Dynabrade 52510 Manual

Effective S/N 6E1284
Models:
52510 — 25,000 RPM
52512 — 30,000 RPM
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools (ANSI B186.1) and any other applicable safety
WARNING
!
codes and regulations. Please refer to Dynabrade's Warning/Safety Operating Instructions for more complete safety information.
02650 Bearing L 50767 Pin (2)
3
01546 Housing
Left Hand Threads
01548 Gasket
01461 Lock Nut
95523 O-Ring
95558 Retaining Ring
01470 Insert
Right Hand Threads
Valve Body Housing
02401 – 25,000 RPM,
02403 – 30,000 RPM,
01558 Collar
01449 Valve Stem
95730 O-Ring
01024 O-Ring
01469 Regulator
KEY
O
Oil
Loctite/Hernon:
L
L = Loctite #609, L = Hernon #940
3 4
Torque: N•m x 8.85 = In. - lbs.
T
T = 17 N•m, T = 23 N•m, T
2 3
T = 28 N•m
5
01476 Cylinder 01594 Rotor
01480 Blades (4) (4 pkg.)
01474 Rear Bearing Plate
T
4
01464 Seal
See inside for Important Operating, Maintenance and Safety Instructions.
= 45 N•m,
4
01479 Spacer 54529 Shim Pack (3/pkg.)
O
02649 Bearing
01478 Front Bearing Plate
*01448 Throttle Lever
12132 Pin 95711 Retaining Ring
01468 Spring 94538 O-Ring
01472 Tip Valve Air Control Ring
01598 – 25,000 RPM
01564 – 30,000 RPM
Parts Page Reorder No. PD96 •34U
.3 Hp/7°/Rear Exhaust
2" Disc Sander
For use with Norton Co. Speed-Lock Discs.
01560 Exhaust Cover
01580 Silencer
50133 Adapter
94521 Muffler Base 94525 Felt Muffler
94524 Sintered Muffler 94522 Muffler Cap
*Optional 01462 Safety-Lock Lever available.
Effective June, 1996
Supercedes PD 95•29
T
5
50141 2" Norton Speed Lock Disc pad
T
2
95375 O-Ring 94526 Spacer
94523 Inlet Adapter
L
T O
3 3
