Page 1 60 years of making automobiles; the highest motivation of our most talented employees; and our tradition of incessant striving toward ever greater quality. This Owner’s Manual explains the features of your new Lexus. Please read it and follow the instructions carefully so that you can enjoy many years of safe motoring.
Page 2 However, the more you know about these systems and how to use them properly, the greater your chances Lexus encourages you and your family to take the time to read become of surviving an accident without death or serious Section 1-6 of this Owner’s Manual carefully.
Page 3 IMPORTANT INFORMATION ABOUT YOUR LEXUS New vehicle warranty Important health and safety information about your Lexus Your new vehicle is covered by the following Lexus limited warranties: CAUTION New vehicle warranty Emission control systems warranty WARNING: Engine exhaust, some of its constituents,...
Page 4 SRS airbag and seat belt pretensioner removed Spark ignition system of your Lexus and disposed of by a qualified service shop or by your Lexus The spark ignition system in your Lexus meets all dealer before you scrap your vehicle.
Page 5: Table Of Contents
The vehicle’s equipment is divided into the 7 groups listed Regular and periodic inspection and maintenance of your below. Use of the equipment is explained, including any points Lexus will help to keep your vehicle in its best condition. you should pay particular attention to. 1. Keys and doors...
Page 6 Lexus and its equipment. Your Lexus Owner ’s Manual provides you with a In this manual, you will also see a circle with a slash through considerable amount of information.
Page 7 PICTORIAL INDEX INSTRUMENT PANEL 00sa13c...
Page 8 PICTORIAL INDEX Page Page Glove box ........Driving position memory switch .
Page 9 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles with compass sold in U.S.A.) 00sa01c...
Page 10 PICTORIAL INDEX Page Page SRS warning light ......Tachometer ....... . . Engine coolant temperature gauge .
Page 11 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles without compass sold in U.S.A.) 00sa15a...
Page 12 PICTORIAL INDEX Page Page SRS warning light ......Tachometer ....... . . Engine coolant temperature gauge .
Page 13 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles with compass sold in Canada) 00sa14a xiii...
Page 14 PICTORIAL INDEX Page Page Engine coolant temperature gauge ... . Tachometer ....... . . Automatic transmission indicator lights .
Page 15 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles without compass sold in Canada) 00sa02c...
Page 16 PICTORIAL INDEX Page Page Engine coolant temperature gauge ... . Tachometer ....... . . Automatic transmission indicator lights .
Page 17 PICTORIAL INDEX SEAT AND STEERING WHEEL Page Tilt and telescopic steering adjustment switch ... . . Seat position, seat cushion angle and height control switch ..... 97, 99 Seatback angle and seat position control switch...
Page 18 PICTORIAL INDEX EXTERIOR VIEW Page Fuel filler door ....Rear window defogger ..Trunk lid .
Page 19 PICTORIAL INDEX...
Page 20 BASIC OPERATION QUICK REFERENCE Driver’s seat ............... . . Steering wheel .
Page 21: Quick Reference
QUICK REFERENCE 1. DRIVER’S SEAT 2. STEERING WHEEL D TILT STEERING WHEEL 00sa04a Seat adjustment Seat To tilt the steering wheel up or down to the desired angle, position push the control switch in the required direction and release the button when the steering wheel reaches the Seat cushion desired angle.
Page 22: Automatic Transmission
QUICK REFERENCE 3. AUTOMATIC TRANSMISSION OPERATION OF SELECTOR LEVER 00sa09a SELECTOR LEVER POSITION 00sa10a P: Parking, engine starting and key removal position R: Reverse position N: Neutral position D: Normal driving position (Shifting into overdrive possible) 4: Position for engine braking (Shifting into overdrive not possible)* K Shift while pressing the brake pedal.
Page 23: Headlight And Turn Signal Switches
QUICK REFERENCE 4. HEADLIGHT AND TURN SIGNAL With the engine started and parking brake released SWITCHES D HEADLIGHT SWITCH Parking, tail, license plate, With the ignition OFF side marker and instrument 00sa07b panel lights turn on. Parking, tail, license plate, side marker and instrument panel lights turn on.
Page 24: Wiper Switch
QUICK REFERENCE 5. WIPER SWITCH D TURN SIGNAL SWITCH Mist wiper operation Right or left turn 00L103a Intermittent operation Lane change (Right or left) Low speed operation High speed operation Washer on...
Page 25 QUICK REFERENCE...
Page 26 SECTION – INSTRUMENTS AND CONTROLS Keys and doors Keys ................Engine immobilizer system .
Page 27: Keys And Doors
If you should lose your keys or if you need additional keys, duplicates can be made by a Lexus dealer using the key number. Master keys - These master keys work in every lock.
Page 28 KEYS AND DOORS Flat key Starting the engine using a flat key 11g039c 11sa05 As a transponder chip is built in its key case, you can start 1. Remove the key plate from the key case. the engine with this key. 2.
Page 29 KEYS AND DOORS NOTICE D Do not let the key case become bent as the key plate may fall out or become bent also. 11R055 D The flat key is designed for emergency use only. So do not use it regularly instead of other master keys. D When starting the engine, do not use the key in 11L021-2 proximity with other transponder keys (including the...
Page 30: Engine Immobilizer System
KEYS AND DOORS ENGINE IMMOBILIZER SYSTEM 11G035c 11sa04 D Do not bend the key grip or flat key. D Do not cover the key grip or flat key with any material The engine immobilizer system is a theft prevention system. When you insert the key in the ignition switch, the that cuts off electromagnetic waves.
Page 31 KEYS AND DOORS For your Lexus dealer to make you a new key with a built-in For vehicles sold in Canada transponder chip, your dealer will need your key number and master key. However, there is a limit to the number of This device complies with RSS- 210 of Industry additional keys your Lexus dealer can make for you.
Page 32: Wireless Remote Control
17. You can also have the battery of the key replaced by your Lexus dealer. If you lose the wireless key, contact your Lexus dealer as soon Locking the doors and sounding an alarm as possible to avoid the possibility of theft, or an accident.
Page 33 ***The turn signal the doors will be automatically locked again. lights can be set not to flash. Ask your Lexus dealer for Even if the ”LOCK” or ”UNLOCK” button is kept pressed in, the details.
Page 34 NOTE: *The operation method can be changed. Ask your This function does not work when the ignition switch is in the Lexus dealer for details. ”ON” position. NOTE: *The alarm can be set not to sound. Ask your Lexus dealer for details.
Page 35 Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to NOTE: *The windows can be deactivated. Ask your Lexus provide reasonable protection against harmful dealer for details.
Page 36 D When replacing the battery, be careful not to lose the components, screws and O-ring. D Replace only with the same or equivalent type recommended by a Lexus dealer. D Dispose of used batteries according to the local laws. 2. Remove the module from the key frame.
Page 37 KEYS AND DOORS NOTICE Take care not to damage or bend the O-ring when installing. 11L030-1 6. Install the module into the key frame and secure the cover with the screw. 7. When pushing any button on the wireless key, make sure the indicator light comes on.
Page 38: Doors
Do not pull the inside handle of the side doors while driving. The doors will open and an accident may occur. NOTE: *The 2-step unlocking function can be changed. Lexus strongly recommends that all children be placed Ask your Lexus dealer for details. in the rear seat of the vehicle.
Page 39 “P” position. This auto door locking function is operable while the ignition switch is turned to the “ON” position. NOTE: * This auto door locking function can be disabled or changed. Ask your Lexus dealer for details.
Page 40: Theft Deterrent System
If you lock them with wireless remote control, the turn signals flash once.* NOTE: *The turn signals can be set not to flash. Ask your Lexus dealer for details. The flashing indicator light remains on when all the doors, trunk and hood are closed and locked.
Page 41 NOTE: *The turn signals can be set not to flash. Ask your The system should activate the alarm. Lexus dealer for details. 4. Unlock any of the doors with a key or the wireless remote control to cancel the system.
Page 42 SECTION – INSTRUMENTS AND CONTROLS Switches Headlight switch ..............Headlight dimmer and turn signal switches .
Page 43: Switches
12L086b NOTE: *The operating condition or sensitivity can be changed. Ask your Lexus dealer for details. To turn the lights on, twist the knob on the end of the lever. 12sa10 FIRST CLICKSTOP: Only the parking, tail, license plate, side marker and instrument panel lights turn on.
Page 44 NOTE: *The time before turning off the lights can be changed. Ask your Lexus dealer for details. Twist the knob to the second clickstop to turn on the headlights to full intensity for driving at night.
Page 45: Headlight Dimmer And Turn Signal Switches
For the headlight flasher, pull it further back. If this system fails, the warning light in the instrument cluster A blue light in the instrument cluster indicates high beam or comes on. If this occurs, have your vehicle checked by Lexus headlight flasher is on. dealer.
Page 46: Fog Light Switch
SWITCHES FOG LIGHT SWITCH 12L088b 12SA11 For signaling turns, move the lever up or down in the conventional manner. To turn on the fog lights, turn the switch to the ”ON” The ignition switch must be in the ”ON” position. position.
Page 47: Switches
This function does not work when the interval adjuster is in the ”F” position. 12L120a NOTE: *This feature can be deactivated. Ask your Lexus dealer for details. For mist wiper operations (a single wipe), pull the lever toward you and release it.
Page 48: Headlight Cleaner Switch
SWITCHES When the outside temperature is below 25 _C (77 _F), HEADLIGHT CLEANER SWITCH operating the wipers will automatically turn on the outside rear view mirror defogger. The outside rear view mirror defogger turns off 15 minutes after the wiper stops operating. In cold weather, warm the windshield with the defroster before using the washer.
Page 49: Rear Window And Outside Rear View Mirror Defogger Switch
SWITCHES REAR WINDOW AND OUTSIDE CAUTION REAR VIEW MIRROR DEFOGGER Since the mirror surfaces can get hot, do not touch them SWITCH when the switch is on. If further defrosting or defogging is desired, simply actuate the switch again. When the surface has cleared, push the switch once again to turn the defogger off.
Page 50: Power Window Switches
SWITCHES POWER WINDOW SWITCHES 12L010 12sa04b Operating the switches " 1 For driver’s window To raise or lower the windows, pull the switch halfway up or push it halfway down. 2 For front passenger’s window Automatic operation: To fully raise or lower the window To raise or lower the windows, use the switch on each automatically, pull the switch fully up or push it fully down.
Page 51 SWITCHES Operating the windows from outside the vehicle The windows can be operated using an ignition key.* NOTE: *This feature can be deactivated. Ask your Lexus 12sa05b dealer for details. " Indicator light 12sa06a With the window lock switch pressed in, only the driver’s window can be raised or lowered.
Page 52 SWITCHES Jam protection function D Be sure to remove the ignition key when you leave your vehicle. If something gets caught between the window and window frame during automatic raising operation, key off raising D Never leave anyone (particularly a small child) alone operation or raising operation using the ignition key from the in your vehicle, especially with the ignition key still outside, the window stops and is lowered.
Page 53: Emergency Flasher Switch
SWITCHES EMERGENCY FLASHER SWITCH SEAT HEATER SWITCHES 12sa07 12sa08a " 1 For front passenger’s seat To turn on the emergency flashers, push the switch. 2 For driver’s seat All the turn signal lights will flash. The emergency flashers will The seat heater has 2 dials. Turn the dials to the left to turn work with the engine running or off and with or without the the respective seat heaters on.
Page 54 SWITCHES CAUTION Occupants must use caution when operating the seat heater because they may experience minor burns even at low temperatures. Use extra caution for; D Babies, small children, elderly persons, sick persons or handicapped persons D Persons who have delicate skin D Persons who are exhausted D Persons who have taken alcohol or drugs which induce sleep (sleeping drug, cold remedy, etc.).
Page 55 SWITCHES...
Page 56 SECTION – INSTRUMENTS AND CONTROLS Gauges, meters and service reminder indicators Fuel gauge ............... . . Engine coolant temperature gauge .
Page 57: Gauges, Meters And Service Reminder Indicators
Your vehicle may overheat during severe operating conditions, The indicator lamp goes off after driving several times. If the such as: indicator lamp does not go off, contact your Lexus dealer as D Driving up a long hill on a hot day. soon as possible.
Page 58: Tachometer
GAUGES, METERS AND SERVICE REMINDER INDICATORS D Idling for a long period with the air conditioning on in TACHOMETER stop-and-go traffic. NOTICE D Do not remove the thermostat in the engine cooling system as this may cause the engine to overheat. The 13sa03b thermostat is designed to control the flow of coolant to keep the temperature of the engine within the...
Page 59: Odometer And Trip Meter
”ODO/TRIP” button. To set the A trip meter to zero, display the A meter reading, then push the ”RESET” button. The same applies for the B trip meter. Take vehicle to Lexus The data of trip meters will be cancelled if the electrical power dealer immediately.
