Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Item
Weight Capacity
Maximum Height
Minimum Height
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2018 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
64264
3 Tons (6,000 lb.)
19-5/8"
3-1/8"
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
18f
Advertisement
Table of Contents
Related Manuals for Pittsburgh Automotive 64264
Summary of Contents for Pittsburgh Automotive 64264
- Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. Item 64264 Weight Capacity 3 Tons (6,000 lb.) Maximum Height 19-5/8"...
- Page 2 Thoroughly test the Jack for proper operation. 13. Lower load slowly. If it does not work properly, bleed air from its hydraulic system as stated on page 4. SaVE tHESE InStructIOnS. Page 2 For technical questions, please call 1-888-866-5797. Item 64264...
- Page 3 Saddle Oil Fill Screw (Not Shown) Lifting Arm Handle Socket U-Joint Safety Valve Cover Rear Caster DO NOT OPEN OR ADJUST U-Joint (Not Shown) Fill Screw Hydraulic Unit Figure a Item 64264 For technical questions, please call 1-888-866-5797. Page 3...
- Page 4 2. Add high grade hydraulic fluid into the Fill Screw slowly until the oil reaches the top of the oil fill hole. 3. Replace the Fill Screw. Page 4 For technical questions, please call 1-888-866-5797. Item 64264...
- Page 5 5. To prevent accidents, turn off the tool and disconnect its power supply after use. Clean, then store the tool indoors out of children’s reach. Item 64264 For technical questions, please call 1-888-866-5797. Page 5...
- Page 6 Jack may be low on oil. Check the oil level and refill if needed. Jack may require bleeding - see instructions on page Bleeding on page 4. Unit may have too much hydraulic oil inside, check fluid level and adjust if needed. Page 6 For technical questions, please call 1-888-866-5797. Item 64264...
- Page 7 If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Item 64264 For technical questions, please call 1-888-866-5797. Page 7...
- Page 8 pLEaSE rEaD tHE FOLLOWInG carEFuLLy THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
