Del Medical EV200 Installation, Maintenance And Operation

Elevating table
Hide thumbs
Table of Contents

Advertisement

Quick Links

8000-8680R
EV200 ELEVATING TABLE
MODEL 8680R
THIS DOCUMENT CONTAINS
INSTALLATION, MAINTENANCE,
AND OPERATION INFORMATION
- DO NOT DISCARD -
Del Medical Imaging Corporation
11550 W. King Street
Franklin Park, IL 60131
Tel: 847-288-7000
Fax: 847-288-7010
Email: tech_support@delmedical.com
Manual Part Number 8000-8680R
Revision D
June 28, 2002
©Del Medical Imaging
June 28, 2002
page i of 31 pages

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Del Medical EV200

Summary of Contents for Del Medical EV200

  • Page 1 8000-8680R EV200 ELEVATING TABLE MODEL 8680R THIS DOCUMENT CONTAINS INSTALLATION, MAINTENANCE, AND OPERATION INFORMATION - DO NOT DISCARD - Del Medical Imaging Corporation 11550 W. King Street Franklin Park, IL 60131 Tel: 847-288-7000 Fax: 847-288-7010 Email: tech_support@delmedical.com Manual Part Number 8000-8680R...
  • Page 2 MANUAL IMPROVEMENT RECOMMENDATION We at Del Medical Imaging Corporation are most interested in improving the quality of the Technical Documentation we provide. Please identify any improvements or corrections and fax them to our Technical Publications Department. Name________________________________________________ Dealership____________________________________________ Manual Part Number____________________________________...
  • Page 3 Manual Revision History Manual Part Number: 8000-8680 Revision Date Description of Changes 10/1/92 7/29/93 Addition of collision sensor assembly, schematic update, document 6/28/02 revised and converted to standardized manual format ©Del Medical Imaging June 28, 2002 page iii of 31 pages...

  • Page 4: Table Of Contents

    EV200 Elevating Table Revision D Table of Contents Table of Contents INTRODUCTION ......................5 SAFE OPERATION ......................5 DESCRIPTION........................5 BRH COMPLIANCE......................6 OPERATION........................7 SAFETY ..........................7 TABLE CONTROLS ......................7 FOOT PEDAL SYMBOLS AND FUNCTIONS..............7 REQUIRED PREVENTATIVE MAINTENANCE ...............9 USER SERVICE AND MAINTENANCE ................9 PRE INSTALLATION ....................10 GENERAL SAFETY PROCEDURES ................10...

  • Page 5: Introduction

    While this table has been designed for safe operation, improper or careless operation can result in an unsafe condition. Del Medical Imaging Corporation or its agents and representatives assume no responsibility for: 1.

  • Page 6: Brh Compliance

    EV200 Elevating Table Revision D Introduction The table top is a four - way float top, providing 43.5 inches (110.5 cm) of longitudinal travel and 9.5 inches (24.1 cm) of transverse travel. Electric locks maintain the desired position. Locks are released and the table is raised and lowered by easily identified foot pedals.

  • Page 7: Operation

    EV200 Elevating Table Revision D Operation OPERATION SAFETY 1. Table power must be ON before permitting a patient to either get on or off the table. The table locks will not operate without power. 2. Extreme care must be taken during the changing of the table height to insure that both the patient and operator are clear of tubestand equipment and areas around the Bucky.
  • Page 8 EV200 Elevating Table Revision D Operation configuration of the system. This switch is preset at the factory and will need to be repositioned at the time of installation. To continue downward movement beyond the exposure position, release switch pedal and then depress it again.

  • Page 9: Required Preventative Maintenance

    It is the owner's responsibility to arrange for this required service. Maintenance procedures for the EV200 are required within 30 days after completion of the installation and every 6 months thereafter. Safe equipment performance also requires the use of service personnel who are specifically trained and experienced with medical x-ray apparatus.

  • Page 10: Pre Installation

    EV200 Elevating Table Revision D Pre Installation PRE INSTALLATION GENERAL SAFETY PROCEDURES During installation it is important that all protective ground wire connections provided by the manufacturer are properly made before the equipment is started up. Regulations of professional associations concerning safety and accident prevention must be observed.

  • Page 11: Component Designations

    EV200 Elevating Table Revision D Pre Installation COMPONENT DESIGNATIONS Tabletop Inner Frame and Supports Upper Frame and Cover Lower Frame and Cover Carriage and Bucky Foot Treadle / Pedals ©Del Medical Imaging June 7, 2002 page 11 of 31 pages...

  • Page 12: Selecting Equipment Location

    EV200 Elevating Table Revision D Pre Installation SELECTING EQUIPMENT LOCATION ©Del Medical Imaging June 7, 2002 page 12 of 31 pages...

  • Page 13: Mains Connection Data

    Mains Connection Capacity: 0.7 kVA The EV200 is available in either 120 VAC, 60 Hz, or 240 VAC, 50 Hz configurations. This configuration must be specified when the table is ordered. For 120 VAC operation, the EV200 must be supplied with 20 Ampere service, on a dedicated line.