Page 60 Stop and check. Close all doors. (Indicator and buzzer) Stop and check. Replace bulb. Add engine oil. Add washer fluid. Take vehicle to Lexus dealer. Take vehicle to Lexus dealer. Take vehicle to Lexus dealer. Take vehicle to Lexus If brake system dealer.
Page 61 GAUGES, METERS AND SERVICE REMINDER INDICATORS (a) Brake System Warning Light and Buzzer IF THIS INDICATOR OR DO THIS. BUZZER COMES ON ... This light comes on in the following cases when the ignition switch is in the “ON” position. Adjust tire inflation D When the parking brake is applied ...
Page 62 CAUTION system, and it is not a malfunction. If either of the following conditions occurs, immediately stop your vehicle at a safe place and contact your Lexus dealer. D The light does not turn off even after the parking brake is released while the engine is running.
Page 63 If either of the following conditions occurs, this indicates a malfunction somewhere in the parts monitored by the warning This light reminds you to buckle up the front passenger’s seat light system. Contact your Lexus dealer as soon as possible belt. to service the vehicle.
Page 64 If it flickers or stays on while you are driving, pull off the road engine, and check for the cause. Look first at the engine drive to a safe place and stop the engine immediately. Call a Lexus belt. dealer or qualified repair shop for assistance.
Page 65 D There is a problem somewhere in the engine, emission control system, electronic throttle control system, automatic transmission electrical system or warning light system itself. Contact your Lexus dealer as soon as possible to service the vehicle.
Page 66 Thereafter, if either of the systems malfunctions, the vehicle at low speeds. Have your Lexus checked by your light comes on again. Lexus dealer as soon as possible.
Page 67 If it comes on, have your vehicle checked by your Lexus dealer. (j) Open Door Warning Light and Buzzer This light remains on until both side doors and trunk lid are completely closed.
Page 68 If the ”VSC” warning light and ”VSC OFF” indicator light come means the low tire pressure warning light is operating properly. on, have your vehicle checked by Lexus dealer as soon as possible. If the warning light does not go off, or comes on or blinks during...
Page 69 If the warning light does not go off more than 15 minutes after Decrease your speed as soon as possible and call a Lexus the tire inflation pressure is adjusted, the system might be dealer, Roadside Assistance or Customer Service Assistance malfunctioning.
Page 70 D Take due care not to go over a curb stone and be If the warning light blinks and chimes sound, take your vehicle to the nearest Lexus dealer or authorized tire careful of holes in the road because deflated tire dealer as soon as possible, observing the following pressure affects tire cushion performance.
Page 71 If the warning light blinks and chimes sound, observe air is put in the deflated tire, the system might be the following instructions: malfunctioning. Consult your Lexus dealer. D Decrease the speed as soon as possible. D Avoid abrupt steering wheel maneuvering and CAUTION braking.
Page 72 D When the tires must be repaired or replaced, have (except the low fuel level warning light): them repaired or replaced by the nearest Lexus 1. Apply the parking brake. dealer or authorized tire dealer. The tire pressure sensors will be affected by the installation or removal 2.
Page 73: Trip Information Display
It is normal if they go out after a while. D Average fuel consumption If any service reminder indicator or warning buzzer does not function as described above, have it checked by your Lexus D Average vehicle speed dealer as soon as possible.
Page 74 GAUGES, METERS AND SERVICE REMINDER INDICATORS D Available driving distance D Average fuel consumption (Figures with “Mi” or “km”) (Figures with “MPG” or “L/100km”) w155b w167a " When the fuel gauge is not close to ”E” The average fuel consumption is calculated and displayed based on the total driving distance and the total fuel consumption with the engine running.
Page 75: Compass
GAUGES, METERS AND SERVICE REMINDER INDICATORS D Average vehicle speed COMPASS (Figures with “MPH” or “km/h”) (Vehicles without Navigation System) w166a 13sa06a The average vehicle speed is calculated and displayed based on the total driving distance and the total driving time with the engine running.
Page 76 GAUGES, METERS AND SERVICE REMINDER INDICATORS The compass may not show the correct direction in the COMPASS SENSOR following conditions: D The vehicle is stopped immediately after turning. The compass does not adjust while the vehicle is stopped. D The ignition switch is turned off immediately after turning. 13SA10a The compass does not adjust while the vehicle is stopped.
Page 77 GAUGES, METERS AND SERVICE REMINDER INDICATORS CALIBRATING THE COMPASS The direction display on the compass deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. To adjust for this deviation, stop the vehicle and with the ignition on, push the “ODO/TRIP”...
Page 78 GAUGES, METERS AND SERVICE REMINDER INDICATORS Other Areas Zone Number A. Samoa Hawaii Guam 13sa07b Saipan Puerto Rico CAUTION After you select the zone number, push the “ODO/TRIP” Do not adjust the display while the vehicle is moving. button. “--” blinks on the display. Then perform the circling Be sure to adjust the display only when the vehicle is calibration according to the following procedure.
Page 79 If calibration cannot be performed because of the vehicle is magnetized, take your vehicle to a Lexus dealer. If you want to cancel the calibration before it is complete, push the “ODO/TRIP” button while “--” is blinking on the display.
Page 80: Instrument Panel Light Control
GAUGES, METERS AND SERVICE REMINDER INDICATORS INSTRUMENT PANEL LIGHT CONTROL 13SA05a To adjust the brightness of the instrument panel lights, turn the knob. When the headlight switch is in the first or second click stop, you can also adjust the brightness of the displays on the audio and air conditioning systems using this knob.
Page 81 GAUGES, METERS AND SERVICE REMINDER INDICATORS...
Page 82 SECTION – INSTRUMENTS AND CONTROLS Interior equipment Vanity mirrors ............... Interior light .
Page 83: Interior Equipment
INTERIOR EQUIPMENT VANITY MIRRORS Sun visors 14sa02 14sa01 To block out glare from the front, swing the sun visor To use the vanity mirrors, swing the sun visor down and down. open the cover. To block out glare from the side, remove the sun visor The vanity light comes on when you open the cover.
Page 84: Interior Light
INTERIOR EQUIPMENT INTERIOR LIGHT PERSONAL LIGHTS 14sa03b 14sa04b To turn on the interior light, slide the switch. To turn on the personal light, push the switch. To turn it off, push the switch again. With the switch in the ”DOOR” position, the light comes on when either of the side doors is opened.
Page 85: Ignition Switch Light
INTERIOR EQUIPMENT IGNITION SWITCH LIGHT CLOCK 14sa05 14sa06 For easy access to the ignition switch, the ignition switch The digital clock indicates the time on the automatic air light comes on when either of the side doors is opened. conditioning control panel. To reset the hour, press the ”H”...
Page 86: Cigarette Lighter And Ashtray
When finished with your cigarette, thoroughly extinguish it in the ashtray to prevent other cigarette butts from catching fire. After using the ashtray, push it back in completely. To remove the ashtray, pull it out. Use a Lexus genuine cigarette lighter or equivalent for replacement.
Page 87: Rear Console Box
INTERIOR EQUIPMENT REAR CONSOLE BOX 14sa10 14sa09b " 1 Unlock 2 Lock To lock the lower box, insert the master key and turn it " 1 For upper tray 2 For lower box clockwise. To use the rear console box, open as shown in the A loop of wire for unlocking the trunk lid is located in the lower illustration.
Page 88: Power Outlet
INTERIOR EQUIPMENT POWER OUTLET NOTICE D To prevent the fuse from being blown, do not use the electricity over the total vehicle capacity of 12V 10A. D To prevent the battery from being discharged, do not use the power outlet longer than necessary when the engine is not running.
Page 89: Auxiliary Box
INTERIOR EQUIPMENT AUXILIARY BOX GLOVE BOX 14sa20 14sa11 " 1 Unlock The auxiliary box is located behind the rear console box. 2 Open 3 Lock To use the box, open the cover. To open the glove box door, pull the lever. To lock the Do not keep the valuables in this box as it cannot be locked.
Page 90: Garage Door Opener
INTERIOR EQUIPMENT The trunk lid opener main switch is located in the glove box. GARAGE DOOR OPENER When keeping items in the trunk, be sure to turn off the main switch and lock the glove box and rear console box in which a The garage door opener ( Universal loop of wire for unlocking the trunk lid is located.
Page 91 INTERIOR EQUIPMENT The battery side of the hand-held transmitter must be pointed If the garage door does not operate, identify if your garage away from the HomeLink during the programming process. transmitter is of the “Rolling Code” type. Press and hold the programmed HomeLink button.
Page 92 INTERIOR EQUIPMENT 3. Press and release the vehicle’s programmed HomeLink Programming an entrance gate / button twice. The garage door may open. If the door does Programming all devices in the Canadian open, the programming process is complete. If the door does market not open, press and release the button a third time.
Page 93 To program other devices such as home security systems, To operate the HomeLink , press the appropriate HomeLink home door locks or lighting, contact your authorized Lexus button to activate the programmed device. The HomeLink dealer for assistance. indicator light should come on. If the “Rolling Code” type...
Page 94 INTERIOR EQUIPMENT (c) Erasing the entire HomeLink memory This device complies with Part 15 of the FCC Rules (all three programs) and with RSS-210 of the Industry Canada. Operation is subject to the following two conditions: (1) This To erase all previously programmed codes at one time, press device may not cause harmful interference, and (2) this and hold down the 2 outside buttons for 20 seconds until the device must accept any interference received, including...
Page 95: Cup Holder
INTERIOR EQUIPMENT CUP HOLDER 14sa24 14sa13a To close the cup holder, push in the cup holder in the arrow direction 1 and close the lid in the arrow direction To use the cup holder, push the cup holder lid. CAUTION D Do not place anything else other than cups or drink-cans in the cup holder, as such items may be thrown about in the compartment and possibly injure...
Page 96: Coin Box
INTERIOR EQUIPMENT COIN BOX FIRST-AID KIT SPACE 14sa14b 14sa21 To use the coin box, slide the switch backward. This space is provided on the right side of the trunk to accommodate the first-aid kit. CAUTION Keep the coin box closed when not in use.
Page 97: Floor Mat
INTERIOR EQUIPMENT FLOOR MAT 14sa18a 14sa17a CAUTION Use a floor mat of the correct size. Make sure the floor mat is properly placed on the floor If the floor carpet and floor mat have 2 holes, then they are carpet. If the floor mat slips and interferes with the designed for use with locking clips.
Page 98: Luggage Cover
INTERIOR EQUIPMENT LUGGAGE COVER See “Cargo and luggage” on page 234 for precautions in loading luggage. The retractable hardtop cannot be opened if the luggage cover is not set. NOTICE 14sa22a D Do not place anything on the luggage cover. Doing so could interfere with the retractable hardtop opening and damage its mechanism.
Page 99: Tie-Down Hooks
INTERIOR EQUIPMENT TIE-DOWN HOOKS 14sa16b To secure your luggage, use the tie- down hooks as shown above. See “Cargo and luggage” on page 234 for precautions in loading luggage.
Page 100 SECTION – INSTRUMENTS AND CONTROLS Exterior equipment Retractable hardtop ..............Hood .
Page 101: Exterior Equipment
If the indicator remains on or off with the switch pushed, and the retractable hardtop does not activate, have your vehicle checked by your Lexus dealer. If you hold down the switch on the “OPEN” side after or when the retractable hardtop is opened fully, the side windows will close.
Page 102 If the indicator remains on or off with the switch pushed, and the retractable hardtop does not activate, have your vehicle checked by your Lexus dealer. If you hold down the switch on the “CLOSE” side after or when the retractable hardtop is closed fully, the side windows will close.
Page 103 EXTERIOR EQUIPMENT If you drive your vehicle without the retractable hardtop CAUTION closed fully, a beep continues sounding. After you stop your vehicle in a safe place, immediately either open or To avoid serious personal injury, you must do the close the retractable hardtop fully.
Page 104 EXTERIOR EQUIPMENT D Before opening or closing the retractable hardtop, NOTICE first make sure it is safe to do so. Always make sure D When opening or closing the retractable hardtop, nobody places his/her head, hands or other parts of the body on the hardtop mechanism on the windows.
Page 105: Hood
EXTERIOR EQUIPMENT HOOD D Do not open the trunk when the retractable hardtop is not closed or opened fully. The opened trunk may not be closed. D Do not open or close the retractable hardtop repeatedly within a short time. If the motor prevention circuit activates, the retractable hardtop operation is disabled.
Page 106: Trunk Lid
EXTERIOR EQUIPMENT TRUNK LID Trunk lid opener 15sa04 15sa07a 2. Insert your fingers under the hood, push up the auxiliary catch lever and lift the hood. Before closing the hood, check to see that you have not forgotten any tools, rags, etc. Then lower the hood and make To open the trunk lid while sitting in the driver’s seat, push sure it locks.
