Dometic CFF45 Operating Manual

Mobile refrigerating appliance
Hide thumbs Also See for CFF45:
Table of Contents

Advertisement

Quick Links

MOBILE COOLING
CFF
CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ
Mobile refrigerating appliance
EN
Operating manual

Advertisement

Table of Contents
loading

Related Manuals for Dometic CFF45

Summary of Contents for Dometic CFF45

  • Page 1 MOBILE COOLING CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Mobile refrigerating appliance Operating manual...
  • Page 2 © 2023 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or be patent pending. The trademarks mentioned in this manual belong to Dometic Sweden AB.

  • Page 3: Table Of Contents

    CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Explanation of symbols Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure that you install, use, and maintain the product properly at all times. These instructions MUST stay with this product.

  • Page 4: Safety Instructions

    Safety instructions CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ NOTICE! Indicates a situation that, if not avoided, can result in property damage. NOTE Supplementary information for operating the product. Safety instructions DANGER! Failure to obey these warnings will result in death or serious injury.
  • Page 5 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Safety instructions • Keep the ventilation openings on the device housing or in installations free of obstructions. • Do not use any mechanical objects or other means to speed up the defrosting process, unless they have been recommended by the man- ufacturer for this purpose.
  • Page 6 Safety instructions CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ • Clean regularly surfaces that can come in contact with food and accessible drainage systems. • If the device is left empty for long periods: – Switch off the device. – Defrost the device.

  • Page 7: Scope Of Delivery

    CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Scope of delivery Scope of delivery 12/24 V DC 12/24 V DC 100–240 V AC 100–240 V AC CFF12 CFF18 CFF20 CFF35, CFF45 CFF20, CFF35, CFF45, CFF70DZ CFF70DZ CFF12 Item in Quantity Description fig. 1, page 7...

  • Page 8: Intended Use

    Intended use CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Item in Quantity Description fig. 1, page 7 CFF20, CFF35, CFF45, CFF70DZ only: Carry handle set, consisting of: • 4 holders • 2 handles • 8 fastening screws • 1 Allen wrench CFF12 only: Shoulder strap –...
  • Page 9 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Intended use • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. Function description A low maintenance refrigerant circuit with compressor provides the cooling. The generous insulation and powerful compressor ensure efficient and fast cooling.
  • Page 10 Intended use CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Operating and display elements Lid latches (fig. 2, page 10) CFF12 CFF18 CFF20 CFF35, CFF45 CFF70DZ...
  • Page 11 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Intended use Operating panel (fig. 3, page 11) CFF12, CFF18 CFF20 ° CFF35, CFF45 ° CFF70DZ Item Description Explanation Switches the cooler on or off when the button is pressed for between one and two seconds Status indication POWER “...

