Cooper Lighting Metalux 471 Specification Sheet

STRIPS AND INDUSTRIALS ACCESSORIES
A C C E S S O R Y
Gripper Hanger
Tong Hanger
Spacer
Suspension Sets
Stem Sets
SCF SCS SCA
Cable Sets
27")
CCA CCA CCA
PFC PFS NPF
Chain Hanger
Channel Connector
DI Long Connector
COOPER LIGHTING - METALUX
D E S I G N AT I O N
GRP-SS-U
(Use with SS, IA/IC)
GRP-STN-U
(Use with STN, STM, IA/IC-HO)
ATG-4-U
(Use with IA/IC-HO,STN, STM, DI,
DIM, DIVM, EI, EIM, EIVM)
ATG-5-U
(Use with STW)
A-1-B/Spacer-U
(Use with all Strips and Industrials)
SCF-XX-B
SCS-XX-B
(Deep canopy, 3/8" stem, 5/8"
outside diameter)
XX= Length 6, 8, 12, 24, 36, 48, 60, 72
SCA-48-B
Used with all surface fixtures as stem sets. SCS stems have 45° swivel, one direction. One set
consists of one stem assembly. Minimum of two sets required per fixture. NOTE: Coupler, 3/8" IPS
Pipe Coupler to join lengths. Coupler is standard baked white enamel or special order of black.
CCA-XX-PFC-U
CCA-XX-PFS-U
CCA-XX-NPF-U
CCF-XX-PFC
CCF-XX-PFS
CCF-XX-NPF
AYC-Chain/Set-U
(Use with all strips and industrials
except SN and STW)
Eye-Chain/ Set-B
(SN only)
VT2-Chain/ Set-U
(VT2 only)
CLC-B
DI2 Long Connector
(Use with STN, STM, DI, DIM, DIVM,
EI, EIM, EIVM, IA/IC-HO)
Items listed are the major accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional
options and accessories are available.
Consult Pre-Sales Technical Support for additional information.
(ORDER SEPARATELY)
D E S C R I P T I O N
For mounting on T-bar grid. Use two per fixture.
Can also be stem mounted or bolted to surface
using 11/16" hole provided. Fixture spacing 1-
1/2".
Heavy Gauge Channel Tong Hanger.
Use two per fixture. Fixture spacing 1 1/2".
Spaces fixture 1 1/2" to 2 1/2" from ceiling
Fixed Stem Set
Swivel Stem Set
Adjustable Stem Set (1/4" IPS Stem, 1/2" O.D.)
CCA=Adjustable Cable (XX=48" or 120")
CCF=Fixed Cable (XX=12", 15", 18", 21", 24" or
PFC=Power Feed, coil power cord
PFS=Power Feed, straight power cord
NPF=Non Power Feed
Sturdy wire hook and 36" chain set.
Use two per fixture. One set of two provided
Eye bolt and 36" chain.
Use two per fixture. One set of two provided
Eye bolt and 36" chain.
Special rigid channel connector designed to give
extra support to continuous channel installation
(Use with SS, IA/IC). Provision for hanging
device. (LA City Approved)
Extra support heavy duty channel connector.
®
471
COOPER LIGHTING