Page 107 EXTERIOR EQUIPMENT Trunk lid opener main switch CAUTION D Keep the trunk lid closed while driving. This not only prevents luggage from being thrown out, but also prevents exhaust gases from entering the vehicle. D Always lock the trunk lid and all doors, and keep the 15sa11 vehicle keys out the reach of children.
Page 108 EXTERIOR EQUIPMENT Internal trunk release handle 15sa10 15sa06a To close the trunk lid, pull down the lever and push down the trunk lid. After closing the trunk lid, try pulling it up to make sure it is securely closed. If a person is locked in the trunk, he/she can pull down the phosphorescent handle on the inside of trunk lid to open the trunk lid.
Page 109: Fuel Tank Cap
The indicator lamp goes off after driving several times. If the D Do not smoke, cause sparks or allow open flames indicator lamp does not go off, contact your Lexus dealer as when refuelling. The fumes are flammable. soon as possible.
Page 110 In case the opener is not actuated CAUTION D Make sure the cap is installed securely to prevent fuel spillage in the event of an accident. D Use only a genuine Lexus fuel tank cap for replacement. It is designed to regulate fuel tank 15sa09a pressure.
Page 111 EXTERIOR EQUIPMENT...
Page 112 SECTION – INSTRUMENTS AND CONTROLS Occupant restraint systems Seats ................Front head restraints .
Page 113: Occupant Restraint Systems
OCCUPANT RESTRAINT SYSTEMS SEATS Front seat precautions Driver seat While the vehicle is being driven, all vehicle occupants should have the seatback upright, sit well back in the seat and properly wear the seat belts provided. CAUTION The SRS driver airbag deploys with considerable force, CAUTION and can cause death or serious injury especially if the driver is very close to the airbag.
Page 114 OCCUPANT RESTRAINT SYSTEMS Front seats (with SRS side airbags) D If your steering wheel is adjustable, tilt it downward. This points the airbag toward your chest instead of your head and neck. CAUTION The seat should be adjusted as recommended by The SRS side airbags are installed in the driver and front NHTSA above, while still maintaining control of the foot passenger seats.
Page 115 OCCUPANT RESTRAINT SYSTEMS Seat adjustment precautions Adjusting front seats CAUTION D Do not adjust the seat while the vehicle is moving as the seat may unexpectedly move and cause the driver to lose control of the vehicle. 16sa01c D Be careful that the seat does not hit a passenger, luggage or the rear seat.
Page 116 OCCUPANT RESTRAINT SYSTEMS Adjusting seat position 2. Move the seatback angle switch forward until a beeping sound is emitted. 16sa02c Move the control switch in the desired direction. Releasing the switch will stop the seat in that position. Do not place anything under the seat, as this might interfere with the seat movement.
Page 117 OCCUPANT RESTRAINT SYSTEMS Adjusting seatback angle CAUTION To reduce the risk of sliding under the lap belt during a collision, avoid reclining the seatback any more than needed. The seat belts provide maximum protection in a frontal or rear collision when the driver and the front passenger are sitting up straight and well back in the 16sa03d seats.
Page 118 OCCUPANT RESTRAINT SYSTEMS Adjusting seat cushion angle and height Adjusting lumbar support 16sa04b 16sa05b Move the control switch in the desired direction. Push the control switch on either side. Releasing the switch will stop the seat cushion in that position. The amount of lumbar support will change while the switch is pushed.
Page 119 OCCUPANT RESTRAINT SYSTEMS Inclining front seats for rear seat entry FRONT HEAD RESTRAINTS 16sa29c 16sa30 Lift the seatback lock release lever on the side of the seat For your safety and comfort, adjust the head restraint or on the side of the seatback. The seatback will incline. before driving.
Page 120 Seat belt precautions closest to the top of your ears. Lexus strongly urges that the driver and passengers in the D After adjusting the head restraint, make sure it is vehicle be properly restrained at all times with the seat belts locked in position.
Page 121 OCCUPANT RESTRAINT SYSTEMS Pregnant woman. Lexus recommends the use of a seat belt. D Be careful not to damage the belt webbing or Ask your doctor for specific recommendations. The lap belt hardware. Take care that they do not get caught or should be worn securely and as low as possible over the hips pinched in the seat or doors.
Page 122 OCCUPANT RESTRAINT SYSTEMS Front seat belt buckle illumination Fastening seat belts 16sa12 16sa13b " 1 Tab Opening the driver’s door lights up the driver’s seat belt 2 Buckle buckle for easy use. The same applies for the front Adjust the seat as needed and sit up straight and well back passenger’s door and seat belt buckle.
Page 123 D If the seat belt does not function normally, CAUTION immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed, because it cannot D Both high-positioned lap belts and loose-fitting protect an adult occupant or your child from injury.
Page 124 OCCUPANT RESTRAINT SYSTEMS Seat belt guides 16sa15b 16sa32b To release the belt, press the buckle release button and allow the belt to retract. The seat belt guides are attached on the shoulders of the If the belt does not retract smoothly, pull it out and check for front seats so that smaller front occupants can easily use kinks or twists.
Page 125 If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Lexus dealer free of charge. Please contact your local Lexus dealer to order the proper required length for the extender. Bring the heaviest coat you 16sa76b expect to wear for proper measurement and selection of length.
Page 126 D If the seat belt does not function normally, immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed, because it cannot protect an adult occupant or your child from injury.
Page 127 OCCUPANT RESTRAINT SYSTEMS Seat belt pretensioners 16st05 16sa17c " 1 Front airbag sensors 2 Seat belt pretensioner assemblies The driver and front passenger seat belt pretensioners are 3 SRS warning light designed to be activated in response to a severe frontal 4 Airbag sensor assembly impact.
Page 128 16sa33a serious injury. Consult your Lexus dealer about any repair and modification. NOTICE Do not perform any of the following changes without This indicator comes on when the ignition switch is turned consulting your Lexus dealer.
Page 129 16sa19 " Front airbags In response to a severe frontal impact, the SRS front In the following cases, contact your Lexus dealer as soon as airbags work together with the seat belts to help reduce possible. injury by inflating. The SRS front airbags help reduce D The front of the vehicle (shaded in the illustration) was injuries mainly to the driver’s or front passenger’s head or...
Page 130 Always wear your seat belt properly. to use a seat belt should be properly secured using child restraint system. Lexus strongly recommends that all infants and children be placed CAUTION in the rear seat of the vehicle and properly restrained.
Page 131 OCCUPANT RESTRAINT SYSTEMS The SRS front airbags are designed to deploy in severe (usually frontal) collisions where the magnitude and duration of the forward deceleration of the vehicle exceeds the designed threshold level. The SRS front airbags will deploy if the severity of the impact 16sa23b is above the designed threshold level, comparable to an approximate 25 km/h (15 mph) collision when the vehicle has...
Page 132 OCCUPANT RESTRAINT SYSTEMS 16sa26 16sa78 " 1 Hitting a curb, edge of pavement or hard surface " 1 Airbag module for front passenger 2 Falling into or jumping over a deep hole (airbag and inflator) 2 Airbag module for driver (airbag and inflator) 3 Landing hard or vehicle falling 3 SRS warning light The SRS front airbags may also deploy if a serious impact...
Page 133 OCCUPANT RESTRAINT SYSTEMS The front airbag sensors constantly monitor the forward Deployment of the airbags happens in a fraction of a second, deceleration of the vehicle. If an impact results in a forward so the airbags must inflate with considerable force. While the deceleration beyond the designed threshold level, the system system is designed to reduce serious injuries, primarily to the triggers the airbag inflators.
Page 134 The driver or front passenger who is too close to the steering wheel or dashboard during airbag deployment can be killed or seriously injured. Lexus strongly 16sa36 recommends that: D The driver sit as far back as possible from the steering wheel while still maintaining control of the vehicle.
Page 135 OCCUPANT RESTRAINT SYSTEMS 16sa39a 16sa41a D Lexus strongly recommends that all infants and D Do not put anything or any part of your body on or in children be placed in the rear seat of the vehicle and front of the dashboard or steering wheel pad that be properly restrained.
Page 136 Failure to follow these instructions can result in death D Modification of the suspension system. or serious injury. Consult your Lexus dealer about any D Modification of the front end structure. repair and modification. D Attachment of a grille guard (bull bar, kangaroo bar, etc.), snowplow, winches or any other equipment to...
Page 137 40.) If any of the following conditions occurs, this indicates a malfunction of the airbags or seat belt pretensioners. Contact In the following cases, contact your Lexus dealer as soon as your Lexus dealer as soon as possible. possible: D When the ignition switch is turned to the “ON” position, the D The SRS front airbags have been inflated.
Page 138 NOTICE protection provided by the seat belts. Do not disconnect the battery cables before contacting your Lexus dealer. 16sa21b " Side airbags In response to a severe side impact, the SRS side airbags for the driver or front passenger work together with the seat belts to help reduce injury by inflating.
Page 139 To ensure child restraint system. Lexus strongly maximum protection in an accident, the driver and all recommends that all infants and children be placed passengers in the vehicle must wear their seat belts in the rear seats of the vehicle and properly properly.
Page 140 OCCUPANT RESTRAINT SYSTEMS 16sa24 16sa25 " 1 Collision from the side at an angle Collision from the side to the vehicle body other than the passenger compartment " 1 Collision from the front The SRS side airbag system may not activate if the vehicle 2 Collision from the rear is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the...
Page 141 OCCUPANT RESTRAINT SYSTEMS When the airbags inflate, they produce a loud noise and release some smoke and residue along with non-toxic gas. This does not indicate a fire. This smoke may remain inside the vehicle for some time, and may cause some minor irritation to the eyes, skin or breathing.
Page 142 OCCUPANT RESTRAINT SYSTEMS 16sa37 16sa38a D Do not allow anyone to lean against the door when D Do not allow anyone to get his/her head closer to the the vehicle is in use, since the side airbag could area where the side airbag inflates, since the side inflate with considerable...
Page 143 OCCUPANT RESTRAINT SYSTEMS 16sa80 16sa42a D Do not allow anyone to kneel on the front passenger D Do not attach a cup holder or any other device or seat, facing the passenger’s side door, since the side object on or around the door. When the side airbag airbag could inflate with considerable speed and inflates, the cup holder or any other device or object force.
Page 144 16sa33a serious injury. Failure to follow these instructions can result in death or serious injury. Consult your Lexus dealer about any repair and modification. NOTICE This indicator comes on when the ignition switch is turned to the ”ON”...
Page 145 16sa77 Do not disconnect the battery cables before contacting your Lexus dealer. In the following cases, contact your Lexus dealer as soon as possible: D The SRS side airbags have been inflated. D The portion of the doors (shaded in the illustration) was involved in an accident that was not severe enough to cause the SRS side airbags to inflate.
Page 146 It is dangerous D Lexus strongly urges use of a proper child restraint if the side airbag inflates, because the impact could system which conforms to the size of the child, cause death or serious injury to the child.
Page 147 OCCUPANT RESTRAINT SYSTEMS Types of child restraint system D Make sure you have complied with all installation instructions provided child restraint Child restraint systems are classified into the following 3 types manufacturer and that the system is properly depending on the child’s age and size. secured.
Page 148 OCCUPANT RESTRAINT SYSTEMS (B) Convertible seat INSTALLATION WITH 3-POINT TYPE SEAT BELT (A) Infant seat installation 16sa47c 16sa46c (C) Booster seat An infant seat must be used in rear-facing position only. 16sa48c...
Page 149 OCCUPANT RESTRAINT SYSTEMS 16sa34 16sa50d D Do not put a child restraint system on the rear seat if CAUTION it interferes with the lock mechanism of the front D Never put a rear-facing child restraint system on the seats. Otherwise, the child or front seat occupants may be killed or seriously injured in case of sudden front passenger seat.
Page 150 D If the seat belt does not function normally, it cannot protect your child from death or serious injury. Immediately contact your Lexus dealer. Do not put the child restraint system on the seat until the seat belt is fixed.
Page 151 OCCUPANT RESTRAINT SYSTEMS 16sa52c 16sa53c 2. Fully extend the shoulder belt to put it in the lock mode. 3. While pressing the infant seat firmly against the seat When the belt is then retracted even slightly, it cannot be cushion and seatback, let the shoulder belt retract as far as it extended.
Page 152 OCCUPANT RESTRAINT SYSTEMS 16sa54c 16sa55a 4. To remove the infant seat, press the buckle release button and allow the belt to retract completely. The belt will move CAUTION freely again and be ready to work for an adult or older child passenger.
Page 153 OCCUPANT RESTRAINT SYSTEMS (B) Convertible seat installation 16sa56 16sa47c CAUTION A convertible seat must be used in forward- facing or rear-facing position depending on the age and size of the D Never put a rear-facing child restraint system on the child.
Page 154 OCCUPANT RESTRAINT SYSTEMS 16sa57 16sa58d " Move seat fully back D Do not put a child restraint system on the rear seat if it interferes with the lock mechanism of the front D A forward-facing child restraint system should be seats.
