- Page 1 RSF-11-RGB Mini Moon RGB 11 IN. RGB LED USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING GENARAY The Genaray Mini Moon RGB is a portable fixture that provides a natural and soft continuous light source with broad coverage for still and tabletop photography, portraits, and interviews. This light delivers highly accurate color rendering in CCT and RGB modes.
- Page 3 PRECAUTIONS · Please read and follow these · Handle the unit with care. instructions, and keep this manual in · Do not attempt to disassemble or a safe place. repair the equipment—doing so will · Keep this unit away from water and void the warranty, and Genaray will not any flammable gases or liquids.
- Page 4 Light Fixture - Front Diffuser PRODUCT OVERVIEW Tilt adjustment knobs Yoke Locking knob 2-way 5/8 in. mount Mini Moon RGB 11 in. RGB LED - USER MANUAL...
- Page 5 Light Fixture - Back V-mount release button V-mount battery plate LCD display DMX button NP-F battery Channel button plates Mode button Bluetooth button Color/Sat/FX dial Dim/Channel dial DMX input and Power socket output Power switch Mini Moon RGB 11 in. RGB LED - USER MANUAL...
- Page 6 MOUNTING THE MINI CONTENTS INCLUDE MOON RGB · LED with yoke The Mini Moon RGB is equipped with a 2-way 5/8-inch receiver. · AC adapter Mount the Mini Moon RGB on any light stand · Power cord with a 5/8-inch stud, in upright or horizontal ·...
- Page 7 POWERING THE MINI MOON RGB The Mini Moon RGB can be powered directly BATTERY POWER from an AC outlet, two NP-F batteries, or The Mini Moon RGB can be powered by two one V-mount battery. NP-F batteries or one V-mount battery. Important AC POWER Use only V-mount batteries with a...
- Page 8 Installing a V-mount battery The battery status indicator on the LCD screen displays the remaining battery Align the battery with the battery terminals, power. and slide the battery onto the plate until it clicks into place. To remove the battery, press the release button to unlock the 100% to 75% battery and slide it off the plate.
- Page 9 OPERATING THE MINI MOON RGB OPERATING MODES SETTING THE CHANNEL The Mini Moon RGB has four operating You can use Genaray’s wireless controller (RSF-11-R available separately) to remotely modes: operate the Mini Moon RGB from up to CCT Mode allows you to adjust the color 60 feet away.
-
Page 10: Rgb Mode
CCT MODE RGB MODE Color temperature Brightness Hue (color) Saturation Brightness Press the Mode button to select CCT mode. Press the Mode button to select RGB mode. · Adjust the color temperature from · Adjust the hue from 0° to 360° in one- 2700 to 9999 K by turning the Color degree increments by turning the Color/ Temperature dial. - Page 11 FX MODE · While the saturation value is blinking, turn the Color/Sat/FX dial to adjust the value, and press the dial again to set it. · Adjust the brightness from 0% to 100% by turning the DIM dial. Effect Frequency Brightness number The Mini Moon RGB has twenty built-in CCT...
- Page 12 ACTIVATING FX MODE CCT EFFECTS To activate FX mode, press and hold the These effects use the white and amber Mode button and press theColor/Sat/FX dial. LEDs to create animated lighting effects with different color temperatures. · Activating FX mode from CCT mode will open a list of effects that use variations of 1.
- Page 13 USING DMX RGB EFFECTS The Mini Moon RGB supports DMX-512, so the light’s settings can be remotely These effects use the RGB LEDs to create controlled from a DMX console. colorful animated lighting effects. Note 1. Cop Car When the Mini Moon RGB is in DMX 2.
- Page 14 USING THE RSF-11-R WIRELESS TRANSMITTER To set the DMX address on the Mini Moon The Mini Moon RGB’s wireless transmitter RGB: allows you to operate the Mini Moon RGB from up to 60 feet away. 1. Press the DMX button to switch to DMX mode.
- Page 15 POWERING ON CHANGING OPERATING MODES Press the On/Off Button. The remote will CCT and RGB Modes power up to the most recently used settings. 1. Press the Mode button to toggle between CCT and RGB modes. SETTING THE CHANNEL 2. Press the up/down buttons to select Press the Channel button to highlight the the values for hue, brightness, and channel number.
- Page 16 Pressing the FX button in RGB mode will SLEEP MODE open a different list of effects that use the Using sleep mode will preserve battery life Mini Moon’s RGB LEDs. without turning off the Mini Moon RGB. Refer to FX Mode above for a list of CCT and Press and hold the On/Off button to put the RGB effects.
-
Page 17: Product Specifications
PRODUCT SPECIFICATIONS Color Temperature: 2700 to 9999 K ±300 K Battery Type: NP-F750/950 (×2) V-mount (14.8 V Max) Brightness : @ 3 ft.: 2520 lx (5600 K) @ 1 m: 2105 lx (5600 K) Mount: 2-way 5/8 in. Receiver Coverage: 120° Cable Length: AC Adapter Cord: 12.5 ft. - Page 18 WIRELESS TRANSMITTER Frequency: 2.4 GHz Working Distance: 60 ft. (18.3 m) Functions: On/off, Mode selection, Brightness, Color saturation, Channel selection ,Color temperature, Effects selection, Effects frequency adjustment Power: Two AAA batteries (not included) Dimensions (H × W × D): 1.75 × 5.5 × 0.7 in. (4.4 ×...
- Page 19 ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment.
