Model No. NTL19117.2
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to my.nordictrack.com
CUSTOMER CARE
For service at any time, go to
nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTL19117.2 and is the answer not in the manual?

Questions and answers

Related Manuals for NordicTrack NTL19117.2

Summary of Contents for NordicTrack NTL19117.2

  • Page 1 USER’S MANUAL Model No. NTL19117.2 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.nordictrack.com CUSTOMER CARE For service at any time, go to nordictrackservice.com.

  • Page 2: Table Of Contents

    Note: The decals may not be shown at actual size. 305284 NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. Wi-Fi is a registered trade- mark of Wi-Fi Alliance. WPA and WPA2 are trademarks of Wi-Fi Alliance. The BLUETOOTH word mark and ®...

  • Page 3: Important Precautions

    5. The treadmill is intended for home use only. purchase a surge suppressor, see your local Do not use the treadmill in any commercial, NORDICTRACK dealer, call the telephone rental, or institutional setting. number on the front cover of this manual, or see your local electronics store.
  • Page 4 19. Always stand on the foot rails when starting frame securely in the storage position. Do or stopping the walking belt. Always hold the not operate the treadmill while it is folded. handrails while using the treadmill. 27. Do not change the incline of the treadmill by 20.
  • Page 6 STANDARD SERVICE PLANS...

  • Page 7: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK COMMERCIAL 2950 treadmill. manual. To help us assist you, please note the product ® The COMMERCIAL 2950 treadmill offers an impres- model number and serial number before contacting us.

  • Page 8: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 9: Assembly

    Phillips screwdriver cleaner. To avoid damaging parts, do not use power tools. • To identify small parts, see page 8. 1. Go to my.nordictrack.com on your computer and register your product. • documents your ownership • activates your warranty •...
  • Page 10 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (83) to the front of the Base (93). Next, identify the Right Upright (84). Have a second person hold the Right Upright near the Base (93).
  • Page 11 4. Hold the Right Upright (84) against the Base (93). Make sure not to pinch the Upright Wire (83). Attach the Right Upright (84) with two 3/8" x 2 3/4" Screws (23), two 3/8" x 1 1/4" Screws (20), and four 3/8" Star Washers (25) as shown; do not fully tighten the Screws yet.
  • Page 12 6. Carefully slide the Upright Crossbar (76) between the Right and Left Uprights (84, 91). Attach the Upright Crossbar with four 5/16" x 3/4" Screws (1); start all four Screws, and then tighten them. 7. Hold the Tray (79) near the Right Upright (84). Locate the tie (F) in the indicated hole (G) in the Right Upright.
  • Page 13 8. Attach the two Handrails (74) to the Right and Left Uprights (84, 91) with two 5/16" x 2" Screws (2) and two 5/16" Star Washers (8); do not fully tighten the Screws yet. Be careful not to pinch the Upright Wire (83) or the fan wire (H) on the right side.
  • Page 14 10. IMPORTANT: To avoid damaging the Pulse Crossbar (80), do not use power tools, and do not overtighten the #10 x 3/4" Screws (6) or the 5/16" x 2" Screws (2). Orient the Pulse Crossbar (80) as shown. Attach the Pulse Crossbar to the Handrails (74) with two 5/16"...
  • Page 15 12. Attach the console assembly (K) to the Handrails (74) with four 5/16" x 2" Screws (2) and four 5/16" Star Washers (8); start all four Screws, and then tighten them. Be careful not to pinch the wires (O). 13. Insert the wires (M, N) into the top of the Right Upright (84).
  • Page 16 14. Start eight #8 x 3/4" Truss Head Screws (24) into the Pulse Crossbar (80), and then tighten them; do not overtighten the Truss Head Screws. 15. Set the Left Handrail Top Cover (73) on the left Handrail (74). Start four #8 x 3/4" Truss Head Screws (24) into the Left Handrail Bottom Cover (75), the left Handrail, and the Left Handrail Top Cover.
  • Page 17 16. Raise the Frame (52) to the upright position. Have a second person hold the Frame until step 18 is completed. Remove the two 5/16" x 1 1/4" Screws (16) from the Latch Crossbar (109). Orient the Latch Crossbar (109) as shown. Make sure that the “This side toward belt”...
  • Page 18 18. Remove the 5/16" Nut (9) and the 5/16" x 2 1/4" Bolt (4) from the bracket on the Frame (52). Align the upper end of the Storage Latch (56) with the bracket on the Frame (52), and insert the 5/16" x 2 1/4" Bolt (4) through the bracket and the Storage Latch.