Page 155 D If the seat belt does not function normally, it cannot protect your child from death or serious injury. Immediately contact your Lexus dealer. Do not put the child restraint system on the seat until the seat belt is fixed.
Page 156 OCCUPANT RESTRAINT SYSTEMS 16sa60d 16sa61d 2. Fully extend the shoulder belt to put it in the lock mode. 3. While pressing the convertible seat firmly against the seat When the belt is then retracted slightly, it cannot be extended. cushion and seatback, let the shoulder belt retract as far as it will go to hold the convertible seat securely.
Page 157 OCCUPANT RESTRAINT SYSTEMS 16sa62d 16sa63a 4. To remove the convertible seat, press the buckle release button and allow the belt to retract completely. The belt will CAUTION move freely again and be ready to work for an adult or older child passenger.
Page 158 OCCUPANT RESTRAINT SYSTEMS (C) Booster seat installation 16sa64 16sa48c " Move seat fully back A booster seat must be used in forward-facing position only. CAUTION D A forward-facing child restraint system should be allowed to be put on the front passenger seat only when it is unavoidable.
Page 159 D If the seat belt does not function normally, it cannot protect your child from death or serious injury. Immediately contact your Lexus dealer. Do not put the child restraint system on the seat until the seat belt is fixed.
Page 160 OCCUPANT RESTRAINT SYSTEMS Using a top strap 16sa66a 16sa68a 2. To remove the child restraint system, press the buckle release button and allow the belt to retract. Follow the procedure below for a child restraint system that requires the use of a top strap. When installing a top strap, the retractable hardtop should be open.
Page 161 OCCUPANT RESTRAINT SYSTEMS 16sa69b 16sa70a " Anchor brackets " 1 Rear cover 2 Anchor bracket Use the anchor bracket in the head restraints of the rear seats. TO USE THE ANCHOR BRACKET Anchor brackets are installed for each rear seating position. 1.
Page 162 OCCUPANT RESTRAINT SYSTEMS Installation with child restraint lower anchorages 16sa71c 16sa72 " 1 Top strap 2 Rear cover 4. Install the rear cover as shown in the illustration For instructions to install the child restraint system, see “Type The lower anchorages for the child restraint system of child restraint system”...
Page 163 OCCUPANT RESTRAINT SYSTEMS 16sa73d 16sa74e Canada only Canada only " Type A " Type B...
Page 164 OCCUPANT RESTRAINT SYSTEMS For owners in Canada CAUTION The symbol on a child restraint system indicates the presence D When using the lower anchorages for the child of a lower connector system. restraint system, be sure that there are no irregular CHILD RESTRAINT SYSTEM INSTALLATION objects around the anchorages or that the seat belt is Type A:...
Page 165 OCCUPANT RESTRAINT SYSTEMS DRIVING POSITION MEMORY 2. While pushing the ”SET” button, push button ”1” or ”2” until the signal beeps. SYSTEM The beep sound means that the positions are recorded in the A microcomputer will memorize the position of the driver’s computer’s memory.
Page 166 OCCUPANT RESTRAINT SYSTEMS Recalling the memorized position Front passenger’s side: D Ignition switch “ON” and selector lever in “N” or “P” position with the vehicle stopped. D Within 30 seconds of opening front passenger’s door. If any driving position memory button is pushed while one of the memorized driving position profiles is being activated, the 16sa45 operation will stop.
Page 167 OCCUPANT RESTRAINT SYSTEMS CAUTION D Do not start the vehicle while the adjustments are being made. D Take care not to select the wrong button, or the seat could strike the rear passenger or hit your body against the steering wheel. If this happens, you can stop the movement by pressing another driving position memory button.
Page 168 SECTION – INSTRUMENTS AND CONTROLS Steering wheel and mirrors Tilt and telescopic steering wheell ........... . Outside rear view mirrors .
Page 169: Steering Wheel And Mirrors
STEERING WHEEL AND MIRRORS TILT AND TELESCOPIC STEERING Adjustment of telescopic steering column WHEEL Adjustment of steering wheel tilt 16sa11a 16sa10a To adjust the steering column length, push the control switch forward or backward to set the steering wheel to the desired position.
Page 170 Any object seen in a convex mirror will look smaller and farther away than if seen in a normal NOTE: *This feature can be deactivated. Ask your Lexus flat mirror. dealer for details.
Page 171 STEERING WHEEL AND MIRRORS Power rear view mirror control CAUTION D Do not adjust the mirror while the vehicle is moving. Doing so may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious injuries. D Since the mirror surfaces can get hot, do not touch 16sa31a them when the rear window and outside rear view...
Page 172 STEERING WHEEL AND MIRRORS When you are backing up, you can adjust the mirrors Folding rear view mirrors down quickly by the following operations with the ignition D Put the selector lever in the “R” position. D Place the master switch at “L” (left) or “R” (right). The mirrors return to the previous position by any of the 16sa07 following operations.
Page 173 STEERING WHEEL AND MIRRORS INSIDE REAR VIEW MIRROR When the outside air temperature is low, it may take a little longer for the mirror to darken in response to the detection of headlights. CAUTION Do not adjust the mirror while the vehicle is moving. 16sa06a Doing so may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious...
Page 174 SECTION – AIR CONDITIONING AND AUDIO Air conditioning Automatic air conditioning controls ........... . 156...
Page 175 AIR CONDITIONING AUTOMATIC AIR CONDITIONING CONTROLS In the automatic operation mode, the air conditioning selects the most suitable fan speed, air flow, air intake and on-off of "You can adjust the brightness of the display. See the air conditioning according to the temperature. “Instrument panel light control”...
Page 176 AIR CONDITIONING Driver side temperature display (in degrees Fahrenheit or Centigrade) Fan speed display Air flow display Outside temperature display (in degrees Fahrenheit or Centigrade) Passenger side temperature display (in degrees Fahrenheit or Centigrade) Separate/dual control button Passenger side temperature control button Air conditioning on-off button Air intake control button Air flow control button...
Page 177 AIR CONDITIONING " Air flow selection Air flows from the lap-jet vents only when the retractable hardtop is opened. See “Lower vent” on page 167. 21sa11c...
Page 178 AIR CONDITIONING (a) Climate control SETTING OPERATION - automatic control 21sk02 21sa10 2. Use the ”TEMP” or ”PASSENGER TEMP” button to set the desired temperature. The ”TEMP” or ”PASSENGER TEMP” button is used to set the 1. Push the ”AUTO” button. desired temperature.
Page 179 AIR CONDITIONING SETTING OPERATION - manual control When one of the manual control buttons is depressed while operating in automatic mode, the mode relevant to the depressed button is set. Other conditions continue to be adjusted automatically. If manual air flow selection is desired - 21sa04 21sa12b The outlets from which air is delivered can be selected...
Page 180 AIR CONDITIONING Floor/Windshield - Air flows mainly from the floor vents, If manual switching of air intake is desired - the windshield vents and the lap- jet vents (if the retractable hardtop is opened). It is recommended that you close the lower vent. For details about this, see page 167.
Page 181 AIR CONDITIONING Turning off the air conditioning manually will cancel the EXHAUST GAS AUTOMATIC mode. If you select the “AUTO” mode during fan operating, the air conditioning turns on and the EXHAUST GAS AUTOMATIC mode will operate. For normal use, it is best to keep the air intake control button 21sa08a set to OUTSIDE AIR mode.
Page 182 ”A/C” button will blink. If the indicator of the ”A/C” button blinks even when the ”A/C” button is pushed 3. Push the fan speed control button on the right side to obtain again, have the compressor checked by your nearest Lexus a maximum air flow. dealer.
Page 183 AIR CONDITIONING When the ”FRONT WINDSHIELD” button is pushed while (c) Air conditioning filter operating in automatic mode, the air conditioning is set to operate and the OUTSIDE AIR mode is set. If you push the ”FRONT WINDSHIELD” button once again while in the FRONT WINDSHIELD mode, the mode then returns to the last mode used.
Page 184 AIR CONDITIONING 21sa13c 21L164a " Soft cloth " 1 Filter 2 Filter case 1. Use pliers to remove the 2 pins installed on the upper 3. Remove the filter from the filter case. part of the glove box and lower the glove box. 4.
Page 185 AIR CONDITIONING (d) Operating tips INFORMATION D Make sure the air inlet grilles in front of the windshield are The filter should be installed properly in position. The not blocked by leaves or other obstructions. use of air conditioning with the filter removed may D If air flow control is not satisfactory, check the dashboard cause deteriorated dustproof performance and then af- vents.
Page 186 AIR CONDITIONING Center vents Lower vent 21st01 21sa14a The center vents may be opened or closed as shown. The lower vent may be opened or closed as shown. For removing frost or fog, it is recommended that you close the Side vents lower vent when you push the “FRONT WINDSHIELD”...
Page 187 AIR CONDITIONING...
Page 188 SECTION – AIR CONDITIONING AND AUDIO Audio Audio system ..............
Page 189 AUDIO AUDIO SYSTEM Quick reference for your audio system 22sa01a " You can adjust the brightness of the display. See “Instrument panel light control” on page 61 for details. The display may be tinged in purple due to the reflection of sunlight, but this is not a malfunction.
Page 190 AUDIO Ejecting a compact disc Function buttons (See page 184 for details.) 1 - 6: Station selector buttons Display of functions in TAPE or CD mode (See page 178 for details.) A " : Side change SCAN: Scan tuning (See page 182 for details.) (See page 178 for details.) : DOLBY NR MSG: Message button...
Page 191 AUDIO Using your audio system: some basics (a) Your audio system This section describes some of the basic features of the Lexus audio system. Some information may not pertain to your system. Your audio system adjusts to the optimum volume and tone...
Page 192 AUDIO (b) Turning the system on and off 22sa03 22sa02 Push ”AM”, ”FM”, ”TAPE” or ”DISC” to turn on that mode. The selected mode turns on directly. Push this knob to turn the audio system on and off. Turn Push these buttons if you want to switch from one mode to this knob to adjust the volume.
Page 193 AUDIO 22sa04 22sa05 In the ”TAPE” or ”CD” mode, the applicable functions are Each time you push the ”AUDIO-TUNE” knob, the display shown in the lowest part of the display. Push the switch changes as in the following. To adjust the tone and just below to turn on each function.
Page 194 D Putting a window tint (especially, conductive or metallic type) on the windshield may affect the reception of radio or mobile telephone. For the installation of the window tint, consult with your Lexus dealer.
Page 195 AUDIO D The following products may not be playable on your (f) Your changer compact disc player. Copy-protected CD CD-R (CD-Recordable) CD-R W (CD-Re-writable) CD-ROM 22sa06 D Your compact disc player is intended for use with 12 cm (4.7 in.) discs only. Radio operation (a) Listening to the radio Your changer can store up to 6 discs and play selected discs...
Page 196 AUDIO (b) Presetting a station 22sa12 22sa08 Turn this knob to the right to step up the station band or to the left to step down. 1. Tune in the desired station. Your radio automatically changes to stereo reception when a 2.
Page 197 AUDIO (c) Selecting a station Tune in the desired station using one of the following methods. 22sa09 22sa13 To scan all the frequencies: Push the ”SCAN” button briefly. ”SCAN” appears on the display. The radio will find the next station up the band, stay there for a few seconds, and then scan again.
Page 198 AUDIO (d) RDS (Radio Data System) TYPE (Program type): When you push the “TYPE” button while receiving an RDS station, the current program type appears on the display. Each time you push the “TYPE” button, the program type changes as in the following: D ROCK 22sa14 D EASY LIS (Easy listening)
Page 199 AUDIO Radio text message: To recall a radio text message, push the “MSG” button. Each time you push the button, the available message will be displayed beginning with the newest one. If there is no radio text message in memory and when no message is received, “NO MSG STORED”...
Page 200 AUDIO Cassette tape player operation (a) Playing a cassette tape 22sa16 22sa11 If a cassette is already in the slot, push the ”TAPE” button. Dolbyr Noise Reduction* feature: If you are listening to a tape that was recorded with Dolby* Noise Reduction, push the When you insert a cassette tape, the exposed tape should “...
Page 201 AUDIO (b) Manual program selection (c) Automatic program selection 22sa19 22sa21a A " ”Program” button: Push the ” ” button to select the ”RPT” button: The repeat feature automatically replays the other side of a cassette tape. The display indicates which side current program.
Page 202 AUDIO Push this button on the lower side to skip backward. Push the button until ”REW” and the number you want to skip appear on the display. D If you set ”REW 1”, the player will rewind to the beginning of the current program.
Page 203 AUDIO Compact disc player operation If you need to insert the next disc, repeat the same procedure to insert another disc. (a) Inserting or ejecting compact discs D Setting all the discs: The ignition switch must be in the ”ACC” or ”ON” position. 1.
Page 204 AUDIO (b) Playing a compact disc 22sa23a 22sa24 D Ejecting a single disc alone: 1. Push the ” ” or ” ” button to display the disc number Push the ”DISC” button if the discs are already loaded in you want to eject. the player.
