Summary of Contents for Omlet eglu cube

  • Page 1 eglu eglu cube cube t-handle lock t-handle lock...
  • Page 2 United Kingdom 01295 500900 United States 646-434-1104 Australia 02 8103 4124 Ireland 01 513 7973 Deutschland 0451 8118 9058 Austria 03 720 115240 France 04 11 92 12 80 Nederland 085 888 3571 Belgium FR 02 2 808 85 07 Belgium NL 02 9 298 04 69 Switzerland DE...
  • Page 3 www.omlet.com.pl...
  • Page 4 You will need... 2 - 3 mm 5/64, 3/32, 7/64 ”...
  • Page 5 What you have received 064.0164: T-Handle Lock T-Handle Lock Body 810.0439 064.0162: T-Handle Lock Fixings Pack T-Handle Lock T-Handle Lock Self Tapping Screw Screw Cap L Screw Cap R 4x8mm 810.0443 810.0444 800.0184...
  • Page 6 Before you start, remove all panels with T-handles from the Eglu Cube and place them face up on a flat, stable surface. Repeat each step on both of the Eglu Cube panels.
  • Page 8 810.0439...
  • Page 10 Repeat on other side...
  • Page 14 2 - 3 mm 5/64, 3/32, 7/64 ” Drill through the first surface only and not through the back of the panel...
  • Page 19 Do not overtighten 800.0184...
  • Page 20 810.0443 810.0444...
  • Page 21 To lock the T-Handle, turn it to its horizontal position and ensure the push button springs up.
  • Page 22 To unlock the T-handle, push the button and twist the handle at the same time.
  • Page 24 That’s it! You can now reattach the panels to your Eglu Cube.
  • Page 26 If you need to remove the lock, use a flat head screwdriver to lift out the screw caps (810.0443 + 810.0444).
  • Page 28 Please Reuse, Compost, Recycle. © Copyright Omlet Ltd. 2023 Design Registered, Patent Pending Omlet is a Registered Trademark of Hebe Studio Ltd. 820.2308_Instruction Manual T-Handle Lock _ 23/02/2023...
