- Page 1 USER GUIDE 3.3 Cubic Foot Compact Refrigerator NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
Specifications ............15 ONE-YEAR LIMITED WARRANTY - INSIGNIA ......16 Introduction Congratulations on your purchase of a high-quality Insignia product. -
Page 3: Important Safety Instructions
3.3 Cubic Foot Compact Refrigerator Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your compact refrigerator. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your compact refrigerator. - Page 4 NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C Turn off the appliance before unplugging it. Refer all servicing to qualified service personnel. Servicing is required when the appliance has been damaged in any way, such as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the appliance, the appliance has been exposed to rain or moisture, does not operate normally, or has been dropped.
-
Page 5: Grounding Requirement
3.3 Cubic Foot Compact Refrigerator Follow local regulations regarding disposal of the refrigerator due to flammable refrigerant and gas. All refrigeration products contain refrigerants, which under the guidelines of federal law must be removed before disposal. It is the consumer's responsibility to comply with federal and local regulations when disposing of this product. -
Page 6: Features
NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C Features Package contents • 3.3 cu. ft. compact refrigerator • User Guide Refrigerator parts Thermostat Top hinge Storage space Adjustable shelves Bottom shelf Bottle storage Crisper compartment Leveling feet Can storage www.insigniaproducts.com... -
Page 7: Setting Up Your Refrigerator
3.3 Cubic Foot Compact Refrigerator Setting up your refrigerator Before using your refrigerator • Remove the exterior and interior packing. • Let the refrigerator stand upright for approximately four hours before connecting it to power. This reduces the possibility of a malfunction in the cooling system from improper handling during transportation. -
Page 8: Providing A Proper Power Supply
NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C Providing a proper power supply Check your local power source. This refrigerator requires a 110V-120V, 60Hz power supply. Use a receptacle that accepts the grounding prong. The power cord is equipped with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding) wall outlet to minimize the possibility of electric shock hazard from this refrigerator. -
Page 9: Setting The Thermostat
3.3 Cubic Foot Compact Refrigerator Setting the thermostat Note: The refrigerator’s temperature ranges from 32° to 46.4°F (0° to 8°C). Thermostat The first time you turn the refrigerator on, adjust the thermostat to “4” and let your refrigerator cool completely before putting food in. A full 24 hours is recommended. - Page 10 NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C Remove the screw holding the top hinge cover to the top of your refrigerator, then remove the top hinge cover. Remove the screws holding the top hinge to your refrigerator, then remove the hinge. Remove the screw hole covers from the top left side of your refrigerator.
- Page 11 3.3 Cubic Foot Compact Refrigerator Install the bottom hinge and the door stopper on the right bottom of your refrigerator using the screws your previously removed. Tighten the screws. Door Bottom of refrigerator Align the hole in the bottom left of the refrigerator door with the bottom hinge pin, then install the door on the hinge pin.
-
Page 12: Maintaining Your Refrigerator
NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C Maintaining your refrigerator Your refrigerator is designed for year-round use with only minimal cleaning and maintenance. When you first receive it, wipe the case with a mild detergent and warm water, then wipe dry with a dry cloth. Do this periodically to keep your refrigerator looking new. -
Page 13: Moving Your Refrigerator
3.3 Cubic Foot Compact Refrigerator Moving Your Refrigerator Turn off the refrigerator and unplug it from the wall outlet. Remove all food. Securely tape down all loose items inside your refrigerator. Tape the doors shut. Be sure the refrigerator stays in the upright position during transportation. Tips on saving energy •... - Page 14 NS-CF33SS8/NS-CF33WH8/NS-CF33BK8/ NS-CF33BK8-C PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The door has been opened too often or Make sure that the door is closed properly. was not closed properly. You have just added a Allow time for the new food to cool, then large amount of food check again.
-
Page 15: Specifications
3.3 Cubic Foot Compact Refrigerator Specifications Dimensions (WxDxH) 19.1 x 17.7 x 32.7 in. (48.5 x 45.0 x 83.0 cm) Weight 55.3 lbs (25.1 kg) Temperature range 32° ~ 46.4°F (0° ~ 8°C) Power requirements 115 V~60 Hz Current 1.5 A Power consumption (annual) 258 kwh 4.9 ft. -
Page 16: One-Year Limited Warranty - Insignia
Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. - Page 17 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults” •...
- Page 18 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. V4 ENGLISH ©2019 Best Buy. All rights reserved.
