OWNER'S MANUAL
TRINITY CHROME SWIVEL STOOL
Model # TWE-1101 / TWE-11012
FOR 3D ASSEMBLY INSTRUCTIONS
Intelligent Instructions
Directives intelligentes
Instrucciones Inteligentes
Advertisement
Related Manuals for Trinity TWE-11012
Summary of Contents for Trinity TWE-11012
- Page 1 OWNER’S MANUAL TRINITY CHROME SWIVEL STOOL Model # TWE-1101 / TWE-11012 Important / Important / Importante FOR 3D ASSEMBLY INSTRUCTIONS Intelligent Instructions Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA...
-
Page 2: Parts List
Your TRINITY Chrome Swivel Stool should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be requested online via our “Contact Us”... - Page 3 PARTS LIST SPACER (4) SEAT (1) SEAT RING (1) 3/16" * 1/2" SCREW (4) 1/4" * 3/4" HEX KEY (1) WRENCH (1) SCREW (4) © 2023 TRINITY - 800.985.5506...
- Page 4 Place SMALL RIGN (F) to inside of legs. Align holes on SMALL RING (F) with holes on legs, tighten with SCREW (G) from inside. Hand tighten ALL SCREWS first to ensure easy of alignment. Fully tighten ALL SCREWS with HEX KEY. © 2023 TRINITY - 800.985.5506...
- Page 5 SEAT RING (O) with white dots on SEAT (N). Lay SEAT (N) on ground and attach legs while stool is upside down. Attach BASE PLATE (K) to SEAT (N) with SCREW (Q). Ensure all screws are tightened. © 2023 TRINITY - 800.985.5506...
- Page 6 SERVICE PARTS LIST – TWE-1101 / TWE-11012 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-25-001-0002 Stool Seat CSV-25-002-0005 Small Ring CSV-25-001-0003 Seat Ring CSV-25-002-0004 Large Ring CSV-25-002-0002 Stool Leg ZSV-02-013-0001 Base Plate CSV-25-002-0003...
-
Page 7: Care And Maintenance
Do not use metal scouring pad for cleaning. Most stains can be removed by using a mild soap and a soft-bristled brush. • Avoid placing any direct heat source on or near seat. • This product is designed for indoor use only. Outdoor use is not recommended. © 2023 TRINITY - 800.985.5506... - Page 8 © 2023 TRINITY - 800.985.5506...
-
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY Chrome Swivel Stool. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 10 © 2023 TRINITY - 800.985.5506...
-
Page 11: Year Limited Warranty
Product, use contrary to this User’s Manual, or alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is limited in duration to one year from the date of purchase and is subject to the same conditions and limitations as is provided for our express warranty. - Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM –...
