Owner's Manual
190 Popular
Roadtrek, Inc.
PDF generated at: Thu, 04 Sep 2014 14:08:31 EDT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 190 Popular and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roadtrek 190 Popular

Summary of Contents for Roadtrek 190 Popular

  • Page 1 Owner's Manual 190 Popular Roadtrek, Inc. PDF generated at: Thu, 04 Sep 2014 14:08:31 EDT...

  • Page 2: Table Of Contents

    Contents Articles Introduction Copyright Do's and Don'ts Before you head out Coming Home Interior Living Space Sleeping Facilities Bathroom Facilities Appliances Outside your Roadtrek Utilities Propane System Heating and Cooling Hydronic System Electrical System Monitor Panel Distribution Panel...
  • Page 3 Alarms and Warnings Maintenance Spare Tire Storage Obtaining Service Specifications Warranty Registration Regulatory Notices HOWTO: Monitor Panel HOWTO: Setting Up Your Campsite HOWTO: Shore Power HOWTO: Potable Water Use HOWTO: Waste Water Dumping HOWTO: Cable and TV Reception HOWTO: Propane System HOWTO: Summer and Winter Mode HOWTO: Water System Winterizing - Standard Edition HOWTO: Water System Winterizing - Anniversary Edition...

  • Page 4: Introduction

    Introduction Congratulations on the purchase of your Roadtrek and welcome to the Roadtreking family. The information included in this manual is meant to help and guide you through the use of your vehicle so that you know how to properly use the many functions your Roadtrek has to offer.

  • Page 5: Copyright

    • • Charge for this manual other than reasonable media and shipping costs. All images used in this manual remain the property of Roadtrek, Inc. They are for illustrative purposes only and may or may not be representative of the upfits in your Roadtrek.

  • Page 6: Do's And Don'ts

    Turn the TV off and stow it while the vehicle is in motion. The flat screen TV should not be stored inside the Roadtrek in cold temperatures. Remove it to reduce the chance of damage from the cold. Check the Owner's Manual for the TV for storage and operating temperatures.
  • Page 7 Do not block the air circulation in the area where the Propane Leak Detector is located. DETECTOR Battery disconnect switch must be in the “ON” position for the propane detector to function. PROPANE LEAK DETECTOR © 2014 by Roadtrek, Inc.
  • Page 8 SERVICING EXTERIOR ACCESS Ensure the shore power cord and city water supply lines are disconnected and in their stored DOORS positions before the vehicle is put in motion. © 2014 by Roadtrek, Inc.
  • Page 9 BATTERY Battery acid can burn your skin and damage clothing. Protective eye wear and gloves should be worn while handling batteries. Effective June 2010 all Roadtrek installed batteries are sealed AGM batteries that do no require the addition of water.
  • Page 10 Plug the vehicle in, drive the vehicle for at least three hours every two weeks to keep the engine and auxiliary batteries charged, or disconnect the engine battery to keep it in good condition. Battery maintenance is the vehicle owner’s responsibility. © 2014 by Roadtrek, Inc.

  • Page 11: Before You Head Out

    Before you head out Before you head out Your new Roadtrek is ready to go with just a little bit of preparation. To prepare for your first trip, you should: • • Read this manual. • • Contact your dealer with any questions.

  • Page 12: Coming Home

    Coming Home Coming Home When you come home, there are a few maintenance tasks you should do to get your Roadtrek ready to go for next time. Refer to other sections in this manual for the procedures listed here. • On your way home, dump the gray and black tanks at a convenient facility. For a concise description of this procedure, see HOWTO: Waste Water Dumping.
  • Page 13 Rear (internal) tank gravity fill Tank selector valve in interior tank Tank isolator valve in open position position (black plastic handle is along the water line) • • Plug in overnight to fully charge batteries. © 2014 by Roadtrek, Inc.
  • Page 14 Inverter switch for large inverter If you turn everything off and you have solar panels, the panels will keep your coach batteries topped up while your Roadtrek is parked outside. If you don't have solar panels, it would be prudent to check your coach battery state of charge every month or so and charge them if necessary.

