- Page 1 DP2 L 770 REV 000A VERTICAL WINDLASSES *Other languages available by scanning the QR code on the *EN - INSTALLATION AND USER'S MANUAL back of this manual or on the label on the product.
-
Page 3: Table Of Contents
3.2- Precautions for the installer 4 - Installation 4.0 - Installation requirements 4.1 - Installation procedures 5 - Wiring diagram 5.0 - Example of connection DP2 L 770 6 - Cautions & Use 6.0 - Important cautions 6.1 - Clutch use 6.2 - Troubleshooting... -
Page 5: Information About The Product
1/2” (*) For gypsy codes, see the exploded drawing on page 12. **) The values in the table refer to a three-strand polyester rope with a rope/chain splice manufactured with the “Quick®” system. QUICK DP2_L 770 INSTALLATION AND USER’S MANUAL - REV000A... -
Page 6: Supply And Equipment
•Control system via RRC radio (R02 - P02 - H02) 3 - Introduction BEFORE USING THE PRODUCT, PLEASE READ THIS USER’S MANUAL CAREFULLY. IF IN DOUBT, PLEASE CONSULT YOUR QUICK® DEALER. 3.0 - Important notes This manual features Warning and/or Caution symbols that are important for safety. -
Page 7: Precautions
• The splice between the rope and the chain must be tightly woven for the rope to slide easily into the gypsy shape. For any problem or request, feel free to contact Quick® Technical Service. • For improved safety, we recommend installing at least two controls to operate the windlass in case one is damaged. -
Page 8: Installation Procedures
If this is not the case, compensate the difference appropriately (fig. B). A lack of parallelism could result in a loss of motor power. The deck thickness must be included among the figures listed in the table. In case of different thickness, please contact your Quick ® dealer. 5 mm (3/6”) C PEAK DEPTH AND BOW ROLLER HEIGHT There must be no obstacles to the passage of cables, rope and chain under deck (fig. 1C). -
Page 9: Wiring Diagram
DP2 L 770 5 - Wiring diagram 5.0 - Example of connection DP2 L 770 with recommended Quick accessories for the operation of the windlass ® QUICK accessories ® RADIO POCKET for windlass operation BASIC SYSTEM WATERTIGHT HAND HELD WINDLASSES... -
Page 10: Cautions & Use
• DO NOT operate the windlass by using the electrical power when the handle is inserted in the drum or into the gypsy cover. • Quick® recommends using a suitable power fuse/thermal-magnetic/hydraulic-magnetic protection for the motor used, to protect the motor from overheating or short circuits. -
Page 11: Troubleshooting
Carefully remove the chain from the gypsy or the rope from the drum. Quick® windlasses are made of materials resistant to the marine environment: it is essential, in any case, to periodically remove salt deposits that form on the external surfaces to avoid corrosion and consequently damage to the device. -
Page 12: List Of Components Dp2 L 770
DP2 L 770 9 - List of components DP2 L 770 N°. NAME WASHER EXTERNAL SNAP RING STRAIGHT WINDLASS LEVER - NYLON SERRATED WASHER FIRST AXLE WHEELS GYPSY COVER SECOND AXIS WHEELS UPPER CLUTCH CONE OIL SEAL SPINE COMPLETE GYPSY DP2... -
Page 13: Dimensions
® In case of discordance or errors in translation between the translated version and the original text in the Italian language, reference will be made to the Italian or English text. QUICK DP2_L 770 INSTALLATION AND USER’S MANUAL - REV000A... - Page 14 DP2 L 770 REV 000A Product serial number QUICK S.p.A. - Via Piangipane, 120/A - 48124 Piangipane (RAVENNA) - ITALY ® Tel. +39.0544.415061 - Fax +39.0544.415047 - www.quickitaly.com - quick@quickitaly.com...
