- Page 1 L−force Drives EDK84VTCE453 .Q1\ Montageanleitung Mounting Instructions Instructions de montage Instrucciones para el montaje Istruzioni per il montaggio 8400 30 ... 45 kW E84AVTCExxxx TopLine C Frequency Inverter...
- Page 2 Warnings! Operation of this equipment requires detailed installation and operation instructions provided in the Hardware manual intended for use with this product. This information is provided on the CD−ROM included in the container this device was packaged in. It should be retained with this device at all times. A hard copy of this information may be ordered by phone or e−mail, printed on the back of this document.
- Page 3 Danger! Dangerous voltage The power terminals X100 and X105 carry dangerous voltages for up to 3 minutes ƒ after mains disconnection. Possible consequences: Death or severe injury if the power terminals are touched. ƒ Protective measures: Switch off the mains voltage and wait at least 3 minutes before starting to work on ƒ...
- Page 4 y de seguridad incluida en el CD−ROM adjunto! Pericolo! Tensione elettrica pericolosa I collegamenti di potenza X100 e X105 presentano una tensione elettrica pericolosa ƒ fino a 3 minuti dopo la disinserzione della rete. Possibili conseguenze: Morte o gravi lesioni in caso di contatto con i collegamenti di potenza. ƒ...
- Page 5 30 ... 45 kW 30 ... 45 kW 8400TLC021 EDK84VTCE453 ZH/EN 2.4...
- Page 6 30 ... 45 kW 30 ... 45 kW 8400TLC022 EDK84VTCE453 ZH/EN 2.4...
- Page 7 30 ... 45 kW [mm] 30 ... 45 kW [mm] 8400GG108f [kW] [mm] E84AVTCE3034xXx E84AVTCE3734xXx E84AVTCE4534xXx E84AVTCE3034xBx E84AVTCE3734xBx E84AVTCE4534xBx EDK84VTCE453 ZH/EN 2.4...
- Page 8 30 ... 45 kW [mm] 8400GG108d [kW] [mm] [kg] E84AVTCE3034xXx E84AVTCE3734xXx > 95 > 120 17.4 E84AVTCE4534xXx E84AVTCE3034xBx E84AVTCE3734xBx > 95 > 120 17.5 E84AVTCE4534xBx EDK84VTCE453 ZH/EN 2.4...
- Page 9 30 ... 45 kW X100 (400 V) 30 ... 45 kW X100 (400 V) X100 − TN, TT 3/N/PE AC 400 V / 500 V F1 … F3 +UG -UG X100 8400GG090a 8400GG007 X100 − IT 3/N/PE AC 400 V / 500 V F1 …...
- Page 10 30 ... 45 kW X101 30 ... 45 kW X101 X101 X101 8400GG090c 8400GG010 COM, NC, NO [mm] [AWG] E84AVTCE3034 0.2 ... 1.5 E84AVTCE3734 24 ... 16 E84AVTCE4534 EDK84VTCE453 ZH/EN 2.4...
- Page 11 30 ... 45 kW X105, X106 30 ... 45 kW X105, X106 8400GG093 X105 X106 84MOTL001_a 84MOTL001_b U, V, W T1, T2 [mm] [Nm] [mm] [Nm] [mm] [AWG] [lb−in] [AWG] [lb−in] [AWG] E84AVTCE3034 16 ... 50 2.5 ... 25 0.2 ... 1.5 E84AVTCE3734 6 ...
- Page 12 30 ... 45 kW X105 30 ... 45 kW X105 X105 − TN, TT " X105 J> 8400GG094a 8400GG013 X105 − IT " X105 J> 8400GG094b 8400GG013 EDK84VTCE453 ZH/EN 2.4...
- Page 13 30 ... 45 kW X106 30 ... 45 kW X106 X106 " X106 T1 T2 J> 8400GG094c 8400GG017 EDK84VTCE453 ZH/EN 2.4...
- Page 14 E84A...xxBx E84A...xxBx 8400TLC018 [mm] [AWG] 0.2 ... 1.5 24 ... 16 84MOTL001_g DC 24 V (+19.2... +28.8 V) 8400TLC017 8400HLC045 EDK84VTCE453 ZH/EN 2.4...
- Page 15 TopLine X1, X3, X4, X5, X10, X107 TopLine X1, X3, X4, X5, X10, X107 8400TLC013 X1, X10 X3, X107 X4, X5 84MOTL001_e 84MOTL001_d 84MOTL001_f X4, X5 X107 min. max. min. max. min. max. min. max. [mm] [mm] [AWG] [mm] [mm] [AWG] [AWG] [mm]...
- Page 16 TopLine X1, X3 X1, X3 c b a 64 32 16 8 4 2 1 Baud CAN Adress EDS84AVxxxx 120Ω CAN-High CAN-Low CAN-Ground " " " 8400TLC002b 8400TLC008 GND-A +10 V / 10 mA " 0 ...10 V 1k ... 10k 8400TLC002c 8400HLC012 EDK84VTCE453 ZH/EN 2.4...
- Page 17 TopLine X4, X5 X4, X5 GND-O DC 24 V (+19.2...+28.8 V) 8400TLC002f 8400HLC045 GND-I 24 V int. DC 24 V (+19.2... +28.8 V) 8400TLC002h 8400HLC045 EDK84VTCE453 ZH/EN 2.4...
- Page 18 TopLine X7, X8 X7, X8 +Ref -Ref +Cos -Cos +Sin -Sin +KTY -KTY 8400TLC002k SSP94RESX7 Hiper- face RefCos RefSin +RS485 Data+ -RS485 Data- Clock- Clock- Clock+ -KTY -KTY +KTY +KTY 8400TLC002m SSP94ENCX8 EDK84VTCE453 ZH/EN 2.4...
- Page 19 TopLine X10, X107 X10, X107 EDS84AVxxxx 120Ω Sync/State CAN-High CAN-Low CAN-Ground " " " 8400TLC002o 8400TLC009 X107 X107 " DC 24 V (+19.2...+28.8 V) 8400TLC002q 8400HLC045 EDK84VTCE453 ZH/EN 2.4...
- Page 20 ã K Q © 05/2020 Lenze Drives GmbH Service Lenze Service GmbH Postfach 10 13 52, D−31763 Hameln Breslauer Straße 3, D−32699 Extertal Breslauer Straße 3, D−32699 Extertal Germany Germany +49 5154 82−0 008000 2446877 (24 h helpline) Ê Ê...