  • Page 15: Interior Living Space

    Cabinet latches in your Roadtrek are different from the ones in your home and more like those on boats - they have to stay closed when the vehicle is in motion. The cabinet doors are secured with latches located along the edge of the cabinet door.
  • Page 16 For this reason, Roadtrek recommends that you not store anything in the overhead cabinets that you wouldn't want to get hit over the head with.
  • Page 17 The fluorescent lights turn on and off with the integrated switch. The oval ceiling lights are all individually controlled, and are tap lights - to turn them off or on, press on the lens area. © 2014 by Roadtrek, Inc.
  • Page 18 Interior Living Space Tables Rear dining area Front lounge area There are front and rear tables to use either the front or rear lounge areas for dining, playing cards, or computer use. © 2014 by Roadtrek, Inc.
  • Page 19 To stow the front table, lift the top and fold the locking hinge component back against the table top, which will allow the leaf to fold against the main part of the table top. Move the table support back behind the driver's seat, pivot the table top down, and slide it back into its storage compartment. © 2014 by Roadtrek, Inc.
  • Page 20 The table socket is off center. Rotate the table top to suit your needs. When storing the table top, rotate it so that the socket will go down into the hole in the side bench base. © 2014 by Roadtrek, Inc.
  • Page 21 Moving the bottom cushion forward and flipping the small panel at the base of the seat back out will configure the second row seat in a more reclined position. © 2014 by Roadtrek, Inc.
  • Page 22 Interior Living Space Second row seat back pin and slot Back seat configured in reclined position © 2014 by Roadtrek, Inc.
  • Page 23 Interior Living Space Ventilation Your Roadtrek is equipped with a ceiling mounted ventilation fan. The fan has a cover that must be raised by turning the large knurled knob before the fan will operate. Raise the cover, then turn the switch to the desired speed.
  • Page 24 Interior Living Space Window Treatments Skylight covers Skylight cover storage Curtains Curtain rails and clips © 2014 by Roadtrek, Inc.
  • Page 25 The window curtains for the regular windows slide on tracks. It's best to use two hands, one at each track, to pull curtains closed and open. The curtains have snaps and clips at the end of the track to hold them in place. © 2014 by Roadtrek, Inc.

  • Page 26: Sleeping Facilities

    Sleeping Facilities Sleeping Facilities Your Roadtrek has beds that can be set up as either a king bed or two twin beds. Experiment with different configurations to find what works best for you. Power Sofa Power sofa switch Power sofa The switch to lower the sofa into the bed position is located next to the thermostat on the passenger side in the rear.
  • Page 27 Sleeping Facilities Twin beds King bed © 2014 by Roadtrek, Inc.
  • Page 28 Move the bottom cushion for the bench seats together over this panel, and place the smaller seat back cushions for the bench seats between these and the outer walls of the Roadtrek. Panel to support cushions for king bed © 2014 by Roadtrek, Inc.
  • Page 29 With the front seat facing the door, slide it as far back (toward the center aisle) as possible to accommodate the folding mattress. This configuration is only possible with the standard bathroom - enclosed bathroom models do not have the second row seat. © 2014 by Roadtrek, Inc.

  • Page 30: Bathroom Facilities

    • • Release the Velcro retention straps from the shower curtain and move the hand held shower from its storage position to the shower position. • • Draw the shower curtain until you are completely surrounded. • • Using the Velcro connectors, secure the edges of the curtain to the inside edges of the door. © 2014 by Roadtrek, Inc.
  • Page 31 Open the doors, unlatch the inner partition, and secure the door against the other side of the aisle. The toilet is a marine toilet that has a single flush pedal. When done using it, step on the pedal to flush. Optional Enclosed Bath © 2014 by Roadtrek, Inc.
  • Page 32 Bathroom Facilities Toilet Shower curtain Toilet pedal Bathroom door pin © 2014 by Roadtrek, Inc.
  • Page 33 This will prevent the doors from swinging open when the vehicle is in motion. Toilet The enclosed bathroom in your Roadtrek contains a marine toilet. To flush the toilet, press the foot pedal located at the bottom of the front of the toilet bowl.
  • Page 34 When finished, either air or towel dry the curtain before storing it, refasten the drain stopper to prevent the contents of the gray water tanks from sloshing up into the shower area while driving, and remove the shower hose from the sink connection. Push the knob back down to change the sink back into normal mode. © 2014 by Roadtrek, Inc.
  • Page 35 Pull the white bar back down to close it. Do not drive with the vent open. Outside Shower The outside shower is located on the driver's side, towards the rear wheel. See Outside your Roadtrek for more details on location.

  • Page 36: Appliances

    Both the television and the DVD player use 120 volt current, so the inverter, generator, or shore power must be used. They are supplied with remote controls. See the HOWTO: Cable and TV Reception for antenna connections and configuration details. © 2014 by Roadtrek, Inc.
  • Page 37 Rear speaker control switch Controlling the Rear Speakers The surround sound system offered in your Roadtrek allows you to control the rear speaker sound in your vehicle. Locate the speaker switch which can be found in the cabinet above the home theater system.
  • Page 38 Hot Water Standard Propane Water Heater The 190 Popular is equipped with a 6 gallon water heater. The heater requires both 12VDC and propane for proper operation. See Monitor Panel for location and operation of the switch for the heater.
  • Page 39 The burner igniters require 12 volt power to work, so turn on the battery disconnect switch to use them. Refer to the stovetop owner's manual for details of operation. Galley stove © 2014 by Roadtrek, Inc.

