Summary of Contents for Aspes AEI1401X
- Page 1 USER MANUAL MODEL: AEI1401X...
-
Page 2: Instructions For The Installation
INSTRUCTIONS FOR THE INSTALLATION... -
Page 3: Cleaning And Maintenance
User’s instructions Igniting the burners In these models the knob controls both ignition and the safety device. Proceed as follows to ignite the burners: 1) Turn the chosen knob. 2) Keep the knob strongly pressed in for 3/4 seconds to permit the spark to light the gas that exits from the flametamer and to permit the thermocouple to heat up. -
Page 4: Enamelled Parts
etc.)on the surfaces. Avoid using acid or chlorine-based cleaning products. ENAMELLED PARTS All of the enamelled parts must be washed only with a sponge and soapy water or with non-abrasive products. BURNERS AND GRIDS These parts can be removed and cleaned with appropriate products. -
Page 5: General Advice
GENERAL ADVICE √When the appliance is not being used, it is advisable to keep the gas tap closed. √If the gas tap becomes stiff,it is necessary to dismount it accurately ,clean it with gasoline and spread a bit of special grease resistant to high temperatures on it.This operation must be executed by a qualified technician. - Page 6 Advice for the Installer...
-
Page 7: Installation
IMPORTANT √The appliance should be installed, regulated and adapted to function with other types of gas by a QUALIFIED INSTALLATION TECHNICIAN. Failure to comply with this condition will render the guarantee invalid. √The appliance must be installed in compliance with regulations in force. - Page 8 INSTALLATION IN KITCHEN CABINET WITH DOOR (fig.13) The fixture has to be made according to specific requirements in order to prevent the gas burners from going out,even when the flame is turned down to minimum, due to pressure changes while opening or closing the cupboard doors.
- Page 9 SETTLING THE HOB FOR INSTALLATION Every cooker top is provided with a set of tabs for fitting to the unit with thickness from 3 to 4 cm and a seal with adhesive on one side. -Remove burners and grids. -Turn the cooker top over and rest the glass side on a cloth. -Apply the self-adhesive seal “G”...
- Page 10 壹NSTALLATION ROOM The room where the gas appliance is to be installer must have a natural flow of air so that the gas can burn. The flow of air must come directly from one or more openings made in the out-side walls with a free area of at least 100c㎡. If the appliance does not have a no-flame safety device this opening must have an area of at least 200c㎡.
-
Page 11: Gas Section
GAS SECTION TYPES OF GASES The gases normally used may be grouped, in view of their features ,in three families: -L.P.G.(in cylinders) -NATURAL GAS(methane) -CITY GAS G110 INSTALLATION The appliance is predisposed and adjusted to operate with the gas indicated on the specifications plate applied onto the appliance. - Page 12 √1 adapter “B”for natural or city gas √1adapter“C”for L.P.G. √gaskets “D”,“E”and“F” The hob must be installed in a room with adequate ventilation(see page 13). Gas connection for: Natural gas (G20)or city gas (G110) √Remove the adapter“C”using two spanners. √Connect the cooking hob to the gas net by a suitable rubber tube(inside diameter 13 mm).
- Page 13 √Never attempt to turn the elbow “A”without having first slackened off the relative lock nipple. √The seals“D-E-F”(fig.18) are the elements that guarantees the seal in the gas connection. Is is recommended that they be replaced whenever they shows even the slightest deformation or imperfection. √After connecting to the mains, check that the couplings are correctly sealed, using soapy solution,but never a naked flame.
-
Page 14: Lubrication Of The Gas Taps
REGULATING THE BURNER MINIMUM SETTING When switching from one type of gas to another,the minimum flow rate must also be correct:the flame should not go out even when passing suddenly from maximum to minimum flame. To regulate the flame follow the instructions below: √Light the burner √Set the cock valve to minimum On gas valves provided with adjustment screw in the centre... - Page 15 Incorrect installation might cause harm and damage to people, animals or objects, for whiche the manufacturer accepts no responsibility. DETAILS √Connection to the electric power supply must be carried out by a qualified technician and following the appropriate safety regulations; √Before carrying out the connection to the power supply,the voltage rating of the appliance(stamped on the appliance identification plate)must be checked for correspondence to the...
-
Page 16: Replacing The Power Supply Cable
mains supply wiring system or if the power plug is not suitable for the type of power point available, it is recommended that a qualified technician be called to carry out substitution. The technician will also have to verify that the cross-section of the electric cables on the power point match the appliance’s power rating.