Page 205 AUDIO (c) Selecting a desired disc (d) Searching for a desired track or disc 22sa25 22sa26 Searching for a desired disc: Searching for a desired track: Push the ” ” or ” ” button to select the disc number. Push the “SCAN” button briefly. ”SCAN” will appear on the display.
Page 206 AUDIO (e) Selecting a desired track (f) Repeating a track or a disc 22sa27 22sa28a ”TRACK” button: Use for direct access to a desired track. ”RPT” button: There are 2 repeat features — you can either replay a disc track or a whole compact disc. Push either side of the ”TRACK”...
Page 207 If the malfunction is not rectified, take your vehicle to your in random order, or only listen to the tracks on a specific Lexus dealer. compact disc in random order. Random playing for the tracks on a disc: Push the ”RAND”...
Page 208 AUDIO Steering pad switches “B” or “Y” switch: The function in each mode is shown below. (a) When the radio mode is selected D Push this switch briefly to select a station that you assigned to a switch on the audio system. D Push this switch and hold it until you hear a beep.
Page 209 AUDIO Car audio system operating hints Fading and drifting stations - Generally, the effective range of FM is about 40 km (25 miles). Once outside this range, you NOTICE may notice fading and drifting, which increase with the distance from the radio transmitter. They are often To ensure correct audio system operations: accompanied by distortion.
Page 210 AUDIO D Do not leave a cassette in the player if you are not listening to it, especially if it is hot outside. Fading - AM broadcasts are reflected by the upper D Store cassettes in their cases and out of direct sunlight. atmosphere - especially at night.
Page 211 AUDIO 20L037 22sv01 D Use only compact discs marked as shown above. The " Special shaped discs following products may not be playable on your compact disc player. Copy-protected CD CD-R (CD-Recordable) CD-R W (CD-Re-writable) CD-ROM 22sv02 " Low quality discs...
Page 212 AUDIO 22sv03 20L038 " Labeled discs " Correct " Wrong D Handle compact discs carefully, especially when you set them into the player. Hold them on the edge and do not bend NOTICE them. Avoid getting fingerprints on them, particularly on the shiny side.
Page 213 AUDIO 20L039 To clean a compact disc: Wipe it with a soft, lint-free cloth that has been dampened with water. Wipe in a straight line from the center to the edge of the disc (not in a circle). Do not use a conventional record cleaner or anti-static device.
Page 214 SECTION – STARTING AND DRIVING Starting and driving Three-way catalytic converters ............Engine exhaust caution .
Page 215: Three-Way Catalytic Converters
STARTING AND DRIVING THREE-W AY CATALYTIC NOTICE CONVERTERS A large amount of unburned gases flowing into the three-way catalytic converter may cause it to overheat and create a fire hazard. To prevent this and other damage, observe the following precautions: D Use only unleaded gasoline.
Page 216: Engine Exhaust Caution
ENGINE EXHAUST CAUTION D If the engine becomes difficult to start or stalls frequently, take your vehicle in for a check-up as soon as possible. Remember, your Lexus dealer CAUTION knows your vehicle and its three-way catalytic converter system best.
Page 217: Before Starting The Engine
STARTING AND DRIVING IGNITION SWITCH WITH STEERING D To allow proper operation of your vehicle’s ventilation system, keep the inlet grilles in front of the LOCK windshield clear snow, leaves, other obstructions. D If you smell exhaust fumes in the vehicle, drive with the windows open and the trunk lid closed.
Page 218: Parking Brake
PARKING BRAKE the driver’s door, a buzzer will remind you to remove the key.* NOTE: *The volume or interval of beep sound can be changed. Ask your Lexus dealer for details. 31sa06b 31sa05 To set: Fully depress the parking brake pedal.
Page 219: How To Start The Engine
STARTING AND DRIVING HOW TO START THE ENGINE With your foot off the accelerator pedal, crank the engine by turning the ignition switch to ”START”. Release it when the engine starts. Before cranking Engine should be warmed up by driving, not in idle. For 1.
Page 220: Automatic Transmission
STARTING AND DRIVING " The shift position is displayed on the instrument AUTOMATIC TRANSMISSION cluster. Your automatic transmission has a shift lock system to P: Parking, engine starting and key removal position minimize the possibility of incorrect operation. This means you can only shift out of ”P” position when the R: Reverse position brake pedal is depressed with the ignition switch in ”ON”...
Page 221 STARTING AND DRIVING Correct use of the automatic transmission is explained in (a) Normal driving the following parts. (a) Normal driving (b) Using engine braking (c) Using the ”3”, ”2” and ”L” positions 31sa08 (d) Backing up (e) Parking (f) Good driving practice (g) If you cannot shift the selector lever "...
Page 222 ”Power”, ”Normal” or ”Snow” mode to suit low, the transmission will not shift into the overdrive gear even your driving condition. For ordinary driving, Lexus in the ”D” position. (See ”(b) Using engine braking” and ”(f) recommends that you use the ”Normal” position to improve fuel Good driving practice”...
Page 223 STARTING AND DRIVING 5. Release the parking brake and brake pedal. Depress (b) Using engine braking the accelerator pedal slowly for smooth starting. In normal cruising, the vehicle will start in first gear and automatically shift up to the most suitable gear. On inclines, declines or winding roads, etc., the vehicle shifts up and down automatically according to the running conditions to obtain the suitable driving power and engine braking.
Page 224 STARTING AND DRIVING Shift into the ”2” position. The transmission will downshift (c) Using the ”3”, ”2” and ”L” positions to second gear when the vehicle speed is or becomes The ”3”, ”2” and ”L” positions are used for strong engine lower than 82 km/h (51 mph) and more powerful engine braking as described previously.
Page 225 STARTING AND DRIVING (d) Backing up (e) Parking 31sa12 31sa13 " 1 Brake pedal " 1 Brake pedal 2 ”R” (Reverse) position 2 Parking brake pedal 3 ”P” (Park) position 1. Bring the vehicle to a complete stop. 1. Bring the vehicle to a complete stop. 2.
Page 226: Electronic Throttle Control System
If you cannot shift the selector lever even though the brake pedal is depressed, use the shift lock override button. For Normal mode: For ordinary driving, Lexus recommends that instructions, see ”If you cannot shift automatic transmission you use the normal mode to improve fuel economy.
Page 227: Cruise Control
STARTING AND DRIVING In the power mode, the ”ECT PWR” light in the instrument CRUISE CONTROL cluster is on and the transmission is shifted up at higher vehicle speeds and shifted down more responsively than in the normal The cruise control allows you to cruise the vehicle at a mode.
Page 228 STARTING AND DRIVING Turning the system on Setting operation 31sa14 31sa15 " Each function is described below. To operate the cruise control, push the main switch. This turns the system on. The indicator light in the instrument cluster Setting at a desired speed. shows that you can now set your desired cruising speed.
Page 229 If the preset speed automatically cancels out for other than However, a quicker way to reset is to depress the brake pedal these reasons, have your vehicle checked by your Lexus and then press the control lever downward in the dealer at the earliest opportunity.
Page 230: Traction Control System
D The indicator light flashes again. D The indicator light goes out after it comes on. 31sa16a If this is the case, contact your Lexus dealer and have your Lexus inspected. " Slip indicator light When you turn the ignition switch on, this system always turns on.
Page 231: Vehicle Stability Control System
STARTING AND DRIVING When getting the vehicle out of mud or new snow, etc. the VEHICLE STABILITY CONTROL traction control system will help operate to prevent the wheels SYSTEM from spinning. To turn off the traction control system, see page 213. The vehicle stability control system helps provide integrated control of the systems such as an anti-lock brake system, traction control, engine control, etc.
Page 232 If the ”VSC” warning light and ”VSC OFF” indicator light come pushing the ”VSC OFF” switch. The ”VSC OFF” indicator on, have your vehicle checked by Lexus dealer as soon as comes on. At this time, the traction control system also possible.
Page 233: Brake System
If the brake system warning light comes on, immediately Lexus dealer. stop your vehicle and contact your Lexus dealer. The brake system warning light may stay on for about 60 seconds after the ignition switch is turned to the “ON” position.
Page 234 STARTING AND DRIVING You may hear a small sound in the engine compartment after The anti- lock brake system becomes operative after the the engine is started or the brake pedal is depressed vehicle has accelerated to a speed in excess of approximately repeatedly.
Page 235 STARTING AND DRIVING D Driving over the steps such as the joints on the road. CAUTION D Driving on roads where the road surface is pitted or Do not overestimate the anti-lock brake system: has other differences in surface height. Although the anti-lock brake system assists in Install all 4 tires of specified size at appropriate providing vehicle control, it is still important to drive...
Page 236 Lexus dealer. seconds. Thereafter, if either of the systems malfunctions, the In this case, not only the anti-lock brake system will fail light comes on again.
Page 237: Brake Pad Wear Limit Indicators
If you hear a squealing or scraping noise while driving, have speed below approximately 5 km/h (3 mph). the brake pads checked and replaced by your Lexus dealer as soon as possible. Expensive rotor damage can result if the The brake assist system may not work for about 60 seconds pads are not replaced when needed.
Page 238: Tire Pressure Warning System
If you cannot verify the tire inflation pressure is low. Make sure there is no flat tire. If the warning pressure soon, go to the nearest Lexus dealer or authorized light comes on again even after air is put in the tires, a tire may tire dealer at the moderate speed and do not ever exceed 90 be flat or the system may be malfunctioning.
Page 239 Decrease your speed as soon as possible and take your If the warning light comes on, take your vehicle to the vehicle to the nearest Lexus dealer or authorized tire dealer at nearest Lexus dealer, tire dealer or gas station as soon a speed below 90 km/h (55 mph).
Page 240 D When the tires must be replaced, have them replaced malfunctioning. Consult your Lexus dealer. by the nearest Lexus dealer or authorized tire dealer. The tire pressure sensor will be affected by the CAUTION installation or removal of tires.
Page 241 D When the tires must be repaired or replaced, have located in the tool bag. Locate the deflated tire and change to them repaired or replaced by the nearest Lexus the spare tire. For the procedure for changing the tire, see “If dealer or authorized tire dealer.
Page 242 STARTING AND DRIVING For vehicles sold in U.S.A. CAUTION This device complies with Part 15 of the FCC Rules. D The use of non-genuine wheels will cause the tire Operation is subject to the following two conditions: (1) pressure sensors to transmit the electronic code in This device may not cause harmful interference, and (2) different manner, resulting in the failure of the this device must accept any interference received,...
Page 243 STARTING AND DRIVING Replacing tires and wheels D Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. As you might have difficulty in locating a flat or deflated tire, an tire pressure warning system should be installed D Consult the dealer or an experienced radio / TV on the tires of this vehicle.
Page 244 “MAIN”. Have a new tires set with new tire pressure sensors registered at “2nd” by Lexus dealer. ID codes should be registered by Lexus dealer. Once registered, change the setting position each time you purchase tires and wheels. Re-registration is not required.
Page 245 STARTING AND DRIVING CAUTION When the tires whose ID code is registered at “MAIN” are used, the system does not work properly with the selector switch set at “2nd”. If the tires whose ID code is registered at “2nd” are stored nearby, the system will detect their tire inflation pressure (and vice versa).
Page 246 SECTION – STARTING AND DRIVING Driving tips Break-in period ..............Operation in foreign countries .
Page 247: Driving Tips
Drive gently and avoid high speeds. D Always slow down in gusty crosswinds. This will allow you You need not follow a break-in schedule with your new Lexus. But following a few simple tips for the first 1600 km (1000 miles) much better control.
Page 248: Winter Driving Tips
DRIVING TIPS D Do not continue normal driving when the brakes are CAUTION wet. If they are wet, your vehicle will require a longer D Before driving off, make sure the parking brake is stopping distance, and it may pull to one side when the brakes are applied.
Page 249 Page 356 tells you how to visually inspect the battery. wheels. Do not use the parking brake, or snow or water Your Lexus dealer and most service stations will be pleased to accumulated in and around the parking brake mechanism may check the battery charge level.
Page 250: Dinghy Towing
TRAILER TOWING 32sa01a 32sa02 Your vehicle is not designed to be dinghy towed (with four Lexus does not recommend towing a trailer with your wheels on the ground) behind a motorhome. vehicle. It is not designed for trailer towing. NOTICE Do not tow your vehicle with four wheels on the ground.
Page 251: How To Save Fuel And Make Your Vehicle Last Longer
DRIVING TIPS D Avoid unnecessary stopping and braking. Maintain a HOW TO SAVE FUEL AND MAKE steady pace. Try to time the traffic signals so you only need YOUR VEHICLE LAST LONGER to stop as little as possible or take advantage of through streets to avoid traffic lights.