  • Page 40: Outside Your Roadtrek

    To open the awning push the rocker switch and the awning will extend. Lower the supports on each side and secure them to the two attachment points on the side of the Roadtrek. Refer to the awning manual for the proper way of securing the awning supports to the attachments.
  • Page 41 The center door has a storage area for the waste water discharge hose and power cord. The smaller door just in front of the rear tire has the outside shower. The rear access door has the shower and cable TV connection. © 2014 by Roadtrek, Inc.
  • Page 42 Since all these sources of open flame are near the fuel fill door on the driver's side, please ensure that all propane appliances are off when refueling your Roadtrek. In addition to making sure your main propane tank valve is shut whenever the vehicle is stored or in motion, turn the battery disconnect switch off when refueling - this will disable the water heater igniter, the refrigerator igniter, and the furnace.
  • Page 43 If you ordered this option, look for this screen in the white box that comes with your new Roadtrek. The screen attaches to the rear door frame and cargo area floor with a zipper and hook-and-loop fasteners.
  • Page 44 Open the screen and locate the edge with hook and loop material along it. This edge is the bottom, so use the hook-and-loop strips on the screen to attach it across the bottom of the door opening. Start the zipper on the left side Installed screen You can access the underbed storage area without removing the screen © 2014 by Roadtrek, Inc.
  • Page 45 Use the double slider to unzip the bottom of the screen to allow access to the underbed storage area in the back of the Roadtrek without disturbing the top section. To remove and stow the screen, unzip it from the top down. Unzipping it from the bottom will not allow you to remove it from the doorframe surround.
  • Page 46 Outside your Roadtrek Locate the screen in the white box that comes with your new Roadtrek, and shake it out. To orient the screen correctly, look for the zipper in the screen - hold the screen so that the zipper goes across near the top and then down the right side.

  • Page 47: Utilities

    Utilities Utilities Just like your house, your 190 Popular has fresh water, electricity, waste water disposal, heating, and cooling systems. In the 190 Popular, these systems are self contained and travel with you. Your vehicle should be reasonably level to allow normal operation of the system.
  • Page 48 In summer mode, you don't have to worry about which tank has water - with the tank isolator valve open, water from the interior tank replenishes water from the exterior tank as it is used. © 2014 by Roadtrek, Inc.
  • Page 49 Fill exterior tank first, then interior tank. Roadtrek recommends that you use a dedicated single purpose potable-water hose. These are usually white in color. Buy a new one and use it only for filling your tanks and connecting to city water. View any hose lying around a campground with extreme skepticism, especially it there's a wastewater dump nearby.
  • Page 50 Utilities City Water Your Roadtrek can operate in either fully self-contained mode, or can be connected to a water supply such as a campsite's faucet. The city water connection is in the driver's side rearmost compartment. Unscrew the white plastic protective cap and connect your clean hose to the water faucet and a water pressure regulator attached to this connection point.
  • Page 51 If you see fluid below the toilet valve in the bowl of the toilet, your black water tank is full and also needs to be emptied before further use. © 2014 by Roadtrek, Inc.
  • Page 52 Close both the black and grey water gate valves before using the waste water system. It is possible for the valves to open slightly especially after extensive driving. Black and grey water dump valves are accessed through the driver side storage door. © 2014 by Roadtrek, Inc.

  • Page 53: Propane System

    You must close the tank shutoff valve when the vehicle is not in daily use. Further, you must close the shutoff valve when the vehicle is traveling. Never operate any propane appliance, including the refrigerator, while the vehicle is in motion. © 2014 by Roadtrek, Inc.
  • Page 54 The propane system has a high-pressure auxiliary BBQ takeoff. Locate the hose behind the access panel. The hose has a yellow dustcap, and an integral cutoff valve. This provides 15PSI regulated propane to appliances that have their own regulators or are built to use high-pressure propane. © 2014 by Roadtrek, Inc.
  • Page 55 Propane fill valve Propane bleed Roadtrek recommends that you take your van to a qualified LPG retailer to fill the tank. While filling, turn off all propane appliances, then turn off the tank shutoff valve. We recommend that you use only propane from certified LPG retailers.
  • Page 56 The auxiliary BBQ outlet is regulated to 15 P.S.I. If you are using an external grill with this hookup, ensure that the appliance is rated for that pressure or has its own regulator for lower pressure. © 2014 by Roadtrek, Inc.

  • Page 57: Heating And Cooling

    For all other circumstances, use the regular heating system to heat the cabin. If your unit has the heat strip option, you can operate it by turning the thermostat to "furnace" and setting the desired temperature. The third setting, "fan", recirculates cabin air using the fan inside the air conditioning unit. © 2014 by Roadtrek, Inc.
  • Page 58 Heat Pump The heat pump can provide both heating and cooling for your Roadtrek using electric shore power or generator power. The heat pump gives you the advantage of heating your unit with electricity if you would prefer to use electricity rather than the propane the furnace uses.
  • Page 59 Keep the aisle in front of the furnace clear of any obstructions when using the furnace to allow air circulation. The furnace can operate when outside temperatures are below freezing. Anniversary Edition Hydronic Heat See Hydronic System © 2014 by Roadtrek, Inc.

  • Page 60: Hydronic System

    This protects the Alde plumbing only; you still need to winterize the remaining water system in your Roadtrek to prevent damage to the water lines and other components. You can also drain the system manually by turning the valve to the tripped position.
  • Page 61 Hydronic System temperature around the valve is high enough. Alde frost control valve in operating Resetting the tripped valve position © 2014 by Roadtrek, Inc.

