INSTRUCTION MANUAL
LS-Drive
GLD-SDO
LS-Drive Operator
GLD-R2.5M
Rail for (max) 2.5m High Door
GLD-R3.0M
Rail for (max) 3.0m High Door
Commercial Sectional Door Operator
• THIS OPERATOR IS TO BE INSTALLED AND SERVICED BY A TRAINED TECHNICIAN ONLY
• Compatible with Security+ 2.0
• Compatible with Grifco Battery Backup and myQ Internet Gateway
Chamberlain Australia Pty Ltd
Unit 1, 75 Epping Rd North Ryde NSW 2113
Ph: 1800 GRIFCO
www.grifco.com.au
Ref: 114A4934F
Compatible
Compatible
®
accessories
SUPPLIED WITH GRIFCO
SUPPLIED WITH GRIFCO
MONITORED ENTRAPMENT
MONITORED ENTRAPMENT
Reflective
Safety Beam
Compatible
OPERATOR
OPERATOR
PROTECTION
PROTECTION
Advertisement
Table of Contents
Related Manuals for Grifco GLD-R2.5M
Summary of Contents for Grifco GLD-R2.5M
- Page 1 • THIS OPERATOR IS TO BE INSTALLED AND SERVICED BY A TRAINED TECHNICIAN ONLY ® • Compatible with Security+ 2.0 accessories • Compatible with Grifco Battery Backup and myQ Internet Gateway Chamberlain Australia Pty Ltd Unit 1, 75 Epping Rd North Ryde NSW 2113 Ph: 1800 GRIFCO www.grifco.com.au...
-
Page 2: Safety Symbol And Signal Word Review
SAFETY SYMBOL AND SIGNAL WORD REVIEW This commercial sectional door operator has been designed and tested to offer safe service provided it is installed, operated, maintained and tested in strict accordance with the instructions and warnings contained in this manual. WARNING When you see these Safety Symbols and Signal Words on the following pages, they will alert you to the possibility of serious... -
Page 3: Table Of Contents
INTRODUCTION CONTENTS SAFETY SYMBOL AND SIGNAL WORD REVIEW ......................2 INTRODUCTION ................................3 OPERATOR SPECIFICATIONS ................................4 OPERATOR OVERVIEW ..................................5 CONTROL PANEL OVERVIEW ................................5 CARTON INVENTORY ....................................6 TOOLS REQUIRED ....................................6 HARDWARE PROVIDED ..................................6 INSTALLATION ................................7 CONNECT RAIL TO OPERATOR ................................7 TIGHTENING THE CHAIN ..................................7 FASTENING RAIL TO OPERATOR .................................7 HEADER BRACKET POSITIONING ................................8 INSTALL HEADER BRACKET .................................8... -
Page 4: Operator Specifications
Maximum Door Area Commercial Spring-Balanced Sectonal Doors up to 15m² Max. Door Cycles 50 cycles / day Dimensions Operator Length 370mm Rail Length GLD-R2.5m: 3,822mm / GLD-R3.0M: 4,322mm Operator Height 100mm Rail Height 46.5mm Operator Width 200mm Rail Width 88mm Total installed dimensions GLD-SDO-R2.5M: 3,972mm (L) x 150mm (H) x 200mm (W) -
Page 5: Operator Overview
INTRODUCTION OPERATOR OVERVIEW Hanging bracket Operator Mounting Bracket Header Bracket Trolley connection Power cord J-Bar Rail Operator Door arm Manual Release Door Connection Bracket CONTROL PANEL OVERVIEW Control Panel is accessible under the cover on the rear of the operator. 6. -
Page 6: Carton Inventory
The commercial sectional door operator is supplied in two separate cartons. GLD-SDO contains the operator, fitting hardware and accessories. GLD-R2.5m or GLD-R3.0M contain the complete, assembled rail and some hardware. GLD-BBU24V is a separate accessory, supplied in its own carton. -
Page 7: Installation
INSTALLATION WARNING Before beginning installation of the operator check the door is in good mechanical condition, opens and closes properly and correctly balanced STEP 1 CONNECT RAIL TO OPERATOR Your door operator and rail are packed in two separate cartons. Remove the operator, rail and all the hardware in preparation for assembly. -
Page 8: Header Bracket Positioning
INSTALLATION STEP 4 HEADER BRACKET POSITIONING The header bracket must be fastened rigidly to a structural support. Reinforce the wall with a 40mm board if necessary. With the door closed, mark the vertical centre line of the door. Extend line upward onto header wall above door. -