Page 252: Vehicle Load Limits
DRIVING TIPS D Keep your vehicle tuned-up and in top shape. A dirty air VEHICLE LOAD LIMITS cleaner, improper valve clearance, dirty plugs, dirty oil and grease, brakes not adjusted, etc. all lower engine Vehicle load limits include total load capacity, seating performance and contribute to poor fuel economy.
Page 253: Cargo And Luggage
DRIVING TIPS Towing capacity CARGO AND LUGGAGE Lexus does not recommend towing a trailer with your Stowage precautions vehicle. Your vehicle is not designed for trailer towing. When stowing cargo and luggage in the vehicle, Cargo capacity observe the following:...
Page 254 DRIVING TIPS Capacity and distribution NOTICE Cargo capacity depends on the total weight of the Do not load the vehicle beyond the vehicle occupants. capacity weight tire loading (Cargo capacity) = (Total load capacity) – (Total weight information label. of occupants) Steps for determining correct load limit 1.
Page 255 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Lexus does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. 32SA05 "...
Page 256 DRIVING TIPS As shown in the above example, if the number of occupants increases, the cargo and luggage load equaling the combined weight of occupants who got on later must be reduced. In other words, if the increase in the number of occupants causes the excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you have to reduce the cargo and luggage on your vehicle.
Page 257 DRIVING TIPS...
Page 258 ....... . . Lexus link system ..............
Page 259: If Your Engine Stalls While Driving
If the engine will not start, see ”If your vehicle will not start”. work, your key may be broken. Have the key checked at your Lexus dealer. If none of your keys work, there may be a malfunction in the immobilizer system. Call your Lexus dealer.
Page 260 If you are unsure about how to follow this procedure, we strongly recommend that you seek help from your Lexus dealer, Roadside Assistance or Customer Service Assistance. (See ”Foreword”.)
Page 261 IN CASE OF AN EMERGENCY CAUTION D Batteries contain sulfuric acid which is poisonous and corrosive. Wear protective safety glasses when jump starting, and avoid spilling acid on your skin, clothing, or vehicle. D If you should accidentally get acid on yourself or in your eyes, remove any contaminated clothing and flush the affected area with water immediately.
Page 262 Connect the clamp at the other end of the positive (red) example, lights left on), you should have it checked at your cable to the positive (+) terminal of the booster battery. Lexus dealer. Connect a negative (black) cable clamp to the negative (-) terminal of the booster battery.
Page 263: If You Cannot Increase The Engine Speed
Move the vehicle to a safe place by means of creeping and call a Lexus dealer for When the engine overheats assistance: Pull safely off the road, stop the vehicle and turn on your 1.
Page 264: If You Have A Flat Tire (Vehicles With Run-Flat Tires)
31sa01b If the cooling fan is not operating or the coolant is not in the acceptable range, turn off the engine and call your Lexus dealer. If both conditions are O.K., after the engine coolant temperature has cooled to normal, continue driving your vehicle.
Page 265 Lexus dealer or authorized tire dealer as D Take due care not to go over a curb stone and soon as possible, observing the following...
Page 266: If You Have A Flat Tire (Vehicles With Standard Tires)
IN CASE OF AN EMERGENCY IF YOU HAVE A FLAT TIRE 4. Have everyone get out of the vehicle on the side away from traffic. (Vehicles with standard tires) 5. Read the following instructions thoroughly. CAUTION CAUTION If the low tire pressure warning light blinks and When jacking, be sure to observe the following to chimes sound,...
Page 267 Lexus dealer or authorized tire dealer. The tire pressure sensors will be affected by the The compact spare tire saves space in your luggage installation or removal of tires.
Page 268 CAUTION D The compact spare tire was designed especially INFORMATION for your Lexus. Do not use it on any other vehicle. As the spare tire is not equipped with the tire D Do not use more than one compact spare tire at pressure sensor, low inflation pressure of the the same time.
Page 269 IN CASE OF AN EMERGENCY Changing procedure 40sa28a 40sa27a " Joint When removing the jack, turn the joint by hand in " Wrench Jack handle Towing eyelet the ”contract” direction until the jack is free. Allen wrench Tool bag Jack Spare tire When storing, turn the joint by hand in the ”expand”...
Page 270 IN CASE OF AN EMERGENCY 40sa38b 40sa29 To remove the spare tire: 2. Block the wheel diagonally opposite the flat tire to keep the vehicle from rolling when it is jacked up. Remove the tire cover. When blocking the wheel, place a wheel block in front of Loosen the bolt and remove it.
Page 271 IN CASE OF AN EMERGENCY 40sa30a 40sa31 3. Loosen all the wheel nuts. 4. Position the jack at the jack points as shown. Always loosen the wheel nuts before raising the vehicle. Make sure the jack is positioned on a level and solid surface.
Page 272 IN CASE OF AN EMERGENCY 40sa32a 40sa33a 5. After making sure no one is in the vehicle, raise it 6. Remove the wheel nuts and remove the flat tire. high enough so that the spare tire can be installed. Lift the flat tire straight off and put it aside. Allow for the fact that you need more ground clearance when putting on the spare tire than when removing the flat tire.
Page 273 IN CASE OF AN EMERGENCY 40sa34a 40sa35 Before putting on the wheel, remove any corrosion on 7. Reinstall all the wheel nuts finger tight. the mounting surfaces with a wire brush or such. Align the holes in the wheel with the bolts. Then lift up Installation of wheels without good metal- to- metal the wheel and get at least the top bolt started through its contact at the mounting surface can cause wheel nuts to...
Page 274 IN CASE OF AN EMERGENCY CAUTION D When lowering the vehicle, make sure all portions of your body and all other persons 40sa36 around will not be injured as the vehicle is lowered to the ground. D Have the wheel nuts tightened with torque wrench to 103 N·m (10.5 kgf·m, 76 ft·lbf.), as soon as possible after changing wheels.
Page 275: If Your Vehicle Becomes Stuck
IN CASE OF AN EMERGENCY 9. After changing the wheel, check the air pressure IF YOUR VEHICLE BECOMES of the replaced tire. Stow all the tools, jack and flat STUCK tire securely. If your vehicle becomes stuck in snow, mud, sand, etc. Load the flat tire in the trunk with the retractable hardtop then you may attempt to rock the vehicle free by moving closed.
Page 276: If Your Vehicle Needs To Be Towed
If towing is necessary, we recommend you to have it done precautions to prevent damage to the transmission and by your Lexus dealer or a commercial tow truck service. other parts. In consultation with them, have your vehicle towed using D Do not depress the accelerator pedal while shifting either (a) or (b).
Page 277 IN CASE OF AN EMERGENCY D From rear (a) Towing with a wheel lift type truck D From front 40sa43 40sa42 Place the ignition switch in the ”ACC” position. Use a towing dolly under the rear wheels. NOTICE NOTICE D Do not tow with the key removed or in the ”LOCK” position, as the steering lock mechanism is not Never tow a vehicle with an automatic transmission strong enough to hold the front wheels straight.
Page 278 IN CASE OF AN EMERGENCY (b) Using a flat bed truck 40sa39 40sa44 If your Lexus is transported by a flat bed, it should be tied down at locations A and B as shown above. D Tie down points 40sa40a 40sa45 "...
Page 279 IN CASE OF AN EMERGENCY D Tie down angle (c) Towing with a sling type truck 40sa46 40sa47 If you use chains or wires to tie down your vehicle, the angles shaded black must be at 45_. NOTICE Do not tow with a sling type truck, either from the front or rear.
Page 280 If towing is necessary, we recommend you to have it done NOTICE by your Lexus dealer or a commercial tow truck service. If towing service is not available in an emergency, your Use only a cable or chain specifically intended for use vehicle may be temporarily towed by a cable or chain in towing vehicles.
Page 281: If The Retractable Hardtop Does Not Close
Lexus inspected at Lexus dealer as soon as possible. In other procedures, you may be injured by performing them with bare hands.
Page 282 IN CASE OF AN EMERGENCY Closing the retractable hardtop manually 40sa02 40sa01...
Page 283 IN CASE OF AN EMERGENCY (a) Unlocking the trunk lid Push the trunk lid opener switch to unlock the trunk lid. If the trunk lid opener does not operate properly, unlock the trunk lid in accordance with the following procedure. 40sa04 40sa03 "...
Page 284 IN CASE OF AN EMERGENCY (b) Opening the trunk lid (c) Setting up luggage links INFORMATION 2 people are required for this work. They should stand on each side of the rear of the vehicle and work in 40sa05a unison. 40sa06b Open the trunk lid fully.
Page 285 IN CASE OF AN EMERGENCY NOTICE Do not apply the force to the part other than green painting part to avoid the deformation of the panel. 40sa07b 40sa08a " 1 Loop of wire 2 Front of luggage link 2. While pulling out the loop of wire with one hand, put your other hand over the front side of the luggage link (where green painting is applied) and raise it gradually.
Page 286 IN CASE OF AN EMERGENCY (d) Raising the package tray 40sq03 40sa10 " 1 Cable 2 Joint 2. Disconnect the joints of the cables at both ends under " 1 Main board 2 Slide board 3 Side board the package tray using your hand. 1.
Page 287 IN CASE OF AN EMERGENCY 40sa10b 40sa11b " 1 Main board 2 Slide board 3 Side board 4. After raising it, push down the slide board as low as the main board. 3. Raise the package tray gradually until it stops. NOTICE Do not apply force directly to the side board as it moves in accordance with the main board movement.
Page 288 IN CASE OF AN EMERGENCY (e) Closing the roof panel partially NOTICE The use of shorter side of Allen wrench may damage the roof panel. 40sa12c 40sa53 1. Take out the Allen wrench located in the trunk. " 1 Roof stopper 2 Hook 3.
Page 289 IN CASE OF AN EMERGENCY 40sa52 40sa14b 4. Insert your hands at the lower part of the roof and lift the 5. After the roof is lifted up to a certain point, 2 people lift roof upward gradually. At this time, the person on the side it on the rear side of the vehicle in unison.
Page 290 IN CASE OF AN EMERGENCY (f) Folding down the package tray 40sa15 40sa16a 6. Stop lifting the roof panel when the rear window is perpendicular to the ground. " 1 Main board 2 Slide board With the slide board as low as the main board, fold down CAUTION the main board rearward.
Page 291 IN CASE OF AN EMERGENCY (g) Closing the roof panel fully 40sa18 40sa17 " 1 Drive gear shaft 2 Hook 2. Insert the wrench tip into the drive gear shaft and turn " 1 Service hole cover 2 Drive gear shaft the wrench about one turn counterclockwise as viewed 1.
Page 292 IN CASE OF AN EMERGENCY 40sa19b 40sa20b " 1 Guide hole 3. Gradually close the roof panel, then the rear window. 2 Guide pin 4. Make sure the guide pins at the top of the roof panel are in the guide holes on the top of the windshield and push CAUTION down in the vicinity of the line separating the roof panel Take care not to catch your hands when closing the roof...
Page 293 IN CASE OF AN EMERGENCY (h) Closing the front of trunk lid INFORMATION D 2 people are required for this work. They should 40sa21a stand on each side of the rear of the vehicle and work in unison. D Strength is required to lower the luggage links. Wear gloves or apply a piece of rag where your hands are put and exert the pressure gradually.
Page 294 4. Hold down the same switch on the “CLOSE” side once within 10 seconds after step 3. The quarter windows will close. Close the trunk lid as you do usually. Be sure to have the system checked by your Lexus dealer as INFORMATION soon as possible.
Page 295: If You Cannot Shift Automatic Transmission Selector Lever
IN CASE OF AN EMERGENCY IF YOU CANNOT SHIFT D Never leave small children alone in the vehicle, espe- cially with the ignition key still inserted. They could AUTOMATIC TRANSMISSION use the retractable hardtop switch and get trapped in SELECTOR LEVER the windows.
Page 296: Lexus Link System
For your safety, keep the brake pedal depressed. The Lexus Link System is an in-vehicle communications service that provides you with enhanced safety, security Be sure to have the system checked by your Lexus dealer as and convenience. With an active subscription you can soon as possible.
Page 297 ANSI Standard EXPOSURE TO RADIO FREQUENCY SIGNALS (C95.1). The Lexus Link System to be installed in your vehicle a low The design of the Lexus Link System complies with the FCC power radio transmitter and receiver. When the ignition is guidelines in addition to those standards.
Page 298 To learn more about your subscription status or how to renew or extend your subscription, please push the “SERVICES” button and speak to the Lexus Link Advisor, or you may dial toll free 1- 800- 25 Lexus (Toll- Free) (1- 800- 255- 3987) and select the option for Lexus Link.
Page 299 “SERVICES” button voice prompt messages are disabled and you desire to to speak to a Lexus Link Advisor, or you may dial toll free have them re-activated, contact your Lexus dealer. 1-800-25 Lexus (Toll-Free) (1-800-255-3987) and select the option for Lexus Link.
