Example Configuration for SolarSpectrum H-alpha-Filter – for Photography
with a Reducer
1
TriBand Schmidt-Cassegrain with SC-thread
1
# 2958243 Baader Ultrashort 2"/ 2" Thread-Inverter-Ring, included with the TZ-3
2
# 2459257 2" Research Grade TZ-3 Telecentric System (3-times extension of the
3
focal length),
# 2958244 Baader Reducing-Ring 2"i / T-2a, with 1.5 mm optical length, included
4
with the TZ-3 – to attach SolarSpectrum-Filters with T-2-thread. Not needed for
SolarSpectrum-filters with female SC-thread.
SolarSpectrum-Filter with T-2-threads. Filter with SC-thread can be attached
5
directly to the telecentric system, without
In addition only for SolarSpectrum-Filters which only have a T-2-thread:
6
Baader T-2 Conversion Ring and
1.5 mm optical length. Not necessary for SolarSpectrum-filters with SC-thread
# 2459259 SolarSpectrum 0.7x Telecompressor 2" with 110 mm back focus
7
or
# 2459260 SolarSpectrum
Research Grade H-alpha 0.4x
Telecompressor 2" with 74 mm
back focus
Please note the adjacent dia-
gram for the correct orientation
of the reducer.
# 2958244 Baader Reducing
8
Ring 2"i / T-2a, with 1.5 mm
optical length
T-2-extension(s) to set the wor-
9
king distance for your camera
Monochrome camera
10
2
3
# 2958244
8
4 7
5 9
6
4
Baader Reducing-Ring 2"i / T-2a, with
© 2023 Baader Planetarium GmbH
10
# 2958110