Page 9: Position The Operator
INSTALLATION Rail should be mounted 50mm above the highest STEP 7 point of door travel POSITION THE OPERATOR Disengage the trolley mechanism (see section “Operating the manual release”) and slide it back towards the operator. Secure the hanging push arm up into the rail assembly temporarily using tape or rope, to avoid a hazard. -
Page 10: Attach Door Arm To Trolley
This will re-engage the trolley, and when the door passes the trolley position it will automatically re-engage the operator. www.grifco.com.au www.grifco.co.nz RISK OF ENTRAPMENT Repeat Safety Reverse Test monthly. Door must reverse on contact with a 40mm obstacle placed on the floor. -
Page 11: Commissioning
COMMISSIONING WARNING STEP 12 WHEN SETTING THE TRAVEL LIMITS, ENSURE PEOPLE ARE CLEAR OF THE MOVING DOOR PROGRAM THE TRAVEL LIMITS AND FORCE SETTINGS TO AVOID INJURY. Travel limits regulate the points at which the door will stop when moving UP or DOWN. The Without a properly installed safety travel limit buttons are located under the access cover on the rear panel (Figure 1) reversal system, persons... -
Page 12: Install The Entrapment Protection System
COMMISSIONING STEP 13 WARNING To prevent entrapment, install The Safety INSTALL THE ENTRAPMENT PROTECTION SYSTEM Beams no higher than 100 mm above the floor. NOTE: LS-Drive is supplied with a pair of monitored entrapment protection Disconnect power to the operator before safety beams. -
Page 13: Setting Timer-To-Close (Ttc)
ATTACHING BATTERY BACKUP UNIT (OPTIONAL) Mounting holes (x2) LS-Drive is compatible with the separate Grifco Battery Backup accessory GLD- BBU24V. The BBU should be attached after the LS-Drive has been installed. 1. TURN MAINS POWER OFF BEFORE PROCEEDING Battery Backup 2. -
Page 14: Types Of Security +2.0 Transmitters
COMMISSIONING STEP 16 WARNING COMMISSIONING REMOTE ACCESS DEVICES Activate the operator only when door is in full view, free of obstruction and properly adjusted. No one NOTE: The transmitter supplied with your operator is should enter or leave garage while door is in motion. preprogrammed by the factory. -
Page 15: Commissioning Myq
PROGRAMMING myQ Please refer to the myQ manual supplied with the Internet Gateway. TYPES OF SECURITY +2.0 REMOTE ACCESS DEVICES All Grifco remote access devices feature Security +2.0 technology. This E960G E943G advanced platform cuts through interference, and ensures consistent,... -
Page 16: Maintenance And Care
MAINTENANCE AND CARE USING YOUR OPERATOR WARNING 1. Your operator can be activated by any of the following devices: Before opening the door manually, ensure • Operator control panel: Up and Down Buttons door is at its CLOSED limit position if possible. •... -
Page 17: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING 7. Door opens but won't close: 1. Operator doesn't operate from either door control or remote: • Check Safety Beams. If the light on the Safety Beams are • Does the operator have electric power? Plug lamp into flashing, correct the alignment. -
Page 18: Diagnostics
DIAGNOSTICS The operator is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the control panel indicate the diagnostic code. DIAGNOSTIC CODE SYMPTOM POSSIBLE RESOLUTION UP Arrow DOWN Arrow Flashes Flashes The operator will not close and Safety sensors wires may have been reversed, cut or the courtesy light flashes. -
Page 19: Service And Repair Parts
SERVICE AND REPAIR PARTS If the supply cord is damaged, it must be Power cord replaced by the manufacturer, its service agent or similarly qualified persons 026B0181 in order to avoid hazard. Passpoint assembly 002A1965 041A0045 Transformer 041A4027 Transfer Board 041A0034 LED module 041A4002-1... -
Page 20: Chamberlain Limited Warranty
Chamberlain’s warranty Chamberlain warrants to the original purchaser of the Grifco product (Unit) that: 1 The LS-Drive Unit (including electric motor) is free from defects in materials and workmanship for a period of 24 months from the date of purchase or 20,000 cycles (whichever comes first).
