Front Panel Controls

Volume up
and down
buttons
Headphones jack
OPEN•CLOSE button
Arrow buttons (up, right, down, left) Use these buttons to move through the DVD Player's on-screen menu system
Disc tray Press OPEN•CLOSE to open and close the disc tray.
Front panel display (See following page for details.)
GO BACK Press to go back one level in the menu system.
Headphones jack You can attach headphones here for private listening.
MENU Press to access the main DVD Player menu.
OK SELECT Press this button to select a highlighted item on the screen.
ON•OFF button and ON•OFF indicator light Turns the player on and off. The ON•OFF indicator lights when the
player is on.
OPEN•CLOSE Press to open and close the disc tray.
PAUSE Pauses disc play (also used for frame advance).
PLAY Begins disc play (and closes disc tray if open).
SKIP FWD Allows you to move to the beginning of the next title, chapter, or track on a disc (in effect, "skipping" the
title, chapter, or track).
SKIP REV Allows you to move to the beginning of the preceding title, chapter, or track on a disc (in effect, "skipping"
the title, chapter, or track).
STOP Stops disc play.
VOLUME (+ and –) Adjusts the headphone, volume level.
84
ON•OFF button
and indicator
light
Front panel display
OK SELECT
button
MENU
Disc tray
button
PLAY button
SKIP REV SKIP FWD
button button
STOP
button
PAUSE
GO BACK
button
button