  • Page 62: Electrical System

    Electrical System Electrical System Coach Batteries The coach batteries in your Roadtrek are sealed AGM batteries. Do not attempt to open them. There is no user maintenance possible on these batteries except keeping them charged. Battery Disconnect Switch The battery disconnect switch provides power to all 12 volt appliances, such as the water pump, the refrigerator, and so forth.
  • Page 63 Standard Alternator Charger and Battery Isolator While driving, your Roadtrek will also charge the coach batteries from the vehicle alternator through an isolator. The isolator allows extra vehicle alternator-produced electricity to charge your coach batteries in addition to keeping your engine (chassis) battery charged.
  • Page 64 The standard configuration includes a 750 watt inverter. This inverter provides 120 volt AC power (household current) for a few of the outlets in your Roadtrek; primarily the ones running the TV and the DVD player. It is not powerful enough to operate the air conditioner or the microwave.
  • Page 65 Always close the rear windows of the vehicle and turn off the roof ventilation fan to avoid exhaust entering the vehicle's interior. Optional gasoline generator switch © 2014 by Roadtrek, Inc.
  • Page 66 Electrical System Shore Power The shore power cord is located on the driver's side, in the large middle compartment. See Outside your Roadtrek for location. The switchover from shore power to inverter is automatic, as is battery charging. As soon as your inverter/charger senses power coming in, it will start charging the coach batteries.

  • Page 67: Monitor Panel

    Roadtrek is not being used to avoid discharging the batteries. The battery disconnect switch has a blue indicator light to the right of it to show you when the battery power is on.
  • Page 68 2500 watt inverter, your inverter switch is back by the thermostat on the passenger side of the rear lounge area. See the Optional Engine Generator and 2500 Watt Inverter portion of the Electrical System section for further information. © 2014 by Roadtrek, Inc.
  • Page 69 Shore Power Shore power is the name for power supplied by a utility company that you plug into to provide power to your Roadtrek. See HOWTO: Shore Power for a concise guide to plugging in and unplugging from shore power.
  • Page 70 Even though the water heater uses propane to heat the water, all the igniters and controls are electrical. Water heater switch Tank status lights © 2014 by Roadtrek, Inc.
  • Page 71 The hour meter to the right of the switch keeps track of how many hours your generator has been running. There is a break-in oil change after 20 to 50 hours of operation, and other required maintenance at other intervals later on - see the generator manual for details. © 2014 by Roadtrek, Inc.

  • Page 72: Distribution Panel

    Flip the cover to the right and note the sticker under the cover with the identifying information on each breaker. When storing the Roadtrek for the winter, turn off the battery disconnect switch and all circuit breakers in this panel.
  • Page 73 120 Volt AC Breakers DC Fuses 12 Volt Fuse Panel The 12 volt fuses are located to the right of the 120 volt AC breakers. The sticker on the cover has identifying information for each fuse. © 2014 by Roadtrek, Inc.

  • Page 74: Alarms And Warnings

    The detector has a useful service life, beyond which it needs to be replaced. See Manufacturer’s Owner’s Manual for other operating instructions, or look for the sticker which is sometimes placed on the detector to see the replacement date. The detector may chirp if the coach batteries are running low. © 2014 by Roadtrek, Inc.
  • Page 75 Fire Extinguisher Your Roadtrek comes equipped with a dry chemical fire extinguisher suitable for all fires. Before every trip, check to see that the needle on the dial is in the green range. If not, replace the fire extinguisher. DO NOT test your fire extinguisher by discharging it - total discharge time is 8 to 12 seconds, it will rapidly deplete if you test it this way.

  • Page 76: Maintenance

    Any adverse conditions should be brought to the attention of your dealer or qualified service technician for expert service advice as soon as possible. The owner maintenance checks are generally not covered by warranties and you may be charged for labor, parts and supplies used. © 2014 by Roadtrek, Inc.
  • Page 77 • Flush tanks again. You can add 1/2 cup vinegar add while you flush to help dissipate the chlorine smell. Information on the location of these valves is in the HOWTO: Potable Water Use section. © 2014 by Roadtrek, Inc.
  • Page 78 Maintenance Exterior tank fill location (driver door Interior tank fill location (rear door, right pillar) side) Exterior tank drain, under driver's Tank isolator valve,shown in open Tank selector valve in interior tank doorstep position position © 2014 by Roadtrek, Inc.
  • Page 79 To prevent water from entering your vehicle, avoid spraying water directly into exterior vents or grills. Do not use a power washer to clean your Roadtrek - damage to the paint, removal of decals, and water leaks will result. Hand washing or commercial car washes accommodating large vehicles are the best way to keep your Roadtrek clean.

  • Page 80: Spare Tire Storage

    Roadtrek. If you ever need to change a tire, you will need this key. If your new Roadtrek still has the blue protective coating on the chrome spare tire cover, remove it as soon as you can.
  • Page 81 To use the spare tire, lower the tire, unlock the chrome surround with the key supplied with your Roadtrek, unbolt the tire from the carrier with your lug wrench, and lift the tire off the carrier. Follow the Chevrolet manual for instructions on the use of the jack and other tire change procedures.