Page 300 Lexus Link Call Center. The Advisor will attempt to contact you to determine whether the alarm is valid. If you report to the Lexus Link Call Center that your vehicle has been stolen, the Advisor will locate, track and provide location information to the appropriate law enforcement authority.
Page 301 This emergency call should only be made in life-threatening situations. If your vehicle is stolen, call the Lexus Link Call Center at 1- 800- 25- LEXUS (Toll- Free) (1- 800- 255- 3987). The Center will locate, track and provide location information to the appropriate police authority.
Page 302 For details about various services that are available, contact your Lexus dealer, or push the “SERVICES” button and speak to the Lexus Link Advisor, or you may dial toll free 1-800-25 Lexus (Toll-Free) (1-800-255-3987) and select the option for Lexus Link.
Page 303 The Lexus Link System will allow your vehicle to be locked If you hear this message, take your vehicle to your Lexus and unlocked remotely. dealer. If you find that your vehicle has not been locked, call the Lexus Lexus Link services may not be available if: Link Call...
Page 304 When you change the volume, one chime sounds. During a service call, you can record a conversation with the Lexus Link Call Center Advisor. This function is very convenient for drivers so they do not have to take notes while driving.
Page 305 IN CASE OF AN EMERGENCY Audible voice prompts The following table shows the voice responses from the Lexus Link System. Voice phrase: Explanation about Lexus Link System This is the Lexus Link system. In an emergency, press the emergency If you accidentally set off the alarm,...
Page 306 IN CASE OF AN EMERGENCY Voice phrase Description Voice phrase Description The Lexus Link System is The system is operational The Lexus Link System is Message notifies vehicle active. with the ignition on. not active. To activate your occupants that the Lexus Link System, press subscription has expired.
Page 307 D Do not contact with the antenna, this may affect quality of transceiver’s operation and may cause the unit to operate at a higher power level than needed. D If you forget reattaching the Lexus Link transceiver 40sa59a antenna, the Lexus Link System may not function properly.
Page 308: If You Lose Your Keys Or Lock Yourself Out
LOCK YOURSELF OUT You must provide the Lexus Link operator with your You can purchase a new key at your Lexus dealer if you Lexus Link PIN (Personal Identification Number ) or can give them the key number and master key.
Page 309 IN CASE OF AN EMERGENCY...
Page 310 SECTION MAINTENANCE Maintenance Maintenance requirements ............General maintenance .
Page 311 Manual Supplement / Scheduled Maintenance”. It is the owner’s responsibility to make sure the specified It is recommended that only genuine Lexus parts be used maintenance, including general maintenance services, is for maintenance.
Page 312 Engine compartment warranty, your Lexus dealer will promptly take care of it. Again, Items listed below should be checked from time to time, be sure to keep a copy of the repair order for any service e.g.
Page 313 MAINTENANCE Brake fluid level Steering wheel Make sure the brake fluid level is correct. See page 327 for Check that it has the specified free play. Be alert for changes additional information. in steering condition, such as hard steering, excessive free play or strange noise.
Page 314 MAINTENANCE Automatic transmission ”Park” mechanism Tire surface On a safe incline, check that your vehicle is held securely with Check the tires carefully for cuts, damage or excessive the selector lever in ”P” position and all brakes released. wear. See page 343 for additional information. Tire rotation Vehicle exterior Rotate the tires according to the maintenance schedule.
Page 315 MAINTENANCE DOES YOUR VEHICLE NEED Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Lexus REPAIRING? dealer as soon as possible. It probably needs adjustment or Be on the alert for changes in performance and sounds, and repair.
Page 316 OBD system will not be cleared unless about 40 trips or more are taken. If your vehicle does not pass the I/M test and the malfunction indicator lamp does not come on, contact your Lexus dealer to prepare the vehicle for re-testing.
Page 317 MAINTENANCE...
Page 318 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Introduction Vehicle identification ..............Theft prevention labels .
Page 319 This number is on the left top of the instrument panel and can be seen through the windshield from outside. This is the primary identification number for your Lexus. It is 61sa03a used in registering the ownership of your vehicle.
Page 320 INTRODUCTION THEFT PREVENTION LABELS 17E002 Your new vehicle carries theft prevention labels which are approximately 56 mm (2.20 in.) by 16 mm (0.63 in.). The purpose of these labels is to reduce the incidence of vehicle thefts by facilitating the tracing and recovery of parts from stolen vehicles.
Page 321 INTRODUCTION ENGINE COMPARTMENT OVERVIEW Battery Fuse box Engine oil filler cap Engine oil level dipstick Brake fluid reservoir Washer fluid tank 61st02 Radiator Condenser Engine coolant reservoir Electric cooling fans Power steering fluid reservoir...
Page 322 Read the separate other solid supports. Lexus Warranty statement for details and suggestions. D Be sure the ignition is off if you work near the electric This Section gives instructions only for those items that are cooling fan or radiator grille.
Page 323 INTRODUCTION POSITIONING THE JACK NOTICE D Remember that battery and ignition cables carry high currents or voltages. Be careful of accidentally causing a short circuit. D Add only ”Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, 61sa07 non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology to fill the...
Page 324 Here is a list of parts and tools you will need to perform When jacking, be sure to observe the following to do-it-yourself maintenance. Remember all Lexus parts are reduce the possibility of personal injury: designed in metric sizes, so your tools must be metric.
Page 325 Parts (if level is low): Parts (if replacement is necessary): D FMVSS No. 116 DOT 3 or SAE J1703 brake fluid D Genuine Lexus fuse or equivalent with same amperage rating as original Tools: D Funnel (only for adding fluid)
Page 326 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Engine Specifications ..............Fuel .
Page 327: Engine
ENGINE SPECIFICATIONS – GENERAL Model 3UZ-FE Type 8 cylinder V type, 4 cycle, gasoline Bore and stroke 91.0 X 82.5 mm (3.58 X 3.25 in.) Displacement 4293 cm (262.0 cu.in.) Valve clearance (engine cold) Intake 0.15 - 0.25 mm (0.006 - 0.010 in.) Exhaust 0.25 - 0.35 mm (0.010 - 0.014 in.) Drive belt tension...
Page 328 Temperature range anticipated before next oil change NOTE: “Toyota Genuine Motor Oil” is filled in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the above grade and viscosity. Please contact your Lexus dealer for further details.
Page 329 NOTE: “Toyota Super Long Life Coolant” is filled in your Lexus vehicle at factory fill. In order to avoid technical problems, only use ”Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology.
Page 330: Fuel
Your vehicle must use only unleaded gasoline. cannot be obtained, you may temporarily use unleaded To help prevent gas station mixups, your Lexus has a smaller gasoline with an Octane Rating as low as 87 (Research fuel tank opening. The special nozzle on pumps with unleaded Octane Number 91).
Page 331 10% ethanol or 15% D If drivability problems are encountered (poor hot MTBE. If you use gasohol in your Lexus, be sure that it has starting, vaporizing, engine knock, etc.), discontinue an octane rating no lower than 87.
Page 332: Fuel Pump Shut Off System
ENGINE FUEL PUMP SHUT OFF SYSTEM D Take care not to spill gasohol during refueling. Gasohol may cause paint damage. The fuel pump shut off system stops supplying fuel to the engine to minimize the risk of fuel leakage when the engine Fuel tank capacity stalls or an airbag inflates upon collision.
Page 333: Facts About Engine Oil Consumption
ENGINE FACTS ABOUT ENGINE OIL More oil is consumed by high- speed driving and frequent acceleration and deceleration. CONSUMPTION A new engine consumes more oil, since its pistons, piston rings and cylinder walls have not become conditioned. Functions of engine oil Oil consumption: Max.
Page 334: Used Engine Oil
CAUTION that oil function will not be impaired. Therefore, it is essential that the oil level be checked regularly. Lexus recommends that D Used engine oil contains potentially harmful the oil level be checked every time you refuel the vehicle.
Page 335: Checking The Engine Oil Level
ENGINE CHECKING THE ENGINE OIL LEVEL 61sa05 61sa04a 1 Add oil 2 O.K. 3 Too full 4. Pull the dipstick out and look at the oil level while holding a With the engine at operating temperature and turned off, rag under the end. If it is between the full line ( 5 ) and the check the oil level on the dipstick.
Page 336 ENGINE NOTICE D Be careful not to spill the engine oil on the vehicle components. 61sa06a D Avoid overfilling, or the engine could be damaged. D Check the oil level on the dipstick once again after adding the oil. If the oil level is below or only slightly above the low line, add engine oil of the same type as already in the engine.
Page 337 ENGINE Engine oil selection Oil identification marks “Toyota Genuine Motor Oil” is filled in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: API grade SL “Energy- Conserving” or ILSAC multigrade engine oil.
Page 338: Checking The Engine Coolant Level
CHECKING THE ENGINE COOLANT “Toyota Genuine Motor Oil” is available, which has been LEVEL specifically tested and approved for all Lexus engines. Please contact your Lexus dealer for further details about “Toyota Genuine Motor Oil”. 62sa04a " 1 Reservoir cap...
Page 339 “Toyota Super Long Life Coolant” is formulated with long- life hybrid organic acid technology and has been If you can find no leak, have your Lexus dealer test the cap specifically designed to avoid engine cooling system pressure and check for leaks in the cooling system.
Page 340: Checking The Radiator And Condenser
CHECKING THE RADIATOR AND SPARK PLUGS CONDENSER If either of the above parts are extremely dirty or you are not sure of their condition, take your vehicle to a Lexus dealer. 62r031c CAUTION To prevent burning yourself, be careful not to touch the radiator or condenser when the engine is hot.
Page 341 ENGINE...
Page 342 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Chassis Specifications ..............Checking brake fluid .
Page 343: Specifications
If you are unable to locate an equivalent to “Toyota Genuine Differential Synthetic gear oil API GL-5 SAE 75W-90”, contact your Lexus dealer for further details or another duly qualified and equipped professional.
Page 344 CHASSIS – AUTOMATIC TRANSMISSION Fluid capacity Drain and refill 1.8 L (1.9 qt., 1.6 lmp.qt.) Fluid type Toyota Genuine ATF Type T-IV* *Change automatic transmission fluid only as necessary. NOTICE Generally, it is necessary to change automatic transmission fluid only if your vehicle is driven under one of the Special Using automatic transmission fluid other than Toyota Operating Conditions listed in your “Owner ’s Manual Genuine ATF Type T-IV may cause deterioration in shift...
Page 345 CHASSIS – TIRES AND WHEELS Standard and run-flat tires: Tire size 245/40ZR18 245/40ZR18 93Y Tire inflation pressure Recommended cold tire inflation pressure Front 230 kPa (2.3 kgf/cm or bar, 33 psi) Rear 230 kPa (2.3 kgf/cm or bar, 33 psi) For sustained high speeds above 180 km/h (112 mph), in countries where such speeds are permitted by law, add 80 kPa (0.8 kgf/cm...
Page 346: Checking Brake Fluid
CHASSIS CHECKING BRAKE FLUID If you do not follow the procedure above, the reservoir may overflow. Use only newly opened brake fluid. Once opened, brake fluid absorbs moisture from the air, and excess moisture can cause a dangerous loss of braking efficiency. 63sa06 CAUTION Take care when filling the reservoir because brake fluid...
Page 347: Checking Power Steering Fluid
CHASSIS CHECKING POWER STEERING FLUID 63sa05 63sa04 " 1 If hot O.K. 2 If hot add 3 If cold O.K. 4 If cold add Clean all dirt off the reservoir and look at the fluid level. If the fluid is cold, the level should be in the ”COLD” range. Similarly, Check the fluid level on the dipstick.
Page 348: Checking Tire Inflation Pressure
CHASSIS CHECKING TIRE INFLATION CAUTION PRESSURE The reservoir may be hot so be careful not to burn yourself. NOTICE D Avoid overfilling, or the power steering could be damaged. D When adding the power steering fluid, avoid spilling it. The generator under the power steering reservoir could be damaged if fluid is spilled on it.
Page 349 CHASSIS You should check the tire inflation pressure every two weeks, or at least once a month. And don’t forget the spare, if so equipped. The inflation pressure for the spare tire should be 420 kPa (4.3 kgf/cm , 4.2 bar, 60 psi).
Page 350 CHASSIS D Never exceed the vehicle capacity weight. The Inspection and adjustment procedure passengers and luggage weight should be located so that the vehicle is balanced. CAUTION 63SA09 The inflation pressure for the compact spare tire must be 420 kPa (4.3 kgf/cm , 4.2 bar, 60 psi).
Page 351 CHASSIS If the gauge and the air pump are not available, have CAUTION your vehicle checked by your Lexus dealer. Keep your tires properly inflated. Otherwise, the following conditions may occur and cause an CAUTION accident resulting in death or serious injuries.
Page 352: Tire Information
CHASSIS TIRE INFORMATION Tire symbols 63SA10b " The illustration indicates typical tire symbols.
