Polygroup AR-P17004A Assembly Instructions

TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®! This tree comes with Quick Set® and
Simple Shape TM technology-Set up and light up your tree in less than 10 minutes! Carefully follow the
instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 2
Section 1
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap
before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all
wires are free of branch hinges.
7. Insert green label extension cord into adaptor and adaptor insert into the wall outlet. (See Fig. B), your
entire tree should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or
broken, loose or missing bulbs. Connecting the plugs or replace the bad bulbs promptly in order to
maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
9. This is a Simple Shape TM tree. Just slightly upsweep all branch tips for a uniform look. Shift branches
to fill any gaps. Your Christmas tree is now complete and ready to be decorated.
MODEL #: AR-P17004A
Tree top
Unfold the legs and lay the
stand in a flat area. Then slide
the locking disc downward and
snap into place.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.25A
Output: 24V 0.541A
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Insert Green
Label Extension
Plug Adaptor
Cord into Adaptor
1
Into Wall
Outlet