  • Page 82: Obtaining Service

    Obtaining Service Obtaining Service When your Roadtrek needs service, determine if the issue is with the Roadtrek upfits or the GM Chassis. For Roadtrek upfits, contact your Roadtrek dealer. For chassis-related issues, contact GM service. Advise the service writer that you have a G-30 1 ton van, rather than a "motorhome".

  • Page 83: Specifications

    For general chassis specifications, please refer to the GM manual. For specifications relating to your vehicle, including occupancy, weight rating, tire size, inflation, and so on refer to the sticker on the driver's side B pillar (right side of the door frame, near the latch). This specification refers to the Roadtrek upfits. Roadtrek upfits only Total fresh water capacity (includes water heater) 31 gallons/ 117 liters...

  • Page 84: Warranty

    Roadtrek Motorhomes 5 Year Upfit Warranty Roadtrek Motorhomes warrants to the Purchaser that the Vehicle is free from defects in material and workmanship on the portion manufactured by Roadtrek Motorhomes, under normal use and service, for five (5) years, from date of purchase by the first Purchaser or the date the Vehicle was first put into service (for example, as a demo or rental), whichever is earlier.
  • Page 85 Roadtrek Motorhomes Limited Motorhome Warranty is void unless the following conditions are adhered to: 1. 1. Warranty Card on Vehicle must be completed by the Dealer and faxed to Roadtrek Motorhomes within 48 hours of date of retail delivery. When warranty applications are made and Warranty Card is not on file at Roadtrek Motorhomes, reimbursement of claim will be delayed until proof of original purchase is submitted to Roadtrek Motorhomes.
  • Page 86 Warranty 5. 5. Only parts and accessories and other material, available through Roadtrek Motorhomes are to be used in the performance of warranty service. Express shipping costs are not covered by this warranty policy. 6. 6. Warranty repairs performed a second time by a Dealer (due to incorrect or inadequate diagnosis, improper assembly or repair, or lack of proper testing when the original warranty repair was performed) are considered as shop comebacks and are not reimbursable.
  • Page 87 The intent of this extended warranty is to assure the new owner of a Roadtrek that it is worry free from manufacturer caused defects for the first five (5) years of use. The first owners of this unit can feel comfortable that Roadtrek is behind them for five (5) years.

  • Page 88: Registration

    Registration Registration Please send this form in or email the information to sales@roadtrek.com when you purchase your Roadtrek. © 2014 by Roadtrek, Inc.
  • Page 89 Registration References [1] mailto:sales@roadtrek. com © 2014 by Roadtrek, Inc.

  • Page 90: Regulatory Notices

    Regulatory Notices If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration, (NHTSA) in addition to notifying Roadtrek Motorhomes. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 91: Howto: Monitor Panel

    The battery disconnect switch turns the coach battery power off and on. When off, it prevents your coach batteries from being drained while the Roadtrek is not in use. The lights, the water pump, the fan, the refrigerator control board, even the igniters for the propane cooktop need 12 volt power from the batteries.
  • Page 92 The inverter will shut off if you try to draw too much power through it. © 2014 by Roadtrek, Inc.
  • Page 93 There is a shore power indicator light to the right of the switch to tell you the system is receiving shore power. There is also a battery charging indicator light to tell you when the batteries are being charged by shore power. © 2014 by Roadtrek, Inc.
  • Page 94 Even though the water heater uses propane to heat the water, all the igniters and controls are electrical. Be sure that the water heater is full of water before turning it on - if water © 2014 by Roadtrek, Inc.
  • Page 95 These will give you an approximate reading, to the nearest third, of how much is in each tank. Roadtrek recommends that you keep a small amount of water in your gray and black tanks at all times. This will reduce the likelihood of material sticking to the inside of the tank.
  • Page 96 See your Cummings/Onan generator service manual for details. There is a break-in oil change after the first 20 to 50 hours of use. You also need to exercise your generator every month by running it for an hour under moderate load. © 2014 by Roadtrek, Inc.

  • Page 97: Howto: Setting Up Your Campsite

    What Do You Need To Hook Up? In a Roadtrek, the answer to this question is - a lot less than you think. Rather than slog through the setup ordeal that Class As and fifth wheels and other trailers go through, Class Bs are much more nimble. We travel light and can set up and pack up in minutes.
  • Page 98 Full hookup sites have a handy sewer dump right at your campsite. When your fresh water runs low, refill your fresh water tanks, dump your waste water holding tanks, and you're good to go, plus you can drive off anytime merely by stowing your electrical cord. © 2014 by Roadtrek, Inc.
  • Page 99 Once you're out there, don't look around for those big rigs who are dependent on hookups - they're all back in town. It's just you and nature, with the occasional backpacker. © 2014 by Roadtrek, Inc.
  • Page 100 Front-to-back leveling is more important than side-to-side Leveling blocks leveling. If you have a choice, it's better to have the front of the Roadtrek very slightly higher than the back both for shower drainage and heat pump condensate drainage.

