QSC SR-110 User Manual

QM-SW (Side Wall, 0°) Quick Mount Bracket
QM-BW (Back Wall 8°) Quick Mount Bracket
for the SR-18, SR-26, SR-46, SR-110, and SR-110B Cinema Surround Loudspeakers
Important Safety Precautions & Explanation of Symbols
1- Read these instructions and keep them for future reference.
2- Follow all instructions and heed all warnings.
3- Install in accordance with QSC Audio Product's instructions and a licensed, professional engineer.
4- Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
5- Only use attachments, accessories, mounts, or brackets specified by QSC Audio Products, Inc.
6- Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way.
Installing loudspeakers must be performed by experienced professionals. Incorrectly installed loudspeakers may result in property damage, injury or
death.
WARNING! Before placing, installing, rigging, or suspending any speaker product, inspect all hardware, suspension, cabinets, transducers, brackets and
associated equipment for damage. Any missing, corroded, deformed or non-load rated component could significantly reduce the strength of the installa-
tion, placement, or array. Any such condition severely reduces the safety of the installation and should be immediately corrected. Use only hardware
which is rated for the loading conditions of the installation and any possible short-term unexpected overloading. Never exceed the rating of the hardware
or equipment. Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.
Warranty (USA only; other countries, see your dealer or distributor)
Disclaimer
QSC Audio Products, Inc. is not liable for any damage to amplifiers, or any other equipment that is caused by negligence or improper installation and/or use of this loudspeaker prod-
uct.
QSC Audio Products 3 Year Limited Warranty
QSC Audio Products, Inc. ("QSC") guarantees its products to be free from defective material and / or workmanship for a period of three (3) years from date of sale, and will replace
defective parts and repair malfunctioning products under this warranty when the defect occurs under normal installation and use - provided the unit is returned to our factory or one
of our authorized service stations via prepaid transportation with a copy of proof of purchase (i.e., sales receipt). This warranty provides that the examination of the return product
must indicate, in our judgment, a manufacturing defect. This warranty does not extend to any product which has been subjected to misuse, neglect, accident, improper installation, or
where the date code has been removed or defaced. QSC shall not be liable for incidental and/or consequential damages. This warranty gives you specific legal rights. This limited
warranty is freely transferable during the term of the warranty period.
Customer may have additional rights, which vary from state to state.
In the event that this product was manufactured for export and sale outside of the United States or its territories, then this limited warranty shall not apply. Removal of the serial
number on this product, or purchase of this product from an unauthorized dealer, will void this limited warranty.
Periodically, this warranty is updated. To obtain the most recent version of QSC's warranty statement, please visit www.qscaudio.com.
Contact us at 800-854-4079 or visit our website at www.qscaudio.com.
1675 MacArthur Blvd., Costa Mesa, CA, 92626 USA
Main Number (714) 754-6175 or toll free (USA only) (800) 854-4079
Customer Service(714) 957-7150 or toll free (USA only) (800) 772-2834
These brackets are designed for QSC's SR-18, SR-26, SR-46, SR-110, and SR-110B sur-
round loudspeakers. The QM-SW is intended for side wall mounting and has a 0° angle
(no angle). The QM-BW is intended for back wall mounting and has an 8° downward
angle. An 8° down angle is ideal for most stadium seating when using the SR-26 or SR-
46 loudspeakers. QSC cinema surround loudspeakers are supplied with the mating half
of the Quick Mount bracket installed. We recommend you read and follow these instruc-
tions carefully before beginning.
What is included:
You will also need the two retaining screws (shipped with the loudspeaker) and appro-
priate hardware for attaching the bracket to the mounting structure. This hardware is
not included with the bracket. Refer to loudspeaker mounting procedure on the next
page.
Quantity Description
1 Bracket, QM-SW or QM-BW
