Ef2241 Front And Rear Panels - Polycom Vortex EF2241 Reference Manual

EF2241 F
RONT AND
1
10 11
Figure 2. EF2241 Front and Rear Panels
V EF2241 Reference Manual
ORTEX
R P
EAR ANELS
2 3 4 5
16
12 13 14 15
1. LCD D . Displays menu instructions for configuration and operation of the
ISPLAY
EF2241.
2. D B . Scrolls backward through menu items at a particular level or
OWN UTTON
decreases the value of a parameter.
3. U B . Scrolls forward through menu items at a particular level or increases
P UTTON
the value of a parameter.
4. E . Enters the menu and allows you to select and change parameter values.
NTER
5. E . Returns to the next highest level of menus.
SC
6. H . Returns to the top of the menu structure.
OME
7. L I
EVEL NDICATOR
8. P C
HONE ONNECT
handset connected to the P
disable the P
HONE
9. C A
HANNEL CTIVITY
inputs.
6 7 8
17
. Indicates the level of the selected channel or parameter.
. Takes the phone line on or off hook. If you have an analog
jack on the back panel, pushing this button will
HONE
jack while enabling the L
LED . Indicates gating activity of the 4 mic/line channel
S
6
P -I
RE NSTALLATION
9
18 20 19
jack (see Item 17).
INE
Technical Support: 800.932.2774