  • Page 101: Howto: Shore Power

    HOWTO: Shore Power Your Roadtrek has a shore power cord, which is permanently attached inside the large driver's side storage compartment. Open this compartment and pull the cord out to attach to the campsite or house electrical outlet. There is a "mousehole" in the rear of the storage compartment to thread the cable through if you wish to close the compartment while plugged in.
  • Page 102 Most RV parks and campgrounds have AC power of various voltages and amperages available at each site. The power will typically be in a pedestal with a cover that flips up. If you cannot find your power pedestal or you're not sure how to open it, ask the campground personnel. 50A outlet 30A outlet © 2014 by Roadtrek, Inc.
  • Page 103 The pedestal will also typically have individual breakers for the 15A, 30A, and 50A services. Many campgrounds turn off unused breakers so check that the breaker for the plug you will be using is turned on. Your Roadtrek is equipped with a 30 amp cord. Most power pedestals have a 30 amp receptacle. © 2014 by Roadtrek, Inc.
  • Page 104 30 amps available. Although you are connected to a 50A service, you can only draw 30A; there is no advantage to connecting to a 50A service if a 30A service is available. © 2014 by Roadtrek, Inc.

  • Page 105: Howto: Potable Water Use

    HOWTO: Potable Water Use HOWTO: Potable Water Use Your Roadtrek can operate in either fully self-contained mode, or can be connected to a water supply such as a campsite's faucet. The city water connection is in the driver's side rearmost compartment. Unscrew the white plastic protective cap and connect your clean hose to the water faucet and this connection point.
  • Page 106 HOWTO: Potable Water Use You can connect to a city water connection when your Roadtrek is configured in the summer operation mode. The city water inlet connection is located in the small compartment just in front of the driver's side rear tire.
  • Page 107 Make sure the black plastic handle is vertical, and perpendicular to the water line when your water system is in self-contained mode. © 2014 by Roadtrek, Inc.
  • Page 108 The tank selector valve has a long plastic covered handle, usually either yellow or red. When this handle is pointed toward the front of the Roadtrek, the tank selector valve is drawing water from the internal tank. You want it to be pointing toward the driver's side of the vehicle - that's the position where it's drawing water from the external tank.
  • Page 109 85 pounds lighter. Every little bit helps. Of course, once you get to the area where you're going to camp, fill up both tanks before you head out boondocking so you can stay out for a longer time without running out of water. © 2014 by Roadtrek, Inc.

  • Page 110: Howto: Waste Water Dumping

    Your house is permanently connected to your septic system or a municipal sewer; you don't have to worry about the wastewater you generate because gravity takes it away. Your Roadtrek doesn't have that connection, and has to hold any wastewater until you have the opportunity to dump it at an approved dump station.
  • Page 111 • • Open the access door just to the rear of the driver`s side door. This will expose the black and gray water valves. Support the door in the open position by using the support arm. © 2014 by Roadtrek, Inc.
  • Page 112 • • Open the long compartment behind the driver. This will expose the waste water discharge hose. Support the door in the open position by using the support arm. Waste discharge switch Extending the hose © 2014 by Roadtrek, Inc.
  • Page 113 • Open the driver’s door and locate the waste water pump switch. It is a red pushbutton located on the driver's seat base. • • Remove the waste water discharge hose from storage. Open the waste water discharge hose Weigh the hose down to prevent valve accidents © 2014 by Roadtrek, Inc.
  • Page 114 • • There are two ways to secure the hose in the dump station waste receptacle four inch pipe. In the white box that came with your Roadtrek there is a rubber doughnut, which goes over the discharge nozzle and can be wedged into the waste receptacle to hold the waste water discharge hose in place.
  • Page 115 Tear open the packet and pour the contents into the black tank, and dispose of the packet in the trash. The contents of the powder packets can be irritating to your eyes and nose, so hold the packet low to the bowl and try to © 2014 by Roadtrek, Inc.
  • Page 116 • • Push in on the knob and turn clockwise; you will feel the knob engage the pump shaft. • • Turn the knob first in one direction and then the other to loosen the obstruction. • • Once loose, continue dumping. © 2014 by Roadtrek, Inc.

  • Page 117: Howto: Cable And Tv Reception

    HOWTO: Cable and TV Reception Your Roadtrek comes with a home theatre system. This consists of a TV, a DVD player, the speaker system and the radio in the dash, along with a rooftop TV antenna and a cable TV connection.
  • Page 118 Rear speaker switch Over-the-air TV To watch TV using the Roadtrek rooftop antenna: • • Have 120 volt AC power available (inverter on OR shore power plugged in OR generator running) • • Turn on TV and home theatre system •...
  • Page 119 Coaxial TV connecting wire with screw-on You need a length of coaxial TV cable to reach from the cable TV outlet to your Roadtrek's connection point. These are sold in electronic supply and camping supply stores and come in lengths of 25, 50, and 100 feet. The cable is typically sold as RG-59U or RG-6 with F-type connectors.
  • Page 120 TV cable connected Selector switch Push the small white button in the cabinet above the TV. The button selects between the cable or an external source such as your antenna. © 2014 by Roadtrek, Inc.
  • Page 121 In the Surround position, the rear speakers (the speakers above the bed) will work with the TV/home theatre system. In the Off position the speakers are off. In the Automotive position, the speakers are connected to the dash radio. Rear speaker switch © 2014 by Roadtrek, Inc.

