Highboy TV Stand
Barrister Lane Collection | Model 414720
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Your holder for all
things awesome.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 376462
09/14/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Barrister Lane 414720 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Barrister Lane 414720

Summary of Contents for Sauder Barrister Lane 414720

  • Page 1 Barrister Lane Collection | Model 414720 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 50 pounds. Never use with a TV that weighs more.
  • Page 3 LOWER RIGHT END (1) BACK (1) SIDE BASE (2) LOWER LEFT END (1) BRACE (1) SIDE RAIL (2) UPRIGHT (1) DOOR (4) BACK RAIL (1) LOWER UPRIGHT (1) FRONT MOLDING (1) G2 TOP (1) RIGHT MOLDING (1) www.sauder.com/services 414720 Page 3...
  • Page 4 BLACK 9/16" LARGE HEAD SCREW - 24 BLACK 1-7/8" FLAT HEAD SCREW - 15 BROWN 7/16" LARGE HEAD SCREW - 16 SILVER 1-1/8" FLAT HEAD SCREW - 7 GOLD 1" MACHINE SCREW - 8 BROWN 1" FLAT HEAD SCREW - 4 Page 4 414720 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1269...
  • Page 6 (12 used in this step) Do not fasten this end of the DOOR SLIDE until step 17. Finished edge Finished edge Finished edge Do not fasten this end of the DOOR SLIDE until step 17. Finished edge Page 6 414720 www.sauder.com/services...
  • Page 7 Fasten the RAILS (R and S) to the TOP (G2). Use seven å BLACK 1-7/8" FLAT HEAD SCREWS (2S). Rounded edge Rounded edge Finished surface r f a w i t l e s BLACK 1-7/8" FLAT HEAD SCREW (7 used in this step) www.sauder.com/services 414720 Page 7...
  • Page 8 Step 4 Tap two MOLDING CONNECTORS (19F) into the notches å in the MOLDINGS (M, N, and O). Use your hammer to tap the MOLDING CONNECTORS (19F) into the notches in the MOLDINGS. Flat end Flat end Page 8 414720 www.sauder.com/services...
  • Page 9 Fasten the MOLDINGS (M, N, and O) to the TOP (G2). å Use seven SILVER 1-1/8" FLAT HEAD SCREWS (10S). NOTE: Do not over tighten the SCREWS into the TOP. å SILVER 1-1/8" FLAT HEAD SCREW (7 used in this step) Finished surface www.sauder.com/services 414720 Page 9...
  • Page 10 Step 6 Turn four CAM SCREWS (8F) into the MOLDINGS (N and O). å Page 10 414720 www.sauder.com/services...
  • Page 11 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 414720 Page 11...
  • Page 12 Use six BLACK 1-7/8" FLAT HEAD SCREWS (2S). Do not stand the unit upright without the BACK fastened. The unit may collapse. Rounded edge r f a w i t l e s BLACK 1-7/8" FLAT HEAD SCREW (6 used in this step) Page 12 414720 www.sauder.com/services...
  • Page 13 UPRIGHT (F) to the SHELF (I). Tighten six HIDDEN CAMS. Maximum Arrow 210 degrees Minimum 190 degrees Finished edge w i t r f a w i t r f a Finished edge w i t r f a Finished edge www.sauder.com/services 414720 Page 13...
  • Page 14 Fasten the BOTTOM (H) to the LOWER UPRIGHT (F). Use å two BLACK 1-7/8" FLAT HEAD SCREWS (2S) Minimum 190 degrees These holes must be here. r f a w i t BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Page 14 414720 www.sauder.com/services...
  • Page 15 BLACK 9/16" LARGE HEAD SCREWS (1S). (8 used) NOTE: Be sure the edges of the ANGLE BRACKETS are å even with the edges of the ENDS, BOTTOM, and BRACE. BLACK 9/16" LARGE HEAD SCREW (8 used in this step) www.sauder.com/services 414720 Page 15...
  • Page 16 Carefully turn your unit over onto its front edges. å Fasten the BRACE (K) to the LOWER ENDS (C and D) å and BOTTOM (H). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (4 used in this step) Page 16 414720 www.sauder.com/services...
  • Page 17 SHELF (I). NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. NAIL (46 used in this step) These holes must line up over the SHELF (I). www.sauder.com/services 414720 Page 17...
  • Page 18 D). Use four BROWN 1" FLAT HEAD SCREWS (12S). Unfi nished surface Unfi nished edge Finished surface BLACK 9/16" LARGE HEAD SCREW (4 used for the BRACKETS) Unfi nished edge BROWN 1" FLAT HEAD SCREW (4 used for the SIDE BASES) Page 18 414720 www.sauder.com/services...
  • Page 19 Push the RUBBER SLEEVES (2R) over the METAL PINS (1R). å Insert the METAL PINS into the holes in the ENDS (A, B, C and D) and UPRIGHTS (E and F). These are used for door stops when the DOORS are open. (8 used) www.sauder.com/services 414720 Page 19...
  • Page 20 BLACK 9/16" LARGE HEAD SCREWS (1S). Repeat this step for the other DOORS. å BLACK 9/16" LARGE HEAD SCREW (8 used for the DOOR HANGERS) (8 used) GOLD 1" MACHINE SCREW (8 used for the PULLS) Page 20 414720 www.sauder.com/services...
  • Page 21 Repeat this step to hang the remaining DOORS. å After the door is in the BROWN 7/16" LARGE HEAD SCREW unit horizontally, swing (4 used for the DOOR SLIDES) the DOOR SLIDE up and fasten it with the remaining BROWN 7/16" SCREW (6S). www.sauder.com/services 414720 Page 21...
  • Page 22 Refer to instruction book for complete safety information. Note: This is a permanent label. Do not try to remove. Surface will be damaged. 50 lbs. 08/05 2 6 9 2 2 0 269220 50 lbs. total 50 lbs. total Page 22 414720 www.sauder.com/services...
  • Page 23 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 EXCENTRIQUE ESCAMOTABLE ....16 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 CHEVILLE D'EXCENTRIQUE ......12 en ce qui concerne cet EXTRÉMITÉ DROITE INFÉRIEURE ....1 VIS D'EXCENTRIQUE ..........4 élément, faire référence...
  • Page 24 ! VIS TÊTE PLATE 28 mm ARGENT (10S). • Cette unité Sauder est conçue pour les téléviseurs pesant moins REMARQUE : Ne pas trop serrer les VIS dans le DESSUS. de 22,6 kg. Ne jamais utiliser avec des téléviseurs plus lourds.
  • Page 25 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 414720 Page 25...
  • Page 26 19F CONECTOR DE MOLDURA ........2 et conserver le livret pour future référence. EXTREMO IZQUIERDO ..........1 40G GANCHO PARA PUERTA ........8 Pour contacter Sauder EXTREMO DERECHO INFERIOR .....1 TOPE DE PUERTA ............4 en ce qui concerne cet EXTREMO IZQUIERDO INFERIOR ....1 70K TIRADOR ................4...
  • Page 27 - antes de comenzar el ensamblaje! NOTA: No apriete en exceso los TORNILLOS en el PANEL SUPERIOR. • Esta unidad Sauder está diseñada para ser usada con televisores cuyo peso sea inferior a 22,6 Kg. Nunca la use para un PASO 6 televisor de mayor peso.
  • Page 28 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 28 414720 www.sauder.com/services...
  • Page 29 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/services 414720 Page 29...
  • Page 30 SIEMPRE descargue los estantes y cajones, empezando con las superfi cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 30 414720 www.sauder.com/services...
  • Page 31 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
