3.2.5 Pressure process connection
MDM6000 With Display
Figure 11 (Gauge/Absolute)
MDM6000 With Display
Figure 13 (differential pressure)
MDM6000 Without Display
Figure 12 (Gauge /Absolute)
MDM6000 Without Display
Figure 14 (differential pressure)
5
Unit in mm