  • Page 122: Howto: Propane System

    This valve must be closed whenever the vehicle is in motion in any case, not just in certain areas. Other bridge/tunnels/ferries ban vehicles with propane tanks entirely. Plan ahead and take an alternate route if passing through areas where vehicles with propane are prohibited. © 2014 by Roadtrek, Inc.
  • Page 123 If you close the main valve for an extended period of time it is possible for the distribution lines to fill with air. It may take a while for propane to fill the lines again. The fridge and water heater handle this automatically; for the stove you can hear the difference between propane and air. © 2014 by Roadtrek, Inc.
  • Page 124 This provides 15PSI regulated propane to appliances that have their own regulators or are built to use high-pressure propane. The auxiliary BBQ male connector is Cast Products part # 829000. The hose assembly in varying lengths is available as MB Sturgis part no. 100476. © 2014 by Roadtrek, Inc.
  • Page 125 You may also see liquid propane spit out of the bleeder valve. Stop filling immediately and close the bleeder valve. We recommend that you use only propane from certified LPG retailers. © 2014 by Roadtrek, Inc.
  • Page 126 Note the amount it takes to fill your tank. The ten gallon tank in your Roadtrek will hold eight gallons / 30.4 liters when completely empty and filled to the correct 80% level.
  • Page 127 Propane tanks must not be placed or stored inside your vehicle. Propane tanks are equipped with safety devices which relieve excessive pressure by discharging gas to the atmosphere. The Roadtrek's propane tank is mounted outside the vehicle and will vent propane where it can dissipate; any tank inside the vehicle will vent into the passenger compartment, creating an explosive propane-air mixture inside the enclosed space, which also contains many potential sources of ignition.
  • Page 128 The auxiliary BBQ outlet is regulated to 15 P.S.I. If you are using an external grill with this hookup, ensure that the appliance is rated for that pressure or has its own regulator for lower pressure. © 2014 by Roadtrek, Inc.

  • Page 129: Howto: Summer And Winter Mode

    The hot water heater will also not freeze if left running. In this way, hot and cold running water continues to be supplied to the galley sink, toilet, and shower. © 2014 by Roadtrek, Inc.
  • Page 130 "Winter mode" and "winterized" are two different things. Winter mode protects the water in the system from mildly sub-freezing conditions as long as the Roadtrek is adequately heated and in use. If you plan extended stays in sub-freezing conditions or if you store your vehicle in freezing conditions, you must winterize to avoid damage to the water system.
  • Page 131 (colored plastic handle pointed position, with the colored plastic handle toward driver's side of Roadtrek). This pointed toward the front of the Roadtrek. valve is located inside the hot water heater enclosure, just in front of the tank isolator valve.
  • Page 132 The cold water shutoff valve is harder to find; it is alongside the left side of the water heater about halfway back, on the floor. To shut these valves, turn them so that the black plastic handles are across the water line. Hot water shutoff valve, shown closed Cold water shutoff valve, shown open © 2014 by Roadtrek, Inc.
  • Page 133 This valve is located inside drain the tank, turn the handle so that it the hot water heater enclosure, at the points along the water line. base of the large black speaker on the back wall. © 2014 by Roadtrek, Inc.
  • Page 134 Tank selector valve in exterior tank position, with the colored plastic handle position (colored plastic handle pointed pointed toward the front of the Roadtrek. toward driver's side of Roadtrek). This valve is located inside the hot water heater enclosure, just in front of the tank isolator valve.
  • Page 135 • • Open the two shutoff valves going to the outside shower, and close the outside shower faucet after running water through them briefly to flush air and any contaminants. Hot water shutoff valve, shown open Cold water shutoff valve, shown open © 2014 by Roadtrek, Inc.