  • Page 12: Operation

    Operation CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Item Description Explanation Selects the input mode – Temperature setting – Celsius or Fahrenheit display – Set battery monitor – Set brightness of display DOWN – Press once to decrease the value UP +...
  • Page 13 Before starting your new cooler for the first time, you should clean it inside and outside with a damp cloth for hygienic reasons (please also refer to the chapter “Cleaning and maintenance” on page 28). Mounting the handles ( CFF20, CFF35, CFF45, CFF70DZ only) (fig. 5, page 13) CFF20...
  • Page 14 Operation CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ The handles are enclosed unassembled. If you wish to attach the handles, proceed as follows: 1. Assemble a handle by putting two holders (1) and a handle (2) together. 2. Fasten the holders with the enclosed screws in the holes provided.
  • Page 15 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Operation 180°...
  • Page 16 Operation CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Opening or removing the lid (fig. 7, page 16) CFF12 CFF18 CFF20 CFF35, CFF45 CFF70DZ...
  • Page 17 ➤ To open the lid, unlatch (A). CFF35, CFF45: The lid can be opened from either side. ➤ CFF35, CFF45: To remove the lid, unlatch both sides at the same time (B). CFF12, CFF18, CFF20, CFF70DZ: To remove the lid, push the lid beyond the lid stop position (B).
  • Page 18 Removing the cup holder (CFF12 only) (fig. 9, page 18) CFF12 ➤ Lift the cup holder out to access a convenient storage area. Removing the basket (CFF35 & CFF45 only) and divider (CFF18 only)(fig. 0, page 19) NOTICE! Damage hazard Removing the basket with the lid open may scratch the lid and deform the basket.
  • Page 19 Temperature display units can be switched between Celsius and Fahrenheit as follows: 1. Switch on the cooler. 2. CFF12, CFF18, CFF20, CFF35, CFF45: Press the “SET” button (fig. 3 5, page 11) twice. CFF70DZ: Press the “SET” button (fig. 3 5, page 11) three times.
  • Page 20 Operation CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ • If the cooler has a basket: For optimal energy consumption, position the basket according to its position on delivery. • On a regular basis, make sure the lid seal still fits properly.
  • Page 21 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Operation Connecting to an AC power supply DANGER! Electrocution hazard Failure to obey these warnings will result in death or serious injury. • Never handle plugs and switches with wet hands or if you are stand- ing on a wet surface.
  • Page 22 1. Switch on the cooler. 2. Press the “SET” button (fig. 3 5, page 11): – CFF12, CFF18, CFF20, CFF35, CFF45: Three times. – CFF70DZ: Four times. 3. Use the “UP +” (fig. 3 7, page 11) or “DOWN –” (fig. 3 6, page 11) buttons to select the battery monitor mode.
  • Page 23 2. Press the latch (fig. 2, page 10) down, until it latches in place audibly. NOTE CFF35, CFF45: When latching the lid, ensure that both latch side pins are fully engaged to ensure a good lid seal. One latch may engage slightly before the other.
  • Page 24 Operation CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Fixing with a safety seat belt ➤ Proceed as shown (fig. b, page 24). Fixing with luggage tighteners ➤ Proceed as shown (fig. c, page 24). Setting the temperature CFF12, CFF18, CFF20, CFF35, CFF45 1.
  • Page 25 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Operation ✔ The cooling temperature appears in the display for a few seconds. The display flashes several times and then the current temperature is displayed again. CFF70DZ 1. Press the “SET” button (fig. 3 5, page 11): –...
  • Page 26 1. Switch on the cooler. 2. Press the “SET” button (fig. 3 5, page 11): – CFF12, CFF18, CFF20, CFF35, CFF45: Four times. – CFF70DZ: Five times. 3. Use the “UP +” (fig. 3 7, page 11) or “DOWN –” (fig. 3 6, page 11) buttons to set the brightness of the display.
  • Page 27 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Operation NOTICE! Damage hazard Never use hard or pointed tools to remove ice or to loosen objects which have frozen in place. To defrost the cooler, proceed as follows: 1. Take out the contents of the cooler.

  • Page 28: Cleaning And Maintenance

    Cleaning and maintenance CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ 5.14 Replacing the DC plug fuse ➤ Replace the DC plug fuse as shown in fig. d, page 28. 5.15 Replacing the light PCB NOTICE! Damage hazard The lamp can only be replaced by the manufacturer, a service agent or similarly qualified person to avoid hazard.

  • Page 29: Troubleshooting

    CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Troubleshooting ➤ Occasionally clean the cooling device interior and exterior with a damp cloth. ➤ Make sure that the air inlet and outlet vents on the device are free of any dust and dirt, so that heat can be released and the device is not damaged.
  • Page 30 “Err1”) and the appli- internal fault. ance does not cool. Lid past built-in stop (CFF35, CFF45 only) If the lid has been forced past the built-in stop, proceed as follows (fig. e, page 30): ➤ Support the lid with one hand (A).

  • Page 31: Warranty

    Warranty If the product does not work as it should, please contact your retailer or the manufacturer's branch in your country (see dometic.com/dealer). The warranty applicable to your product is 3 year(s). For repair and warranty processing, please include the following documents when you send in the device: •...

  • Page 32: Disposal

    Disposal CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Local support Please find local support at the following link address: dometic.com/dealer Disposal Recycling products with non-replaceable batteries, rechargeable batter- ies or light sources ➤ If the product contains any non-replaceable batteries, rechargeable batteries or light sources, you don't have to remove them before disposal.
  • Page 33 CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ Technical data CFF12 CFF18 CFF20 equivalent: 0.037 t 0.0286 t 0.040 t Global warming 1430 potential (GWP): Dimensions (W x H x D) (includ- – 510 x 525 x 300 mm 283 x 430 x 660 mm...
  • Page 34 Technical data CFF12, CFF18, CFF20, CFF35, CFF45, CFF70DZ NOTE If the ambient temperature is above +32 °C (+90 °F), the minimum temperature cannot be attained. Test/certificates: This product contains fluorinated greenhouse gases. The cooling unit is hermetically sealed.
