- Page 1 OM-01098-04 May 26, 1981 Rev. C 06‐24‐2019 INSTALLATION, OPERATION, AND MAINTENANCE MANUAL WITH PARTS LIST 0 SERIES PUMP MODEL 02C3-X2 3P GORMAN‐RUPP PUMPS www.grpumps.com 1981 Gorman‐Rupp Pumps Printed in U.S.A.
- Page 2 Register your new Gorman‐Rupp pump online at www.grpumps.com/register. Valid serial number and e‐mail address required. RECORD YOUR PUMP MODEL AND SERIAL NUMBER Please record your pump model and serial number in the spaces provided below. Your Gorman‐Rupp distributor needs this information when you require parts or service. Pump Model: Serial Number:...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........PAGE I - 1 SAFETY - SECTION A . - Page 4 TABLE OF CONTENTS (continued) Pump Model ............PAGE E - 3 PUMP AND SEAL DISASSEMBLY AND REASSEMBLY .
-
Page 5: Introduction
0 SERIES OM-01098 INTRODUCTION Thank You for purchasing a Gorman‐Rupp pump. dures not addressed in this manual are performed Read this manual carefully to learn how to safely only after establishing that neither personal safety nor pump integrity are compromised by such prac install and operate your pump. -
Page 6: Safety - Section A
0 SERIES OM-01098 SAFETY - SECTION A This information applies to 0 Series electric motor driven pumps. Refer to the manual accompanying the motor before attempting to begin operation. This pump is designed to handle petro leum products or other industrial liq This manual will alert personnel to uids that do not contain large entrained known procedures which require spe... - Page 7 OM-01098 0 SERIES the applicable local code, the National or local code shall take precedence. Overheated pumps can cause severe burns and injuries. If overheating of the pump occurs: Because this pump is designed to han 1. Stop the pump immediately. dle volatile and/or flammable liquids, 2.
-
Page 8: Installation - Section B
See Figure 1 for the approximate physical dimen configuration, and priming must be tailored to the sions of this pump. OUTLINE DRAWING Figure 1. Pump Models 02C3-X2 3P INSTALLATION PAGE B - 1... -
Page 9: Preinstallation Inspection
OM-01098 0 SERIES PREINSTALLATION INSPECTION The pump assembly was inspected and tested be The electrical power used to operate fore shipment from the factory. Before installation, inspect the pump for damage which may have oc this pump is high enough to cause inju curred during shipment. -
Page 10: Materials
0 SERIES OM-01098 Materials the source of the liquid being pumped; if the line slopes down to the pump at any point along the suction run, air pockets will be created. Either pipe or hose maybe used for suction and discharge lines;... -
Page 11: Suction Line Positioning
OM-01098 0 SERIES If there is a liquid flow from an open pipe into the tance equal to at least 3 times the diameter of the sump, the flow should be kept away from the suc suction pipe. tion inlet because the inflow will carry air down into the sump, and air entering the suction line will re... -
Page 12: Bypass Lines
Refer to the following motor data before making electrical connections. MODEL VOLTAGE PHASE F.L. AMPS 02C3-X2 3P 230/460 3450 5.8/2.9 GROUNDING tight electrical connection with the rod and the pump. Because this pump is used to handle volatile or... -
Page 13: Operation - Section C
OM-01098 0 SERIES OPERATION - SECTION C Review all SAFETY information in Section A. Add liquid to the pump casing when: 1. The pump is being put into service for the Follow the instructions on all tags, labels and first time. decals attached to the pump. -
Page 14: Operation
OM-01098 0 SERIES Leakage OPERATION No leakage should be visible at pump mating sur faces, or at pump connections or fittings. Keep all Lines With a Bypass line connections and fittings tight to maintain maxi mum pump efficiency. Since this pump does not have a suction check valve, the discharge end of the bypass line must be Liquid Temperature And Overheating submerged in order to maintain suction. -
Page 15: Pump Vacuum Check
OM-01098 0 SERIES equipment. If backflushing is absolutely neces sary, liquid pressure must be limited to 50% of the maximum permissible operating pressure shown on the pump performance curve. Do not operate the pump against a Pump Vacuum Check closed discharge throttling valve for long periods of time. -
Page 16: Troubleshooting - Section D
0 SERIES OM-01098 TROUBLESHOOTING - SECTION D Review all SAFETY information in Section A. Before attempting to open or service the pump: 1. Familiarize yourself with this manual. 2. Disconnect the incoming power to the motor and lock it out to ensure that the pump will remain inopera... - Page 17 OM-01098 0 SERIES TROUBLE POSSIBLE CAUSE PROBABLE REMEDY PUMP STOPS OR Strainer clogged. Check strainer and clean if neces FAILS TO DELIVER sary. RATED FLOW OR Suction intake not submerged at Check installation and correct sub PRESSURE (cont.) proper level or sump too small. mergence as needed.
-
Page 18: Preventive Maintenance
0 SERIES OM-01098 equipped) between regularly scheduled inspec PREVENTIVE MAINTENANCE tions can indicate problems that can be corrected Since pump applications are seldom identical, and before system damage or catastrophic failure oc pump wear is directly affected by such things as curs. -
Page 19: Pump Maintenance And Repair - Section E
PUMP MAINTENANCE AND REPAIR - SECTION E MAINTENANCE AND REPAIR OF THE WEARING PARTS OF THE PUMP WILL MAINTAIN PEAK OPERATING PERFORMANCE. STANDARD PERFORMANCE FOR PUMP MODELS 02C3-X2 3P Based on 70_ F (21_ C) clear water (corrected to Contact the Gorman‐Rupp Company to verify per... - Page 20 OM-01098 0 SERIES ILLUSTRATION PARTS PAGE Figure 1. Pump Model 02C3-X2 3P PAGE E - 2 MAINTENANCE & REPAIR...
-
Page 21: Parts List
OM-01098 0 SERIES PARTS LIST Pump Model 02C3-X2 3P (From S/N 390873 Up) If your pump serial number is followed by an “N”, your pump is NOT a standard production model. Contact the Gorman‐Rupp Company to verify part numbers. ITEM... -
Page 22: Pump And Seal Disassembly And Reassembly
OM-01098 0 SERIES PUMP AND SEAL DISASSEMBLY ensure that only safe, established main tenance procedures are used, and that AND REASSEMBLY any procedures not addressed in this manual are performed only after estab Review all SAFETY information in Section A. lishing that neither personal safety nor pump integrity are compromised by Follow the instructions on all tags, label and decals... -
Page 23: Pump Disassembly
0 SERIES OM-01098 Remove the impeller adjusting shims (8). Tie and tag the shims or measure and record their thick ness for ease of reassembly. Use Only Genuine Gorman-Rupp re Seal Removal and Disassembly placement parts. Failure to do so may cre ate a hazard and damage the pump or di... -
Page 24: Impeller Installation
OM-01098 0 SERIES faces to ensure that they are free of any foreign lows with water or a very small amount of light lu matter. bricating oil, and apply a drop of light lubricating oil on the finished faces. Assemble the seal as follows To ease installation of the seal, lubricate the bel... -
Page 25: Pump Reassembly
0 SERIES OM-01098 Step 1 Step 2 Step 3 Figure 3. Centering Impeller Within Vane Plate Scroll Install the correct thickness of impeller shims (8) Pump Reassembly and screw the impeller onto the shaft until fully Install the vane plate O‐ring (13) onto the vane seated. - Page 26 For Warranty Information, Please Visit www.grpumps.com/warranty or call: U.S.: 419-755-1280 Canada: 519-631-2870 International: +1-419-755-1352 GORMAN‐RUPP PUMPS...
