D I M E N S I O N S
11 3/4" (298mm)
O R D E R I N G I N F O R M AT I O N — A C O N LY E X I T S
Red Letters/White Background
Voltage
No
Arrow
120 VAC
UMX7
277 VAC
UMX71
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : U M X 7
Model Number
Accessories (Order Separately)
See chart
DC Socket Kit
UDC6=Two 6V, 6.6W DC Lamps
UDC12=Two 12V, 7.5W DC Lamps
O R D E R I N G I N F O R M AT I O N — S E L F - P O W E R E D E X I T S
Red Letters/White Background
Battery
No
Left
Arrow
Arrow
Lead Calcium
UMX207
UMX206
Lead Calcium
Battery w/Remote
Capability
UMX107
UMX106
Nickel Cadmium
UMX227
UMX226
W AT TA G E R AT I N G S
UMX201 – UMX208
Lead Calcium=18W for 1 1/2 hrs.; 15W for 2 hrs.
UMX101 – UMX108
Lead Calcium=27W for 1 1/2 hrs.; 24W for 2 hrs.
UMX221 – UMX228
Nickel Cadmium=15W for 1 1/2 hrs.; 12W for 2 hrs.
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : U M X 2 0 7
Model Number
Factory Options
DH=Two 6V, 7.2W Weatherproof Heads
See chart
(UMX101 thru UMX108 only)
TDM=Time Delay Monitor (Exits with Heads only)
TH=Thermal Heater for Battery Compartment (For Use
w/Lead Calcium Exits)
E n e r g y D a t a
A C O n l y E x i t s
—
Fluorescent Exits-6W Lamps
E n e r g y D a t a — S e l f - P o w e r e d E x i t s
Charge Mode (Fully Discharged Battery) Sealed Lead Calcium Battery
Fluorescent Exits - 6W Lamps
Standby Mode (Fully Charged Battery) Sealed Lead Calcium Battery Input Power consumption is reduced by approximately 18 Watts in
the standby operating mode.
Fluorescent Exits - 6W Lamps
COOPER LIGHTING - SURE-LITES
11 3/4"
(298mm)
7 1/2" (191mm)
Left
Right
Double
Arrow
Arrow
Arrow
UMX6
UMX8
UMX5
UMX61
UMX81
UMX51
Vandal Shield
WG7=Wire Guard
VS2=Polycarbonate Vandal Shield
VS2WP=Polycarbonate Vandal
Shield/Weather Resistant
Right
Double
Arrow
Arrow
UMX208
UMX205
UMX108
UMX105
UMX228
UMX225
UMX Exits
Input Power;
Input Current (Max.):
120V
277V
120V
19W
23W
.33A
Input Power;
Input Current (Max.):
120V
277V
120V
41W
43W
.51A
Sealed Nickel Cadmium Battery
29W
29W
.42A
D E S C R I P T I O N
The UMX Series watertight
and corrosion-resistant exit
with tough polycarbonate lens
is designed for use where rain,
moisture, dust or corrosives
are present. Economical long
life fluorescent lamps provide
highly visible signage and
downlighting. The vibration
resistant lamps make the UMX
perfect for heavy industrial
applications (NEMA 4X Listed).
Green Letters/White Background
No
Left
Right
Arrow
Arrow
Arrow
UMX3
UMX2
UMX4
UMX31
UMX21
UMX41
Green Letters/White Background
No
Left
Right
Arrow
Arrow
Arrow
UMX203
UMX202
UMX204
UMX103
UMX102
UMX104
UMX223
UMX222
UMX224
Accessories (Order Separately)
WG7=Wire Guard
Vandal Shield
VS2=Polycarbonate Vandal Shield
VS2WP=Polycarbonate Vandal Shield/Weather Resistant
Power Factor:
T.H.D.:
277V
120V
277V
120V
.32A
>.47
>.26
<6%
Power Factor:
T.H.D.:
277V
120V
277V
120V
.22A
>.66
>.69
<14%
.17A
>.57
>.62
<9%
UMX SERIES
W e t L o c a t i o n
S e l f - P o w e r e d
Double
E X I T L I G H T I N G
Arrow
UMX1
UMX11
• NEMA 4X Listed
• Dual-voltage input
120/277VAC, 60Hz
(Self-Powered Exits)
• Gray fiberglass housing
• Fully gasketed housing
• Tough, high contrast
polycarbonate lens
• AC: two F6T5 fluorescent
lamps
Double
• DC: two 6V, 6W DC lamps
Arrow
UMX201
• Surface mount only
UMX101
• Available with emergency
UMX221
lighting heads mounted on
enclosure
• For operation in ambient
temperatures above 32°F
• Self-powered Exits feature
line-latching, solid-state
voltage limited charger,
solid-state switching,
low-voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator
light
• UL 924 Wet Location
Listed, Life Safety NFPA
101, NEC/OSHA, most
state and local codes.
277V
<9%
277V
<14%
<38%
COOPER LIGHTING
®
A C O n l y
663