  • Page 136: Howto: Water System Winterizing - Standard Edition

    (above 40 deg. F or above 4 deg. C) and the forecast is for temperatures just below freezing for a few hours at night with calm winds, then you don`t need to winterize. The heat in your Roadtrek is enough to keep the lines from freezing.
  • Page 137 • • Dump and rinse the gray and black tanks if they are not already empty. • • Turn off the water pump and open your single lever galley faucet, putting it in the middle halfway between the hot and cold settings. © 2014 by Roadtrek, Inc.
  • Page 138 Let this drain for at least 30 minutes. Close the valve between the tanks and the drain for the exterior tank. © 2014 by Roadtrek, Inc.
  • Page 139 Do so if necessary, and then turn the water pump off. Return the galley sink lever to its open position halfway between hot and cold. © 2014 by Roadtrek, Inc.
  • Page 140 If water is gushing out continuously, STOP! Go back to the beginning of this guide. DO NOT remove the anode rod until you figure out what`s going on. You either left the water pump on, or you are hooked up to city water. © 2014 by Roadtrek, Inc.
  • Page 141 This is a good time to rinse out the water heater and inspect the anode rod. If the anode rod looks spongy or all that is left is a rusty iron rod, throw it away and buy and install a new anode rod. Use teflon tape on the threads to reinstall the anode rod. Do not overtighten. © 2014 by Roadtrek, Inc.
  • Page 142 • • Turn the city water connection valve on. The water pump will operate. Allow it to run about 20 seconds. Turn city water connection valve off. • • Turn the water pump off and open a galley sink faucet to release back pressure. © 2014 by Roadtrek, Inc.
  • Page 143 • • Remove water pump filter if so equipped. Replace water pump filter lid. Winterizing using compressed air Roadtrek recommends against using compressed air for winterizing. Other methods of winterizing Roadtrek only recommends the winterizing method outlined above using RV antifreeze. © 2014 by Roadtrek, Inc.

  • Page 144: Howto: Water System Winterizing - Anniversary Edition

    (above 40 deg. F or above 4 deg. C) and the forecast is for temperatures just below freezing for a few hours at night with calm winds, then you don`t need to winterize. The heat in your Roadtrek is enough to keep the lines from freezing.
  • Page 145 • • Dump and rinse the gray and black tanks if they are not already empty. • • Turn off the water pump and open your single lever galley faucet, putting it in the middle halfway between the hot and cold settings. © 2014 by Roadtrek, Inc.
  • Page 146 Let this drain for at least 30 minutes. Close the valve between the tanks and the drain for the exterior tank. © 2014 by Roadtrek, Inc.
  • Page 147 Do so if necessary, and then turn the water pump off. Return the galley sink lever to its open position halfway between hot and cold. © 2014 by Roadtrek, Inc.
  • Page 148 If water is gushing out continuously, STOP! Go back to the beginning of this guide. DO NOT remove the anode rod until you figure out what`s going on. You either left the water pump on, or you are hooked up to city water. © 2014 by Roadtrek, Inc.
  • Page 149 This is a good time to rinse out the water heater and inspect the anode rod. If the anode rod looks spongy or all that is left is a rusty iron rod, throw it away and buy and install a new anode rod. Use teflon tape on the threads to reinstall the anode rod. Do not overtighten. © 2014 by Roadtrek, Inc.
  • Page 150 Ensure antifreeze flows into all P-traps (galley sink, washroom sink, and shower). You may also consider adding antifreeze from the extra gallon in the container jug to the shower floor-pan trap. © 2014 by Roadtrek, Inc.
  • Page 151 • • If the water pump loses its prime in this process, add more antifreeze to the interior fresh water tank. • • Open the grey and black waste tank valves, and operate the macerator pump for about 20 seconds. You should see pink antifreeze coming out of the waste water discharge hose. © 2014 by Roadtrek, Inc.
  • Page 152 • • Open the fresh tank drain line briefly until antifreeze flows out. • • Remove water pump filter if so equipped. Replace water pump filter lid. © 2014 by Roadtrek, Inc.

  • Page 153: Howto: De-Winterizing - Standard Edition

    2. 2. Mix up two gallons of water and one cup of chlorine bleach. Add to the exterior fresh water fill. You now have a chlorine mixture in both water tanks. 3. 3. This is a good time to get some stuff for spring cleaning of your Roadtrek, so drive around for an hour. Let it sit for a couple more hours.
  • Page 154 • • Pull the anode rod out of the water heater and flush out the water heater tank with a hose. Install the new anode rod using Teflon tape on the threads, and close the pressure relief valve. Take the system out of water heater bypass mode by © 2014 by Roadtrek, Inc.
  • Page 155 • • Drain both tanks completely, fill both fresh water tanks with clean water, and run all faucets for 2-3 minutes each. To help get rid of the residual chlorine smell, pour a half cup of vinegar into each tank, fill, let sit for a few hours, drain, and refill with fresh water. © 2014 by Roadtrek, Inc.

  • Page 156: Howto: De-Winterizing - Anniversary Edition

    2. 2. Mix up two gallons of water and one cup of chlorine bleach. Add to the exterior fresh water fill. You now have a chlorine mixture in both water tanks. 3. 3. This is a good time to get some stuff for spring cleaning of your Roadtrek, so drive around for an hour. Let it sit for a couple more hours.
  • Page 157 • • Pull the anode rod out of the water heater and flush out the water heater tank with a hose. Install the new anode rod using Teflon tape on the threads, and close the pressure relief valve. Take the system out of water heater bypass mode by © 2014 by Roadtrek, Inc.
  • Page 158 • • Drain both tanks completely, fill both fresh water tanks with clean water, and run all faucets for 2-3 minutes each. To help get rid of the residual chlorine smell, pour a half cup of vinegar into each tank, fill, let sit for a few hours, drain, and refill with fresh water. © 2014 by Roadtrek, Inc.
