Configure The Matrix Mixer - Polycom Vortex EF2241 Reference Manual

Automixer and
Bus Mixer
Settings
Operating as an
Independent
Automixer
Operating as One
Automixer with
Multiple Vortex
Devices
Default Settings
C M
ONFIGURE THE
B Y S
UILDING OUR
V EF2241 Reference Manual
ORTEX
To operate the Vortex device in any of the above possibilites, two global parameters
need to be changed: the A
parameter chooses which automixer the input channel will be on (this is
MIXER
changed either on the A
M page).
IXER
The B M parameter is used to assign one of the two internal automixers to one
US IXER
of the EF Bus automixer groups. For example, consider three Vortex devices, each of
which has 2 microphones assigned to Automixer 1 and 2 microphones assigned to
Automixer 2. Now, if each of these devices sets their Automixer 1 to have Bus ID 5,
then the three automixers (one from each device) will work as a single automixer con-
taining 6 (3 x 2) microphones. Setting B
not grouped on the EF Bus.
To set the Vortex device to operate as an independent automixer (or two), set the B
M parameter to 0, or to a number that is different from any other automixer group
IXER
on the EF Bus.
To set the Vortex device to operate as one automixer across several devices, set the
B M parameter on all devices to the same automixer group.
US IXER
In the default preset (Preset 0), the Bus Mixer for Automixer 1 is set to 1 and the Bus
Mixer for Automixer 2 is set to 2. This means that in the default mode, all linked
devices will work together as one complete automixer.
M
ATRIX IXER
The matrix mixer allows arbitrary crosspoint gains in 1 dB increments between any
input and output signal.
If you have a PC, use the Conference Composer software (See the Conference Com-
poser User Guide) to set the matrix parameters. If you would like to set matrix
parameters from the LCD menus, see "Matrix Menu" on page 34 for descriptions and
instructions on setting matrix mixer parameters.
M
YSTEM WITH ULTIPLE
The following is a checklist for building a system with mutliple devices:
1. Assign Inputs.
2. Assign Outputs.
3. Configure submatrix (the EF Bus).
4. Configure your echo canceller reference.
I
NTEGRATING THE
and the B M
UTOMIXER US
page in Conference Composer or on the M
UTOMIXER
M
US IXER
V D
ORTEX EVICES
22 Technical Support: 800.932.2774
EF2241 I Y S
NTO OUR
(see Figure 14). The A
IXER
to 0 means that the automixer is
YSTEM
-
UTO
ATRIX
US