  • Page 19: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Store the heart rate monitor in a warm, dry place. Do not store the heart rate monitor in a plastic bag or If the heart rate monitor looks like the one shown other container that may trap moisture.

  • Page 20: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit.
  • Page 21 CONSOLE DIAGRAM FEATURES OF THE CONSOLE In addition, the console features a selection of work- outs. Each workout automatically controls the speed The advanced treadmill console offers a selection of and incline of the treadmill as it guides you through an features designed to make your workouts more effec- effective exercise session.
  • Page 22 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 23 HOW TO SET UP THE CONSOLE 5. Check for firmware updates. Before using the treadmill for the first time, set up the First, touch the profile button in the lower-right cor- console. ner to select the settings main menu. Next, select the maintenance section.
  • Page 24 HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, press the Incline increase and decrease buttons or one of the See HOW TO TURN ON THE POWER on numbered incline buttons.
  • Page 25 To measure your heart rate, stand on the foot • Your pace rails and hold the contacts with your palms for • The speed of the walking belt approximately ten seconds; avoid moving your hands. When your pulse is detected, your heart rate will be shown.
  • Page 26 HOW TO USE A MAP WORKOUT 5. Monitor your progress with the display modes. Note: To use a map workout, you must have access See step 5 on page 24. to a wireless network (see HOW TO USE THE 6. Measure your heart rate if desired. WIRELESS NETWORK MODE on page 30).
  • Page 27 4. Save your workout. HOW TO USE A DISTANCE OR TIME WORKOUT Touch the Save New Workout button in the lower- Note: To use a distance or time workout, the console left corner of the screen. If desired, change the title must be connected to a wireless network (see HOW of the workout or add a description, and then press TO USE THE WIRELESS NETWORK MODE on page...
  • Page 28 6. Start the workout. 3. Customize settings. See step 4 on page 26. Note: During a distance or To customize settings, touch the desired category, time workout, the display will not show a map. and then touch the toggle button at the side of the category name.
  • Page 29 HOW TO USE THE MAINTENANCE SECTION IMPORTANT: Keep pets, feet, and other objects away from the treadmill while the incline sys- 1. Select the settings main menu. tem is calibrating. In an emergency, pull the key from the console to stop the incline calibration. See step 1 on page 28.
  • Page 30 HOW TO USE THE WIRELESS NETWORK MODE When the console is connected to your wireless network, a checkmark will appear next to the wire- The console features a wireless network mode that less network name. Then, touch the back button on allows you to set up a wireless network connection.
  • Page 31 HOW TO USE THE SOUND SYSTEM HOW TO ADJUST THE ANGLE OF THE CONSOLE To play music or audio books through the console To adjust the angle of the console, hold both sides of sound system while you exercise, plug a 3.5 mm male the console and tilt it to the desired position.

  • Page 32: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 33: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal perfor- as shown, the switch has tripped. To reset the mance and to reduce wear. Inspect and properly tighten power switch, wait for five minutes and then press all parts each time the treadmill is used.
  • Page 34 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center or slips when walked on a. Use only a surge suppressor that meets all of the a. If the walking belt is off-center, first remove the specifications described on page 20.
  • Page 35 SYMPTOM: The displays of the console do not SYMPTOM: The console does not stay in place function properly a. If the console does not stay in the desired position a. If the console does not boot up properly, or because it is too loose, use a hex key to slightly if the console freezes and does not respond, tighten the console in the indicated location on both reset the console to the factory default settings.

  • Page 36: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 37 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 38: Part List

    PART LIST Model No. NTL19117.2 R0518A Key No. Qty. Description Key No. Qty. Description 5/16" x 3/4" Screw Drive Roller/Pulley 5/16" x 2" Screw Frame 5/16" x 1 3/4" Bolt 5/16" x 2 1/4" Bolt Drive Motor #8 x 3/4" Screw Motor Belt #10 x 3/4"...
  • Page 39 Key No. Qty. Description Key No. Qty. Description Right Tray Adjustment Handle Hood Accent Cushion Bushing Hood Grill Cushion Rod Bracket Key/Clip Cushion Wheel Stop Console Frame Cap M10 Spring Washer Console Frame Cushion Wheel Cable Tie 3/8" Flat Washer Cushion Rod 1/4"...

  • Page 40: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL19117.2 R0518A...
  • Page 41 EXPLODED DRAWING B Model No. NTL19117.2 R0518A 114 115...
  • Page 42 EXPLODED DRAWING C Model No. NTL19117.2 R0518A...
  • Page 43 EXPLODED DRAWING D Model No. NTL19117.2 R0518A...

  • Page 44: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
