5566229-JIM-B-1019
All panels must be secured in place when the unit is
lifted.
The condenser coils should be protected from rigging
cable damage with plywood or other suitable material.
LEFT
A
Figure 5: Unit 4 Point Load Weight
Table 2: Weights and Dimensions
Size Weight (lbs.)
Model
(Tons)
Shipping Operating
JA3
ZR 851
(3)
JA4
ZR 870
(4)
JA5
ZR 863
(5)
Table 3: JA3 thru A5ZR Unit Accessory Weights
Unit Accessory
Economizer
Power Exhaust
1
Electric Heat
2
Gas Heat
1. Weight given is for the maximum heater size available (24KW).
2. Weight given is for the maximum number of tube heat exchangers
available (8 tube).
8
FRONT
B
D

Center of Gravity

X Y
846 47.25 24.00
865 48.25 25.34
858 47.25 24.75
Weight (lbs.)
Shipping
90
40
49
110
A
Figure 6: Unit 6 Point Load Weight
C
Figure 7: Center of Gravity
4 Point Load Location (lbs.)
A B C D
161 183 266 235
170 201 268 226
169 191 264 234
Operating
85
35
49
110
LEFT
C
B
F
Y
X
LEFT
6 Point Load Location (lbs.)
A B C
105 114 124
110 123 138
110 120 130
Johnson Controls Ducted Systems
FRONT
D
E
FRONT
D E F
181 167 154
184 163 147
180 165 153