  • Page 14: Installation

    4. Before raising the table, ensure that the chain has not shifted during shipment, and that the retaining clip is properly installed. If you have any doubt about the integrity of the chain or retaining clip, do not attempt a repair. Contact Del Medical Imaging Tech Support for assistance.
  • Page 15 EV200 Elevating Table Revision D Installation 5. Plug in the 120 VAC line cord (which has been left in the table for set-up purposes). Press the "UP" pedal, raising the table top until there is sufficient clearance to allow for removing the pallet mounting screws.
  • Page 16 EV200 Elevating Table Revision D Installation 11. Connector J106 has been provided for interconnections to the FMTS Tubestand. This connector will provide power, collimator information, and optional Tomography control to the tubestand. When utilizing this connector, ensure that the table and tubestand are wired for the same incoming line voltage before plugging in the P106 connector.
  • Page 17 EV200 Elevating Table Revision D Installation 13. Install the optional PBL bracket at the rear of the Bucky, as shown in the illustration below: ©Del Medical Imaging June 7, 2002 page 17 of 31 pages...
  • Page 18 EV200 Elevating Table Revision D Installation After mounting the bracket, insert the cassette tray into the Bucky to verify that the PBL receptacle and the tray sensing stud are in proper alignment. If necessary, the receptacle and the stud can be relocated to one of the other sets of punched holes in the bracket.
  • Page 19 EV200 Elevating Table Revision D Installation 15. Attach the optional continuous vertical SID Monitor Pot Assembly in the table base, as shown: To mount the extension bracket for attaching the string from the pot, you must drill a 0.156” hole in the Upper Table Shelf Flange, above and in line with the SID pot.

  • Page 20: Alternate Method Of Mounting Table Top In Small Rooms

    EV200 Elevating Table Revision D Installation CAUTION AS THE EDGE OF THE TOP APPROACHES EACH MAGNETIC LOCK, DEPRESS THE LOCK SO THAT THE TOP WILL CLEAR IT 18. Temporarily turn power to the table ON and ensure that the collision sensor switches and adjustable tension bearing assemblies are working properly.
  • Page 21 EV200 Elevating Table Revision D Installation the table coasts briefly when stopping while descending, and that it must stop at the same point as when elevating. Raise and lower the table a number of times to verify that all three limit switches are properly adjusted and that their wiring harnesses are clear of the actuator and table mechanism.

  • Page 22: Test And Calibration

    A preliminary setting for this switch can be obtained using the switch adjustment block, part # 242-5037P1, which is supplied in the installation kit for the EV200. This block has two milled surfaces, which have been milled to provide the 0.040” window of operation for the switch.
  • Page 23 EV200 Elevating Table Revision D Test and Calibration Closed Position • Slide the switch adjustment block along the rail, passing over the activation lever of the switch with the “CLOSED” side up. When the block passes over the switch the contacts should close. Loosen the two switch mounting screws slightly and adjust the switch position as necessary.

  • Page 24: Setting The Adjustable Tension Bearing Assemblies

    EV200 Elevating Table Revision D Test and Calibration SETTING THE ADJUSTABLE TENSION BEARING ASSEMBLIES The adjustable bearing assembly helps to maintain the proper amount of tension on the lower surface of the table top guide rail, which holds the collision sensor switch closed, during normal operation.

  • Page 25: Schematics

    Inst. Top Collision Sensing Kit (3 sheets) 124-0090S Schematic, Motor Control PWB 120-0008S Wiring Diagram, EV200 Table 110-0064S Schematic, EV200 (2 sheets) 110-0064G_ EV200 Assembly drawings (6 sheets) for parts identification ©Del Medical Imaging June 7, 2002 page 25 of 31 pages...
  • Page 39 EV200 Elevating Table Revision D Renewal Parts RENEWAL PARTS Description Part Number Top collision Sensing Kit (Complete) 110-5038G1 Switch, Collision Sensing 632-5023P1 Collision Switch Adjustment Block Foot Treadle 112-0305G1 Foot Treadle Switch 632-0013P1 Limit Switch Assy. 122-0066G1 Limit Switch 632-0029P1 Shim, Steel, 2 X 3 X 0.0149”...
  • Page 40 EV200 Elevating Table Revision D Renewal Parts Item # Description (From 110-0064 Assembly Drawings) Del Part # INNER FRAME AND SUPPORT 112-0300G1 BUCKY CARRIAGE 112-0301G1 DRIVE FRAME, 60 HZ. 112-03302G1 LOWER FRAME ASSY – MEDICAL WHITE 112-0303G1 LOWER FRAME ASSY – BLUE...

  • Page 41: Periodic Maintenance

    EV200 Elevating Table Revision D Periodic Maintenance PERIODIC MAINTENANCE MECHANICAL AND ELECTRICAL TESTS The following maintenance schedule should be performed on the elevating table at the time of installation, 90 days after installation, and semi-annually thereafter. This inspection must be carried out by trained service personnel familiar with the equipment and maintenance procedures.
  • Page 42 EV200 Elevating Table Revision D Periodic Maintenance 5. Check mounting bolts for speed reducer, motor and idler sprocket mounting bracket and tighten if necessary. 6. Check chain, sprockets, gears and racks for signs of wear. Elevate and lower the table several times while watching and listening for signs of rubbing or interference.
  • Page 43 EV200 Elevating Table Revision D Periodic Maintenance 9. Lightly oil the rear Bucky carriage rail. Remove the end covers and lock well covers to gain access to the locks and cross table bearings and shafts. Lightly oil the bearing shafts and the unpainted surface of the end plates where the magnetic locks engage.
  • Page 44 EV200 Elevating Table Revision D Periodic Maintenance 12. Inspect the foot treadle assembly to insure that all pedals and switches operate properly. 13. Reinstall the top and bottom front covers and restore power to the table. 14. Operate the table to insure that all motions are accomplished freely and without rubbing or resistance, that the table top stops at both extremes and at the 40 inch S.I.D.
