Technical Specifications - Quintum Carrier Multipath Specifications

Tenor VoIP Carrier MultiPath Switch
CALL MANAGEMENT FEATURES
• Automatic call type detection: Voice/Modem/Fax
• Answer and Disconnect Supervision
• Trunk group support
• Public and private dial plan support
• User programmable dial plan support
• Automated load balancing
• Forced routing

TECHNICAL SPECIFICATIONS

Telephony Specifications
• Voice algorithms: G.723.1 and G.729ab, G.711
• Auto codec negotiation
• Fax Support: Group III at 2.4, 4.8, 7.2, 9.6, 14.4 Kbps, using industry
standard T.38; Super G3 compatible up to 33.6 Kbps
• Modem support with G.711
• Coding: A-law, µ-law
• PRI Signaling Protocols: National ISDN-2, Euro ISDN NET5,
Japan INS-NET1500, KDD, 4ESS, 5ESS, DMS100
• T1 CAS (E&M, Loop Start, Feature Group-D, DTMF, MF)
• E1 CAS (R2 MF)
• DASS2
• Tandem/TDM switching
• Maximum Call Rate: 28,800 calls/hour
• SS7/C7 support using an external SS7 signaling gateway*
• VoIP to circuit, and circuit to circuit (Tandem/TDM) switching
IP Network Specifications
• LAN Interface: Fast Ethernet port (10/100Base-T)
• Standard RJ-45 Interface (IEEE 802.3) for 10Base-T or
100Base-T connections
Configuration / Management
• Network Management Server Interface for network-wide
administration and monitoring
• Central provisioning and management
• SNMPv2 Agent
• Alarm/Fault detection and reporting
• Command Line Interface
• Remote Access with external Remote Management Session Server
GENERAL SPECIFICATIONS FOR THE CMS
• Operating temperature: 40° F - 104° F (5° C - 40° C)
• Operating humidity: 20% - 80% non-condensing
• Telco: FCC Part 68, TS-016, TBR4, TS-038, CS03
• EMC: FCC Part 15 Class A, EN55022 Class A, EN55024,
EN61000-2-3, EN61000-3-3
• Safety: UL60950, EN60950, AS/NZS60950
2 Slot Chassis (1U)
• Dimensions:
W 17 " x H 1 " x D 11 "
1/2 3/4 7/8
W 44.5cm x H 4.5cm x D 30.2cm
• Maximum weight: 11.5 lbs (5.25kg)
• AC Power: 100-240 Volts AC, 50/60 Hz, 300 watts
• DC Power: -40 - -60 Volts DC, 300 watts
71 James Way, Eatontown, New Jersey 07724
1-877-SPEAK-IP . Tel 1.732.460.9000 . Fax 1.732.544.9119
www.Quintum.com
• Pass-through support for calls to Toll-Free, local and
special services numbers (ie. emergency services).
• Automatic appending and stripping of digits to dialed
numbers
• Call Detail Records
• Least Cost Routing with Quintum VoIP Call Routing Server*
• Caller ID Name and Number
VoIP Network Specifications
• H.323 v.3 Gateway and Integrated Gatekeeper
• Support for multiple SIP User Agents (RFC3261 compliant endpoint)
• DTMF Signaling via RFC 2833 or SIP Info
• SIP Supplementary Services
• Message Waiting
• SIP Refer Method support
• IVR/RADIUS server support for AAA with integrated multi-lingual IVR
• Adaptive Voice Activity Detection (VAD) with Comfort
Noise Generation (CNG)
• Adaptive Jitter Buffer
• Carrier Grade Echo Cancellation: ITU Rec. G.165/G.168,
up to 128 msec tailsize
• Packet Loss Concealment
• NATAccess™ - NAT/Firewall
• Security: IP Filtering
• Support for DNS-SRV
Card Specifications
• System Controller (CPU) with Fast Ethernet port 10/100 Base-T
• DS-1 8 Port (T1/E1/PRI) Line Interface Card with built-in
CSU. Individual spans software configurable between T1
and E1; accepts one or two plug-in DSP resource modules
• DSP-120 DSP Resource Module supports up to 120
simultaneous VoIP calls
8 Slot Chassis: (4U)
• Dimensions:
W 17" x H 7" x D 11 "
7/8
W 44.5cm x H 17.8cm x D 30.2cm
• Maximum weight: 27.6 lbs (12.5 kg)
• AC Power: 100-240 Volts AC, 50/60 Hz, 600 watts
• DC Power: -40 - -60 Volts DC, 600 watts
+
* Quintum product purchased separately
+
Original Quintum Tenor Only
