sauder.com
Entertainment Credenza
Barrister Lane Collection | 416798
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Your center of
attention.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-21
Français pg 22-24
Español pg 25-28
Lot # 362200
06/04/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Barrister Lane 416798 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Barrister Lane 416798

Summary of Contents for Sauder Barrister Lane 416798

  • Page 1 Barrister Lane Collection | 416798 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.

  • Page 3: Part Identification

    LARGE SHELF MOLDING (1) RIGHT UPRIGHT (1) DOOR (1) SMALL SHELF MOLDING (2) LEFT UPRIGHT (1) LARGE ADJUSTABLE SHELF (1) END MOLDING (4) TOP (1) SMALL ADJUSTABLE SHELF (2) CATCH BRACE (1) BOTTOM (1) BASE (1) www.sauder.com/services 416798 Page 3...

  • Page 4: Hardware Identification

    (Refer to the last step for proper location and application) DECORATIVE DECORATIVE SAFETY STOP - 1 NAIL - 48 POST - 2 BACKPLATE - 1 RUBBER SLEEVE - 12 METAL PIN - 12 CAM COVER - 12 Page 4 416798 www.sauder.com/services...
  • Page 5 BLACK 1-7/8" FLAT HEAD SCREW - 4 BLACK 1/2" FLAT HEAD SCREW - 2 15S SILVER 5/8" MACHINE SCREW -2 BLACK 9/16" PAN HEAD SCREW - 2 SILVER 3/4" MACHINE SCREW - 2 SILVER 1-1/2" MACHINE SCREW - 1 www.sauder.com/services 416798 Page 5...

  • Page 6: Hidden Cam

    Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push twenty-six HIDDEN CAMS (1F) into the ENDS (A and B), å...
  • Page 7 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 416798 Page 7...
  • Page 8 BOTTOM and TOP MOLDING. Fasten the CORNER BRACKETS (31G) to the BOTTOM (F). Use å four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (13 used in this step) Flat surface Page 8 416798 www.sauder.com/services...
  • Page 9 BACK fastened. The unit may collapse. Long fi nished edge i t h f a c S u r D E N H I D r f a w i t l e s Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 416798 Page 9...
  • Page 10 S u r D E N H I D i t h o f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees Page 10 416798 www.sauder.com/services...
  • Page 11 (2 used in this step) Edge with BRACKETS S u r f a c H I D D E N i t h BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 416798 Page 11...
  • Page 12 (2 used in this step) i t h o f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees BLACK 9/16" LARGE HEAD SCREW (2 used in this step) Page 12 416798 www.sauder.com/services...
  • Page 13 (6 used in this step) Tighten two HIDDEN CAMS. You may need to loosen Surface with the HIDDEN CAMS in HIDDEN CAMS the END MOLDINGS (P). Then, retighten them. Curved edge Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 416798 Page 13...
  • Page 14 Fasten the BASE (L) to the ENDS (A and B) and BOTTOM (F). å Use seven BLACK 9/16" LARGE HEAD SCREWS (1S) through the BRACKETS and into the BASE. BLACK 9/16" LARGE HEAD SCREW (7 used in this step) Curved edge Page 14 416798 www.sauder.com/services...
  • Page 15 BACK. Carefully cut out the holes needed. NAIL (48 used in this step) Push the FEET (23E) into the holes in the BOTTOM (F). å These holes must line up over the UPRIGHTS (C and D). www.sauder.com/services 416798 Page 15...
  • Page 16 Fasten the MAGNETIC CATCH (12I) to the CATCH BRACE (Q). å Use two BLACK 9/16" PAN HEAD SCREWS (51S). NOTE: The MAGNETIC CATCH (12I) goes on the å right side with DOOR (H). BLACK 9/16" PAN HEAD SCREW (2 used for the MAGNETIC CATCH) Page 16 416798 www.sauder.com/services...
  • Page 17 Fasten the HINGES (27H) to the DOORS (H and I). Use eight å BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: The HINGES should be positioned exactly as shown. å BLACK 9/16" LARGE HEAD SCREW (8 used in this step) www.sauder.com/services 416798 Page 17...
  • Page 18 BLACK 1/2" FLAT HEAD SCREWS (11S). SILVER 5/8" MACHINE SCREW (2 used for the DECORATIVE ENDS) SILVER 1-1/2" MACHINE SCREW BLACK 9/16" LARGE HEAD SCREW (1 used for the KNOB and BACKPLATE) (8 used for the HINGES) Page 18 416798 www.sauder.com/services...
  • Page 19 Step Step 14 Slide the SHELF MOLDINGS (N and O) onto the notched å edges of the ADJUSTABLE SHELVES (J and K). *U.S. Patent No. 5,499,886 å Notched edge Notched edge Notched edge www.sauder.com/services 416798 Page 19...
  • Page 20 - The TV must weigh less than 95 lbs. - The base of the TV must be able to sit completely on this shelf. 95 lbs. 30 lbs. 25 lbs. 60 lbs. total 25 lbs. (12 used) Page 20 416798 www.sauder.com/services...

  • Page 21: Liste De Pièces

    EXTRÉMITÉ DROITE ..........1 23E PIED ..................2 pour future référence. EXCENTRIQUE ESCAMOTABLE ....26 EXTRÉMITÉ GAUCHE ..........1 Pour contacter Sauder CHEVILLE D'EXCENTRIQUE ......26 MONTANT DROIT ............1 en ce qui concerne cet CONSOLE EN MÉTAL ..........9 élément, faire référence MONTANT GAUCHE ..........1...
  • Page 22 ! ÉTAPE 5 • Cette unité Sauder est conçue pour les téléviseurs pesant moins de 43 kg. Ne jamais utiliser avec des téléviseurs plus lourds. Fixer les MONTANTS (C et D) au DESSUS (E). Serrer quatre •...
  • Page 23 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. www.sauder.com/services 416798 Page 23...

  • Page 24: Lista De Partes

    AGARRADOR MAGNÉTICO PEQUEÑO ..1 et conserver le livret pour future référence. EXTREMO IZQUIERDO ............1 PLACA DE CONTACTO .........2 Pour contacter Sauder PARAL DERECHO ..............1 AGARRADOR MAGNÉTICO ........1 en ce qui concerne cet PARAL IZQUIERDO ..............1 69K POMO ...................1 élément, faire référence...

  • Page 25: Excéntrico Escondido

    Para apretar completamente, atornille el excéntrico abajo - antes de comenzar el ensamblaje! escondido 210 grados. • Esta unidad Sauder está diseñada para ser usada con televisores cuyo peso sea inferior a 43 Kg. Nunca la use para un PASO 3 televisor de mayor peso.
  • Page 26 CABEZA GRANDE de 14 mm (1S) a través de la MÉNSULA DE ESQUINA y en el EXTREMO DERECHO. Fije la MOLDURA DE TOPE (36M) al PANEL SUPERIOR (E). Utilice dos TORNILLOS PLATEADOS PARA METAL de 19 mm (20S). Page 26 416798 www.sauder.com/services...
  • Page 27 PARALES (C y D). NOTA: Hay perforaciones provistas para el acceso a través del DORSO. Cuidadosamente corte los agujeros necesarios. Inserte las PATAS (23E) en los agujeros del FONDO (F). www.sauder.com/services 416798 Page 27...
  • Page 28 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 28 416798 www.sauder.com/services...
  • Page 29 équipé. • Blessure physique. Le mobilier peut être très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 416798 Page 29...
  • Page 30 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 30 416798 www.sauder.com/services...

  • Page 31: Year Limited Warranty

    GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