Page 353 CHASSIS Tire size: For details, see “Tire size” on page “TUBELESS” or “TUBE TYPE”: A tubeless tire 335. does not have a tube inside the tire and air is directly filled in the tire. A tube type tire has a DOT and Tire Identification Number (TIN): For tube inside the tire and the tube maintains the air details, see “DOT and Tire Identification Number...
Page 354 CHASSIS DOT and Tire Identification Number (TIN) Tire size 63SA11a 63sa12a " The illustration indicates typical DOT and Tire " The illustration indicates typical tire size. Identification Number (TIN) Section width (in millimeters) ”DOT” symbol Aspect ratio (tire height to section width) Tire Identification Number (TIN) Speed category (alphabet with one letter) Tire manufacturer’s identification mark...
Page 355 CHASSIS Name of each section of tire 63sa13b 63sa14 " Section width Tire height " Bead Wheel diameter Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer...
Page 356 Warning: The traction grade assigned to this tire is information on uniform tire quality grading. based on braking (straight ahead) traction tests and Your Lexus dealer will help answer any questions does not include cornering (turning) traction. you may have as you read this information.
Page 357 CHASSIS Tire related terms Cold tire inflation Tire pressure when the vehicle has been parked at least 3 hours or more, or it has pressure not been driven more than 1.5 km or 1 mile under that condition. Maximum inflation The maximum cold inflation pressure to which a tire may be inflated and shown on pressure the sidewall of the tire...
Page 358 CHASSIS 68 kg (150 lb.) times the number of occupants specified in the second column of Normal occupant weight Table 1 that follows. The combined weight of those installed regular production options weighing over 2.3 kg (5 lb.) in excess of those standard items which they replace, not previously Production options weight considered in curb weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim...
Page 359 CHASSIS Rim type designation The industry of manufacturer’s designation for a rim by style or code Rim width Nominal distance between rim flanges Vehicle maximum load on The load on an individual tire that is determined by distributing to each axle its the tire share of the maximum loaded vehicle weight and dividing by two The load on an individual tire that is determined by distributing to each axle its...
Page 360: Run-Flat Tires
After such usage, the tire must be the repaired tire. A spare tire is not provided on the replaced. If you are not sure, consult your Lexus dealer. vehicle with run-flat tires. If you have a flat tire, decrease the speed and drive at lower speed to reduce the extent to which the tire is damaged.
Page 361: Types Of Tires
CHASSIS Tire pressure warning system 2. All season tires The tire pressure warning system is equipped to warn All season tires are designed to provide better traction you of the low tire inflation pressure. For details, see in snow and to be adequate for driving in most winter “Tire pressure warning system”...
Page 362: Rotating Tires
CHECKING AND REPLACING TIRES 63sa07a When to replace your tires To equalize tire wear and help extend tire life, Lexus 63sa02a recommends that you rotate your tires according to the maintenance schedule. (For scheduled maintenance information, please refer to the “Owner’s Manual Supplement”...
Page 363 If a tire often goes flat or cannot be properly repaired due to the size or location of a cut or other damage, it should be replaced. If you are not sure, consult with your Lexus dealer.
Page 364 Gross Axle Weight Ratings (GAWR), see the Lexus dealer. If you change from run-flat tires Certification Label. For details about the Certification to standard tires, a spare tire should also be Label and sidewall of the tire, see pages 300 and 333.
Page 365: Installing Snow Tires And Chains
CHASSIS INSTALLING SNOW TIRES AND CAUTION CHAINS Observe the following instructions. Otherwise, an accident may occur resulting in death or serious When to use snow tires or chains injuries. Snow tires or chains are recommended when driving on D Do not mix radial, bias belted, or bias-ply tires snow or ice.
Page 366 D When the snow tires must be repaired or replaced, Installing snow tires on the rear wheels only can lead to an have them repaired or replaced by Lexus dealer or excessive difference in road grip capability between the front authorized tire dealer.
Page 367: Replacing Wheels
Slow down before entering curves to avoid D Have the tires, wheels or sensors replaced and ID losing control of the vehicle. Otherwise an accident may occur. codes registered by Lexus dealer. If you need sensors, purchase from Lexus dealer. REPLACING WHEELS...
Page 368: Aluminum Wheel Precautions
D Use only the Lexus wheel nuts and wrench designed for chain clearance to the body and chassis. your aluminum wheels. Replacement with used wheels is not recommended as they...
Page 369: Suspension And Chassis
CHASSIS SUSPENSION AND CHASSIS CAUTION Do not modify the suspension/chassis with lift kits, spacers, springs, etc. It can cause dangerous handling characteristics, resulting in loss of control.
Page 370 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Electrical components Specifications ..............Checking battery condition .
Page 371: Electrical Components
ELECTRICAL COMPONENTS SPECIFICATIONS - FUSES -LOCA TION OF FUSES 64sa06a 64sa02a " Driver’s side kick panel 64sa07a " Passenger’s side kick panel " 1 Engine compartment 2 Passenger’s side kick panel 3 Driver’s side kick panel 4 Trunk...
Page 372 ELECTRICAL COMPONENTS 64sa08 " Trunk " Engine compartment 64sa09b...
Page 373 ELECTRICAL COMPONENTS FUSE AMPERE CIRCUIT FUSE AMPERE CIRCUIT TI & TE Tilt and telescopic steering Air conditioning system, Audio Power door lock, Steering lock, system, Glove box light, MPX-B1 Engine immobilizer, Power seat PANEL Trip-information display, system, Retractable hardtop Cigarette lighter, Electronic Tilt and telescopic steering, throttle control system Headlight switch, Windshield...
Page 374 ELECTRICAL COMPONENTS FUSE AMPERE CIRCUIT FUSE AMPERE CIRCUIT Air conditioning system Power windows, Power door lock system, Power rear view P P/SEAT Power seat system D-DOOR mirror control system, Outside rear view mirror defogger, Door TV, Navigation system courtesy lights DEFOG Rear window defogger All components in “DOME”,...
Page 375: Checking Battery Condition
ELECTRICAL COMPONENTS CHECKING BATTERY CONDITION FUSE AMPERE CIRCUIT All components in “DEFOG”, Precautions “ROOF RH”, “ROOF LH”, “LGG RR J/B RH”, “LGG LH”, “P-TRAY”, “LCE LP”, and “FUEL OPN” fuses CAUTION H-LP CLN Headlight cleaner BATTERY PRECAUTIONS Air conditioning system The battery produces flammable and explosive FAN NO.2 Air conditioning system...
Page 376 ELECTRICAL COMPONENTS Checking battery exterior D If electrolyte gets on your skin, thoroughly wash the contact area. If you feel a pain or burn, get medical attention immediately. D If electrolyte gets on your clothes, there is a possibility of its soaking through to your skin, so immediately take off the exposed clothing and follow 64sa17a the procedure above, if necessary.
Page 377: Battery Recharging Precautions
ELECTRICAL COMPONENTS BATTERY RECHARGING NOTICE PRECAUTIONS D Make sure the engine and all accessories are turned During recharging, the battery is producing hydrogen off before performing maintenance. gas. D When checking the battery, remove the ground cable first and reinstall it last. Therefore, before recharging: D Be careful not to cause a short circuit with tools.
Page 378: Checking And Replacing The Blade Type Fuses
ELECTRICAL COMPONENTS CHECKING AND REPLACING THE BLADE TYPE FUSES 64sa13 64sa11 " Driver’s side kick panel " Engine compartment 1 Spare fuses 2 Pull-out tool 64sa12 64sa10 " Passenger’s side kick panel " Engine compartment...
Page 379 ELECTRICAL COMPONENTS 64sa16 64g008a " Trunk " Good " Blown a. Look carefully at the fuse. If the thin wire is broken, the fuse 1. Turn the ignition switch off and open the fuse box lid. has blown. If you are not sure or if it is too dark to see, try Determine which fuse may be causing the problem.
Page 380: Checking The Cartridge Type Fuses
CHECKING THE CARTRIDGE TYPE in your vehicle for emergencies. FUSES If the new fuse immediately blows out, there is a problem with the electrical system. Have your Lexus dealer correct it as soon as possible. CAUTION 64sa19a Never use a fuse with a higher amperage rating, or any other object, in place of a fuse.
Page 381 CAUTION Always use a genuine Lexus fuse or equivalent for replacement. Never install an ordinary wire - even for a temporary fix. This may cause extensive damage and possibly a fire.
Page 382: Adding Washer Fluid
This product is available at 1. Make sure the body around the headlight is not deformed. your Lexus dealer and most auto parts stores. Follow the manufacturer’s directions for how much to mix with water. 2. Park the vehicle on a level spot.
Page 383 ELECTRICAL COMPONENTS Adjusting the vertical aiming 64sa22b 64sa24d 1. Turn the Phillips- head screwdriver five turns or multiple-of-5 turns in either direction for turning the vertical " 1 For vertical movement adjusting bolt 1 movement adjusting bolt 1 (inside screw). At this time, keep the turning direction and number of turns in mind.
Page 384 ELECTRICAL COMPONENTS INFORMATION D If 3 turns of the Phillips-head screwdriver are appropriate for the vertical movement adjusting bolt 1 (inside screw) at step 1, turn the Phillips-head 64sa23a screwdriver three fifth turns in the same direction as step 1 for the vertical movement adjusting bolt 2 (outside screw).
Page 385: Replacing Light Bulbs
If it is necessary to replace a bulb, take your vehicle caused by the temperature difference between the outside and to your Lexus dealer as soon as possible. Use bulbs with the inside of the lens, just like the windshield fogged up in the rain.
Page 386 ELECTRICAL COMPONENTS LIGHT LOCATION 64sa04c 64sa03 Light Bulbs Bulb No. Type Rear side marker light Light Bulbs Bulb No. Type Rear turn signal light 7440 Headlight (High beam) 9005 Tail/stop light 7443 5/21 Front turn signal light Back-up lights 7440 Parking light License plate lights Front side marker light...
Page 387 ELECTRICAL COMPONENTS 64sa05a Light Bulbs Bulb No. Type Front interior/personal light Vanity light Glove box light Foot light Door courtesy light HB3 halogen bulbs D2S discharge bulbs HB4 halogen bulbs Wedge base bulbs Double end bulbs Single end bulbs H3 halogen bulbs...
Page 388 ELECTRICAL COMPONENTS...
Page 389 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Body Specifications ..............Protecting your vehicle from corrosion .
Page 390: Specifications
BODY SPECIFICATIONS – DIMENSIONS AND WEIGHT Overall length 4515 mm (177.8 in.) Overall width 1825 mm (71.9 in.) Overall height 1350 mm (53.1 in.)* Wheelbase 2620 mm (103.1 in.) Tread – Front 1550 mm (61.0 in.) – Rear 1535 mm (60.4 in.) Vehicle capacity weight (occupants + luggage) 295 kg (645 lb.) *: Unladen vehicle...
Page 391: Protecting Your Vehicle From Corrosion
FROM CORROSION Keep your vehicle clean by regular washing. In addition, Proper care of your Lexus can help ensure long- term observe the following points. corrosion prevention. D If you drive on salted roads in the winter or if you live near...
Page 392: Washing And Waxing
WASHING AND WAXING accumulate under the floor mats and could cause corrosion. Occasionally check under the mats to make sure the area is Washing your Lexus dry. Be particularly careful when transporting chemicals, cleansers, fertilizers, salt, etc. These should be transported in Keep your vehicle clean by regular washing.
Page 393 BODY Hand-washing your Lexus Plastic wheel ornaments: The plastic wheel ornaments are damaged easily by organic substances. If any organic Work in the shade and wait until the vehicle body is not hot substance splashes an ornament, be sure to wash it off with to the touch.
Page 394: Cleaning The Interior
Leather Interior original beauty of your Lexus’ finish. The selected leather is used in your Lexus. Due to Apply wax once a month or if the vehicle surface does not repel characteristics of leather products, some parts of leather may water well.
Page 395 BODY 3. Wipe off the surface of the leather with a dry soft cloth. Allow D Improper cleaning of the leather upholstery could the leather to dry in a ventilated shaded area. Excess of wet result in discoloration or staining. may cause the hardening or shrinking of the leather.
Page 396 If the display becomes dirty, do not use chemicals and detergent. Wipe it off with a dry cloth. If you have any questions about the cleaning of your Lexus, your local Lexus dealer will be pleased to answer them.
Page 397 SECTION REPORTING SAFETY DEFECTS FOR U.S. OWNERS Reporting safety defects for U.S. owners Reporting safety defects for U.S. owners ..........
Page 398 Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-25-LEXUS). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 399 GAS STATION INFORMATION D Fuel selection: D Engine coolant: Select premium unleaded gasoline with an Octane Rating Capacity: 9.9 L (10.5 qt., 8.7 lmp. qt.) of 91 (Research Octane Number 96) or higher for optimum Coolant type - ”Toyota Super Long Life Coolant” or similar engine performance.
