancement Systems This receiver is equipped with several built-in sound enhancement systems. Dolby Digital The Dolby Digital mode lets you enjoy full digital surround from software processed in the Dolby Digital format.

  • Page 22: Night Mode

    RT2620 4/7/04 1:42 PM Page 23 Dolby 3 Stereo The 3 Stereo mode will redirect the Surround signals to the front left and right speakers when only the front and center speakers are used. Front Left Speaker Center Speaker Listening...

  • Page 23: Fine Setting Of Components

    RT2620 4/7/04 1:42 PM Page 24 Advanced Sound Control Fine Setting of the Components The receiver can be directly turned on by pressing the DVD•6CH / SAT•CABLE / TV / CD•TAPE / VCR / TUNER buttons on the remote control, which also selects the best surround sound mode.

  • Page 24: Fine Setting Of The Speakers

    RT2620 4/7/04 1:42 PM Page 25 Fine Setting of the Speakers All the basic settings have already been pre-set for the speakers included in the box. Also, to make the surround sound more effective and suit the acoustic conditions in your listening room, you may need to delay the signal coming from some of the speakers.

  • Page 25: Displaying Program Formats

    RT2620 4/7/04 1:42 PM Page 26 Advance Sound Control Speaker Configurations You can also change the setup of the speakers. Use a subwoofer to enjoy optimum sound. • Speaker distance: For optimum surround experience measure the distance between the speaker and your favorite listening position.

  • Page 26: Troubleshooting Tips

    RT2620 4/7/04 1:42 PM Page 27 Troubleshooting Tips Receiver/Tuner Operation ST indicator is off. • Adjust the antenna. • Press GO BACK/ST.MONO button to insure you are not outputting in mono. The signal is Mono. Severe hum or noise. • The signal is too weak. Connect an external antenna.

  • Page 27: Care And Maintenance

    RT2620 4/7/04 1:42 PM Page 28 Care and Maintenance Disconnect the audio system from the power source before performing any maintenance. Cleaning Clean the exterior of the system using a soft dust cloth. Important battery information • Remove the batteries to avoid leakage if you do not use your remote control for more than one month.

  • Page 28: Limited Warranty (U.s.)

    45 days from date of shipment to the rental firm, whichever comes first. What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit. • Pay any Authorized RCA Audio Service Center for the new or, at our option, refurbished replacement parts required to repair your unit.

  • Page 29: Limited Warranty (Canada)

    45 days from date of shipment to the rental firm, whichever comes first. What we will do: • Pay any Authorized RCA Audio Service Center the labor charges to repair your unit. • Pay any Authorized RCA Audio Service Center for the new or, at our option, refurbished replacement parts required to repair your unit.
