- Page 1 English Operating instructions OR-T 55 Battery-operated strapping tool for plastic strapping www.orgapack.com V 02.22_EN H-10933 0623 IH-10933VND...
-
Page 2: Table Of Contents
Read the operating instructions carefully. These operating instructions are part of the product and therefore should be kept for later use or a future owner. Validity ● OR-T 55 from Series no E/21111001 Manufacturer Orgapack c/o Signode Switzerland GmbH Silbernstrasse 14, Postfach... - Page 3 The legal prescriptions for disposal of all parts must be observed. ► Chargers and batteries should be sorted for environmentally-friendly recycling. ► Observe notes, warnings and instructions of the battery manufacturer. V 02.22_EN 3 of 20 ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
-
Page 4: Safety
If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. 4 of 20 V 02.22_EN ORGAPACK OR-T 55 H-10933 0623 IH-10933VND... - Page 5 Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. V 02.22_EN 5 of 20 ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
-
Page 6: Working Safely
For an emergency stop in the case of danger (trapped person): ● To release the strap tension (before welding), actuate the rocker lever. ● After welding, cut the strap using a suitable tool (strap cutter). 6 of 20 V 02.22_EN ORGAPACK OR-T 55 H-10933 0623 IH-10933VND... - Page 7 Do not clean the tool with water or steam. When using the tool outdoors, protect it from rain. Use only original spare parts Using non-original spare parts will void the warranty and any liability. V 02.22_EN 7 of 20 ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
-
Page 8: Description
Description Design Welding lever Tensioning lever Handle Battery Cutting device Serial number (XJJMMYYYY) X E=OR-T 55 JJ Year MM Month YYYY consecutive number Tension shoe Tension wheel Foil tastatur – Battery charging indicator (Section 4.1.3) – Adjust welding time (Section. 4.3) 10 Tri-Color LED –... -
Page 9: Function
9–10, 12–13, 15–16 and 19 mm ″, ″, ″ or ″ Scope of delivery For strapping tool OR-T 55: ● Battery Li-on 12 V / 6.0 Ah Part no 2187.020 ● Battery charger AL60 DV1419, 230 V Part no 2188.025 or for USA version: ●... -
Page 10: Battery
LED display "Battery charge status" on operating panel, with battery inserted: 1 Battey maximum charged 2 Battery fully charged 3 Battery low charged 4 Battery empty (battery must be charged) 10 of 20 V 02.22_EN ORGAPACK OR-T 55 H-10933 0623 IH-10933VND... - Page 11 ► Press the – (1) or + (3) key until the desired sealing time is displayed by means of filled dots (2). ► Carry out seal check after each strapping (Section 5.2) V 02.22_EN 11 of 20 ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
-
Page 12: Strapping
► Insert the strap from dispenser between the tension wheel (3) and the tension shoe (2). Then insert the strap into the slot of the cutting device (1) until stop is reached. 12 of 20 V 02.22_EN ORGAPACK OR-T 55 H-10933 0623 IH-10933VND... - Page 13 (tool is blocked; remove battery and reinsert). If the charge status display (section 4.1.3) is red, there is no welding, since a safe welding of the straps can no longer be guaranteed with the remaining charge of the battery. V 02.22_EN 13 of 20 ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
- Page 14 ► Strapping with poorly welded seals must be performed again. ► Check strap type (Section 7). ► If good welding is not achieved, the tool must be checked by an authorized service center. 14 of 20 V 02.22_EN ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
- Page 15 Setting the strap width The tools can be operated with the following strap widths: ● OR-T 55: 9–10, 12–13, 15-16 or 19 mm ( ″, ″, ″ or ″) Required parts Order number Washer (3) 1821.020.042 ● To change the strap width, the strap stop (2) must be removed with the screw (1) from the tool and refitted with washers (1.5 mm thick)
-
Page 16: Cleaning The Tool
► If necessary, replace the tension wheel / tooth plate (Section 6.3 / 6.4). Replacing the tension wheel Required parts Order number OR-T 55: Tension wheel (1) (wear part) 1821.047.003 Nut (3) 1820.020.163 Saucer spring (2) Ø25/12,2 x 1,5 1925.210.122 Carrier (1) 1821.255.001... - Page 17 ► Fitting is performed in reverse order. Do not oil the coupling discs. Set maximum belt tension after installation (Section 4.2). Replacing the tension shoe Required parts Order number OR-T 55: Tension shoe (1) (wear part) 1821.048.004 Set screw (3) 1820.030.092 Compression spring (4) 1821.010.018...
-
Page 18: Troubleshooting
(tears in the welding area). Tri-colour LED (Sec. 3.1) ● Tensioning lever is moved back ► Remove battery and reinsert. flashes red. too early during welding process. Tool is blocked. 18 of 20 ORGAPACK OR-T 55 V 02.22_EN H-10933 0623 IH-10933VND... - Page 19 Strap width adjustable to 9–10 mm, 12–13 mm, 15-16 mm, 19 mm ″, ″, ″, ″) Strap thickness 0.50–1.00 mm (.019″–.039″) * refer to Section 2.4, Vibration and noise exposure V 02.22_EN 19 of 20 ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
-
Page 20: Manufacturer Orgapack
Agent for the publication of technical documentation: Signode Switzerland GmbH, Silbernstrasse 14, 8953 Dietikon 1, Switzerland Manufacturer Orgapack c/o Signode Switzerland GmbH Silbernstrasse 14, Postfach 8953 Dietikon 1 SWITZERLAND orgapack.com 20 of 20 V 02.22_EN ORGAPACK OR-T 55 H-10933 0623 IH-10933VND...
