- Page 1 SpectroLED STUDIO 800/1200 LED LIGHT USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING GENARAY The Genaray SpectroLED Studio Lights provide bright, continuous light with flicker-free dimming for photography and video shoots. They’re ideal for studio work, but they’re constructed to be sturdy and durable enough for location work as well. SpectroLED fixtures are available with 800- and 1200- SpectroLED LED arrays that can operate on AC or battery power.
- Page 3 PRECAUTIONS · Please read and follow these · Handle the unit with care. instructions, and keep this · Do not stare directly at the lights manual in a safe place. when they are powered on. · Keep this unit away from water and ·...
- Page 4 SP-S-800B/D1 array OVERVIEW Yoke Locking knob SpectroLED Studio LED Light - USER MANUAL...
- Page 5 Brightness Color D-tap input temperature power socket Battery plate V-mount release button Tilt adjustment knobs Color temperature Power switch knob (Bi-color only) 4-pin XLR Dimmer knob power socket SpectroLED Studio LED Light - USER MANUAL...
- Page 6 SP-S-1200B/D1 OVERVIEW array Yoke Locking knob SpectroLED Studio LED Light - USER MANUAL...
- Page 7 Brightness Color D-tap input temperature power socket Battery plate V-mount release button Tilt adjustment Dimmer knob knobs Color temperature Power switch knob (Bi-color only) 4-pin XLR Locking knob power socket SpectroLED Studio LED Light - USER MANUAL...
- Page 8 MOUNTING THE CONTENTS INCLUDE SPECTROLED · AC adapter BABY-PIN STUD · AC power cord Mount the fixture on any heavy-duty light stand with a 5/8-inch baby-pin stud, and · Remote controller turn the locking knob until secure. · Diffuser JUNIOR-PIN RECEIVER ·...
- Page 9 POWERING THE SPECTROLED The SP-S-1200 and SP-S-800 can be USING THE SPECTROLED powered directly from an AC outlet or with WITH BATTERY POWER one V-mount battery (not included). The SP-S-1200 and SP-S-800 can be USING THE SPECTROLED powered by a V-mount battery. WITH AC POWER When attaching the battery, make sure the power switch is in the Off position, and the...
- Page 10 OPERATING THE SPECTROLED Power the fixture on. The LCD screen will To sync your SpectroLED fixtures with show the last setting that was used. the remote, follow these steps: After powering on the light, set the 1. Power on all SpectroLED fixtures. brightness and color temperature by turning 2.
- Page 11 CHANGING THE BRIGHTNESS through the color temperature range. (ALL MODELS) Multilight Setups The A and B buttons control the brightness. If the lights are set at different color Press the buttons to change the setting in temperatures, the remote will change the 1% increments.
- Page 12 SLEEP MODE DIMMER DOWN 25% (DAYLIGHT MODELS ONLY: Sleep mode turns off the LED array without powering off the fixture. It’s a convenient SP-S-1200D1 / SP-S-800D1) function to use to preserve bulb life and This function allows for quick electricity when setting up new shots power adjustments.
- Page 13 USING THE DIFFUSER AND FILTER BARNDOORS The SpectroLED includes a diffuser. For attachment instructions, refer to A tungsten filter is included for the user manual included with the daylight models. To attach the diffuser barndoors (available separately). or filter, follow these steps: 1.
-
Page 14: Product Specifications
PRODUCT SPECIFICATIONS SP-S-800B1 (Bi-Color) SP-S-800D1 (Daylight) LED count: 800 LEDs Maximum output power: 48 W Color temperature: Working voltage: AC: 100–240 V, 50–60 Hz, 2.0 A Bi-Color: 3200 (±150) to 5600 K (±300 K) DC: 12 V, 5 A Daylight: 5600 K Mount: 5/8 in. - Page 15 SP-S-1200B1 (Bi-Color) SP-S-1200D1 (Daylight) LED count: 1200 LEDs Maximum output power: 72 W Color temperature: Working voltage: AC: 100–240 V, 50–60 Hz, 2.0 A Bi-Color: 3200 (±150) to 5600 K (±300 K) DC: 15 V, 6 A Daylight: 5600 K Mount: 5/8 in.
- Page 16 ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment.
