HALO
®
Lampholder/Track Compatibility
L761
Halo Single and 2-Circuit
L762
L650, L651, L652, L653
L763
L641, L642, L643
L764
L611, L612, L613
L1631, L1632
294
COOPER LIGHTING
L 7 6 1
Finish:
Lamp:
M B
P
L 7 6 2
Finish:
Lamp:
Accessories: L1962 Barn Doors
M B
P
L 7 6 3
Finish:
Lamp:
Accessories: L1963 Barn Doors
M B
P
L 7 6 4
Finish:
Lamp:
Accessories: L1964 Barn Doors
M B
P
Halo 4-Circuit
Halo "LA" Architectural
L963 Converter required for
LA1L Converter required
use with Halo 4-Circuit:
for use with Halo "LA"
L621, L622, L623
Linear Architectural Track:
LA631, LA632, LA633
F l a t b a c k C y l i n d e r w i t h B a f f l e
White (P), Black (MB)
40W R16 (Halo Z9), 60W PAR16
BAFFLE
40W R16
60W PAR16
F l a t b a c k C y l i n d e r w i t h B a f f l e
White (P), Black (MB)
50W R20, 50W PAR20, 100W BR25 (Halo Z10)
50W R20
BARN DOORS
BAFFLE
100W BR25
AVAILABLE
F l a t b a c k C y l i n d e r w i t h B a f f l e
White (P), Black (MB), Bronze (BZ)
65W BR30, 75W R30, 75W PAR30,
100W BR25 (Halo Z10)
65W BR30
BARN DOORS
75W R30
BAFFLE
AVAILABLE
100W BR25
F l a t b a c k C y l i n d e r w i t h B a f f l e
White (P), Black (MB)
300W R40, 250W PAR38
BARN DOORS
300W R40
BAFFLE
AVAILABLE
Lazer Track
LZR102, LZR104,
LZR106, LZR108
5 1/4"
(135mm)
Max. Extension:
8 1/4" (210mm)
5 1/2"
(141mm)
Max. Extension:
7 1/2" (191mm)
50W PAR20
6 5/8"
(168mm)
Max. Extension:
8 3/4" (222mm)
75W PAR30
8"
(171mm)
Max. Extension:
250W PAR38
9 7/8" (251mm)
2 1/2"
(64mm)
3 3/4"
(95mm)
4 7/8"
(124mm)
5 7/8"
(149mm)
