Summary of Contents for Orgapack H-1465
- Page 1 H-1465 OR-T 300 Battery-hand tool for plastic strapping Before using the tool, read the operating instructions carefully. 08/07...
-
Page 2: Table Of Contents
ORGAPACK OR-T 300 TABLE OF CONTENTS TECHNICAL DATA Page Weight 4.2 kg (9.9 lbs) (incl. battery) Dimensions Length 375 mm (14.7“) 130 mm (5.1“) Information on environmental protection ) “ Strap tension 400–3300 N (88–727 lbs) Tension speed 250 mm/s (9.8“/s) -
Page 3: Information On Environmental Protection
ORGAPACK OR-T 300 GENERAL INFORMATION These operating instructions are intended to simplify familiarisation with the strapping tool and its proper CAUTION! use for the intended purpose. The operating instruc- tions contain important information concerning the Used where there is dan- safe, proper and effi... -
Page 4: Safety Instructions For Battery
ORGAPACK OR-T 300 SAFETY INSTRUCTIONS Inform yourself! Original ORGAPACK spare Original Read the operating instructions parts must be used exclusi- carefully. vely! jklsfjklsdjš lksdfjkl Preventive and corrective main- Not using original spare parts jkljsdllkjjkljsd ORGAPACK fkljjklkjkljsdafj asdfjklkjjkljklj ksldafkjkljklš tenance on the tool may only... - Page 5 ORGAPACK OR-T 300 DESCRIPTION 4.1 CONSTRUCTION 1 Operating panel 2 Strap tensioning push button 3 Handle 4 Battery 5 Rocker lever 6 Welding/cutting button 7 Welding/Cutting 8 Tensioning 9 Battery charger (refer to chapter 4.4) Note on performance In order to achieve peak performance, only original batteries and charger may be used.
- Page 6 ORGAPACK OR-T 300 4.4 BATTERY CHARGER The battery charger (IFC1702d) is a special device with both charging and discharging functions for maxi- mum battery power and life. – When a battery is placed in the charger, the remai- ning charge level is tested fi rst. If the battery is not completely discharged, the charger will fi...
- Page 7 ORGAPACK OR-T 300 INITIAL OPERATION 5.1 BATTERY CHARGER Input 90-135VAC, 170-264VAC / 47...65 Hz The mains supply must comply with the specifi cations on the rating plate (Fig. 5). Battery Type: Bosch NTC-Battery 14,4V The battery charger is suitable only for charging batteries from the Bosch range of tools (NiCd/ Fig.
-
Page 8: Operating Instructions
ORGAPACK OR-T 300 OPERATING INSTRUCTIONS 6.1 OPERATING THE TOOL – Insert charged battery (7/1) into strapping tool. – Place strap round goods to be packaged, so that the straps lie one above the other on top of package. The beginning of the strap is underneath. - Page 9 ORGAPACK OR-T 300 – Depress button (10/1) completely to the stop. The straps are welded together and the upper strap is cut off. The LED indicator (10/2) indicates the cooling time of the sealing: LED fl ashing After fi nishing the friction wel- ding, the green LED fl...
-
Page 10: Checking Battery Charge
ORGAPACK OR-T 300 6.3 OPERATING PANEL a) Standard indication max. min. a) Standard indication (green) The current strap tension setting is monitored with inserted and charged battery. green 1 = minimum strap tension (approx. 400 N) 7 = maximum strap tension (approx. 1400/3300 N*) -
Page 11: Setting Strap Tension Range
ORGAPACK OR-T 300 6.3.4 SETTING STRAP TENSION RANGE The following two strap tension ranges can be set on the tool: A = 400–3300 N (standard) B = 400–1400 N (eg for PP-straps) Check strap tension range – Depress and hold down “–“ push button (17/2), and depress strap tension push button (17/1) for one second. -
Page 12: Preventive And Corrective Maintenance
ORGAPACK OR-T 300 PREVENTIVE AND CORRECTIVE MAINTENANCE All preventive maintenance tasks can be 7.1 CLEANING/REPLACING TENSION WHEEL performed with a Phillips screw driver! Removal – Remove battery from tool. – Release three sunk screws (20/3) and remove cover (20/2) with ball bearing.
