- Page 1 ML-33K Endeavor 150-WATT DAYLIGHT LED MONOLIGHT USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING GENARAY The Genaray Endeavor 150-watt monolight features an advanced chip-on-board (COB) LED that outputs a powerful constant light source to deliver a brilliant daylight-balance beam for video and photo shoots. The fixture’s natural-looking 5600 K daylight-balance light is dimmable from 100% to 0% Endeavor in 10% increments for the brightness your exposures need.
- Page 3 PRECAUTIONS · Please read and follow these · Do not attempt to disassemble of instructions, and keep this manual in repair the equipment. Doing so will a safe place. void the warranty, and Genaray will not be responsible for any damage. ·...
-
Page 4: Product Overview
Light Fixture - Front Bowens mount release button Bowens mount COB LED array PRODUCT OVERVIEW Reflector Umbrella locking screw Umbrella hole DC power socket Light stand mount Tilt lock Locking knob Locking button 5/8 in. receiver Umbrella mount Endeavor 150-Watt Daylight LED Monolight - USER MANUAL... - Page 5 Light Fixture - Back Battery status Channel indicator Group indicator Brightness Color temperature Channel button Group button Display Power switch Adjustment dial Fuse Power socket Endeavor 150-Watt Daylight LED Monolight - USER MANUAL...
- Page 6 MOUNTING THE CONTENTS INCLUDE ENDEAVOR · Endeavor 150-Watt LED Monolight To mount the Endeavor on any heavy- duty light stand with a 5/8-inch pin: · 7 in. reflector 1. Loosen the locking knob so it · Tungsten filter doesn’t obstruct the receiver. ·...
- Page 7 POWERING THE ENDEAVOR FROM AN AC OUTLET WITH DC POWER The Endeavor can be powered by V-mount Warning! batteries, using the Genaray BA-VMOUNT The Endeavor is a powerful light. Do not look dual-battery adapter (available separately). directly into the light when it’s powered on. Dual 14.8-volt, 160-watt-hour V-mount Connect the AC power cable to the batteries will power the Endeavor...
- Page 8 OPERATING THE ENDEAVOR ATTACHING THE REFLECTOR ATTACHING AN UMBRELLA The Endeavor includes a 7-inch reflector 1. Make sure the reflector’s and is compatible with Bowens-mount umbrella pass-through is aligned accessories. To attach the reflector: with the umbrella mount. 1. Insert the three mounting studs 2.
-
Page 9: Adjusting The Brightness
Note SETTING THE CHANNEL AND GROUP Other brands’ Bowens-style reflectors The Endeavor and remote must be will work with the Endeavor. Make set to the same channel and group sure the reflector has a pass-through for wireless remote operation. hole to use it with an umbrella. Channel Selection Press the channel button (CH). -
Page 10: Product Specifications
PRODUCT SPECIFICATIONS LED Chip Type: COB Working Voltage: 90 to 240 V AC, 50/60 Hz Color Temperature: 5600 K ±200 K Mount: 5/8 in. Light Intensity @ 3 ft.: 33,000 lx Channels and Groups: 16 channels, 5 groups (A, B, C, D, E) Dimming: 100% to 0% Dimensions (H ×... -
Page 11: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment.
