QSC SR-110 Specifications

S R - 1 1 0 C i n e m a S u r r o u n d L o u d s p e a k e r
Developed specifically for the unique requirements of
professional motion picture playback, QSC extends its
commitment to the cinema market with the
introduction of the SR-110 Cinema Surround
Loudspeaker. As a member of QSC's DCS Digital
Cinema Speaker Series, the SR-110 offers high-power
handling, excellent sensitivity and extended bass
response in a very compact enclosure.
The SR-110 Cinema Surround Loudspeaker features
a high-power, long-throw 10" low frequency
transducer coupled with a 1" mylar diaphragm
compression driver. The system's MDF enclosure
features a 15-degree down angle baffle and Array
Optimized Tuning (AOT) for optimum frequency
response. The 200 watt continuous power rating and
sophisticated protection circuit built into the
crossover provide absolute reliability.
The compact black enclosure with black grille blends
into any theatre decor. A new QuickMount bracket
design allows for fast, easy and secure installation.
The loudspeaker half of the bracket comes pre-
installed on each SR-110. The QuickMount wall
bracket is purchased separately to allow shipment to
the job site ahead of the loudspeakers. A traditional
U-bracket is also available in lieu of the QuickMount
bracket system.
Key Features:
Parallel outputs for feeding additional
units
95˚ horizontal dispersion
QuickMount bracket for fast, easy and
secure installation
High-power handling capability and
rugged MDF enclosure optimized for
digital soundtrack reproduction
Specifications
Frequency Range [1]
(-6dB, Half space)
(-10dB, Half space)
Nominal Coverage
Directivity Index
Q
Maximum Output [2]
Calculated Peak at rated power
Calculated Continuous
Impedance
Maximum Input Power [3]
(100 hours of 6db crest factor
IEC 268 noise spectrum)
(2 hours of 6db crest factor pink
noise, 50 - 20,000 Hz, AES method)
Recommended Amplifier Power
Sensitivity 1 watt/1 meter, half space
Crossover Frequency
Recommended Processing
Connectors
Transducers
Enclosure
Dimensions
Weight
[1] All frequency ranges specified refer to measured free field response (half space, 2 ).
[2] Calculated SPL at 1m, (half space, 2 ), speaker operating at rated RMS power with pink noise within specified frequency range.
[3] Maximum input power tested in accordance with IEC 268-5 recommendations, 50 Hz - 20 kHz band limiting, 6 dB signal crest factor.
P r e l i m i n a r y S p e c i f i c a t i o n s
SR-110
SR-110
60-20,000 Hz
50-18,000 Hz
95° horizontal X 85° vertical
(averaged from 400 Hz to 12kHz, -6dB)
6.5 dB
4.5
123 dB
117 dB
8 ohms nominal
150 watts RMS
200 watts RMS
400 watts RMS maximum into 8 ohms
94 dB
2.3 kHz
Subsonic filter at 50 Hz as provided by QSC DCA amplifiers
Barrier strip screw terminals accept up to #10 AWG stranded
wire, four terminals two inputs, two parallel outputs
10" long throw low frequency transducer
1" mylar diaphragm compression driver on an elliptical horn
MDF, Baffle angle is 15° downward
15" wide X 20" high X 12" deep (285mm X 508mm X 364mm)
31 lbs. (15kg)
