Abilize ranger Instruction Booklet page 16

4. Setup Mode (Unit Change) - Press
'km/h' / 'MPH' is flashing, press
The user could quit the setup mode with the following conditions.
(1) Leave or
(2) Press any button of Parking light, Horn, Indicator or Headlight, the definitive settings will be
stored and return to normal speedometer mode.
Odometer:
1. Operation Feature - Use optical coupler to detect the signal and transfer to related distances.
2. Unit Switch - When speedometer was set as 'km/h', the odometer displays as kilometer.
'mph', the odometer displays as mile. '/h', means the odometer is displaying as travel hours.
3. ODO Mode -
Press 'Mode' button and switch to ODO mode.
Display range : 0~99999
When the total distance goes
to 99999km or 62149mile
(99999÷1.609mile), the digits
will be reset to zero "0".
TRIP Mode:
1. Operation Feature - Press 'Mode' button
and switch to 'TRIP' mode. Display range:
0.0~999.9 When the distance goes to
999.9, the counter will stop.
2. Reset Mode (Rest TRIP to Zero) - Press
While 'TRIP' is flashing , press 'Mode' for 3 seconds to reset to zero '0.0'.
3. Quit Setup Mode - The user could quit the setup mode with the following conditions.
(1) Leave or
(2) Press any button of Parking light, Horn, Indicator or Headlight, the definitive settings will be
stored and return to normal TRIP mode.
Notice to Routine Maintenance for certain mileage
1. Display I for Routine Maintenance - The initial mileage of routine maintenance is 5000km
Display : When it reaches the mileage for routine maintenance, ODO symbol will start to flash
for 1 minute.
Time to display :
During flashing, the mobility vehicle
could be driven normally and the control
panel could be operated without any delay.
16
+
or
buttons alone for 15 seconds.
buttons alone for 15 seconds.
together for 3 seconds to enter setup mode. While
to switch to 'MPH' / 'km/h'.
+ together for 3 seconds to enter setup mode.
