LF-RGB-65
RGB LED Fresnel with 6.5 in. Lens
THANK YOU FOR CHOOSING GENARAY
The Genaray LF-RGB-65 boasts a large 6.5-inch Fresnel lens
to focus its spot-to-flood beam from 25° to 60° for ideal key,
fill, and accent light applications. With a peak intensity of nearly
20,000 lux, this light is perfect for photos, videos, theaters, and
houses of worship. It offers a full-spectrum RGB light and a color
temperature range of 2800 to 6500 K. Accurate color temperature
and green/magenta shift adjustment allows this fixture to
conform to natural or artificial ambient lighting conditions as
well as other light fixtures on the set. Multiple operating modes
help you get the most out of this versatile light, and programmed
effects add realistic and dramatic looks to any scene.
The LF-RGB-65 runs on AC power and is operated by its
simple control panel. It can also be operated via DMX 512
protocols, and DMX input and output ports allow for daisy-
chaining and using this light with a DMX universe.
PRECAUTIONS
· Please read and follow these instructions, and keep this manual in a safe place.
· Keep this unit away from water and any flammable gases or liquids.
· Make sure the unit is powered off when plugging it into a power source.
· Use only the correct, recommended voltage.
· Do not attempt to disassemble or repair the equipment—doing so will void the
warranty, and Genaray will not be responsible for any damage.
· Handle the unit with care.
· Do not stare directly at the lights when they are powered on.
· Always use a steel safety cable (not included) when suspending a light fixture or
other assembly.
· Clean the unit with only a soft, dry cloth.
· Images are for illustrative purposes only.
RGB LED Fresnel with 6.5 In. Lens - USER MANUAL
1
OVERVIEW
5/8 in. receiver
Locking handle
Power switch
Fuse
3-prong AC power input
Fresnel lock
LCD display
DMX input
DMX output
Color knob
Mode selector
Yoke
Barndoor clip
4-way barndoors
6.5 in. Fresnel lens
RGB/CCT selector
Focusing knob
Dimmer knob
Confirm button
