Polygroup Evergreen Classics AR-P20008A Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com
TREE ASSEMBLY INSTRUCTIONS
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Each tree section is numbered with a
4. Assemble the tree from bottom to the top. Start with the bottom section and remove the protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Connect the light strings as per the color labels indicated in Fig. B and insert green label adapter into the wall outlet, your entire
tree should now be lit.
MODEL #: AR-P20008A
+1 (888) 919-0070
OR
Polygroup®!
Click
Tree top
Section 2
sticker. Please identify all sections before assembling.
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: AC 100-240V, 50/60Hz, 0.35A
Output: DC 29V 0.45A
Controller: 0.45A
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Foot Pedal
on/off switch
Control box
1
Plug Adapter
Into Wall
Outlet
Insert Green
Label Extension
Cord into Adapter
