Page 2: Table Of Contents
Cluttered benches and dark areas increase the while operating the tool. Distractions are able risks of electric shock, fire, and injury to persons. to result in the loss of control of the tool. Page 2 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553... -
Page 3: Safety
3. Use only the lubricants supplied with the tool or specified by the manufacturer. by qualified repair personnel. 2. When servicing a tool, use only identical replacement parts. Use only authorized parts. Item 69593/69642/95553 For technical questions, please call 1-800-444-3353. Page 3... - Page 4 Cubic Feet per Minute flow Risk of Respiratory Injury. Wear NIOSH-approved dust mask/respirator. Cubic Feet per Minute flow ScFM at standard conditions WARNING marking concerning Risk of Explosion. National pipe thread, tapered Page 4 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553...
- Page 5 19. Use this tool with both hands only. Using tools with only one hand can result in loss of control. SAVE THESE INSTRUcTIONS. Item 69593/69642/95553 For technical questions, please call 1-800-444-3353. Page 5...
- Page 6 Screw Extension (inside Ram) Handle Bracket Throttle Jack Handle Lever Air Inlet Release Valve Screw Extension (inside Ram) Handle Bracket Jack Handle Release Valve Throttle Lever Air Inlet Figure A Page 6 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553...
- Page 7 1. Place the slotted end of the Jack Handle over the Release Valve and turn 1-1/2 turns counterclockwise. 5. Top off Jack Reservoir with a high quality hydraulic jack oil. Item 69593/69642/95553 For technical questions, please call 1-800-444-3353. Page 7...
- Page 8 Page 8 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553...
- Page 9 Item 69593/69642/95553 For technical questions, please call 1-800-444-3353. Page 9...
-
Page 10: Setup
The air hose must be long enough to reach the work area with enough extra length to allow free movement while working. Page 10 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553... -
Page 11: Operation
Bracket and pump up and down. Clean external surfaces of the tool with clean, dry cloth, and apply a thin coat of tool oil. Then store the tool indoors out of children's reach. Item 69593/69642/95553 For technical questions, please call 1-800-444-3353. Page 11... -
Page 12: Maintenance
4. Periodically check the air and hydraulic fittings for leaks. Repair if any leak is detected. 5. Periodically lubricate all moving points of the Jack. Page 12 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553... - Page 13 Check the oil level and refill if needed. Jack may require bleeding - see Purging Air From Hydraulic System on page 7. Unit may have too much hydraulic oil inside, check fluid level and adjust if needed. Item 69593/69642/95553 For technical questions, please call 1-800-444-3353. Page 13...
-
Page 14: Parts List And Diagram
Lock Washer Screw Cylinder Washer Plastic Cup O-Ring Pump Cylinder Air Motor Cup Seal O-Ring Air Hose Nylon Ring Air Valve 13.1 Extension Screw Backup Ring Handle Packing Piston Reservoir Page 14 For technical questions, please call 1-800-444-3353. Item 69593/69642/95553... - Page 15 List and Assembly Diagram for Items #69593 and #69642 part Description part Description part Description Hose Connector Plunger Overload Valve Connecting Nut Shaft Pin Filter Net Air Filter Cotter Pin Spring Washer 8 "O"Ring 18×2.4 Pump Plunger Nut 8...
-
