4-Bay Standalone Hard Drive Eraser
for 2.5"/3.5" SATA Drives
SATERASER4
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/SATERASER4.
Manual Revision: 05/25/2022
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SATERASER4
Summary of Contents for StarTech.com SATERASER4
- Page 1 4-Bay Standalone Hard Drive Eraser for 2.5”/3.5” SATA Drives SATERASER4 *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product diagram ..................1 Package contents ...................2 Requirements ..................2 Menu Options ..................3 USB 3.0 and USB 3.1 Gen 1 ..............4 Available erase modes ................4 About the LED indicators ..............5 Erase drives .....................6 Print a receipt..................7 Connect the eraser to your computer ..........7 Technical support ...................8 Warranty information ................8 Instruction manual... -
Page 4: Product Diagram
Product diagram Top view *actual product may vary from photos Port LED indicators UP button GO button DOWN button Drive port OK button LCD display ESC button Front view SATA data connector SATA power connector Instruction manual... -
Page 5: Package Contents
• 1 x USB 3.0 cable • 1 x quick-start guide Requirements • Up to four 2.5” or 3.5” SATA HDDs or SSDs • Default Password = 123456 Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/SATERASER4. Instruction manual... -
Page 6: Menu Options
Menu Options 1. Quick Erase 2. 1-Pass Erase 3. 3-Pass (DoD 5220.22-M) 4. 3-Pass (CSEC ITSG-06) 5. 3-Pass(HMG Enhanced IS 5) 6. 7-Pass (VSITR) 7. Custom Erase 7.1. Run 1-Pass 7.2. Setup Pass # [Setup Pass #] 1~99 7.3. Setup Pattern [Pattern Count] 1~99 ;... -
Page 7: Usb 3.0 And Usb 3.1 Gen 1
USB 3.0 and USB 3.1 Gen 1 USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard offers speeds up to 5 Gbps. Available erase modes SATERASER4 features nine erase modes. Erase option Description of the process Quick Erase The partition table is quickly erased. -
Page 8: About The Led Indicators
About the LED indicators SATERASER4 features three LEDs for each of the four drive ports on the hard drive eraser. See the tables below for more information about what the LED behaviors signify. Red error LED LED behavior Signifies Red LED is illuminated An error is occurring. -
Page 9: Erase Drives
Erase drives Warning! You should handle drives carefully, especially when you’re transporting them. If you’re not careful with your drives, you may lose data as a result. Make sure that you’re properly grounded by wearing an anti-static strap. If an anti-static strap isn’t available, touch a large, grounded metal surface for several seconds to discharge any built-up static electricity. -
Page 10: Print A Receipt
Print a receipt You can use the SATERASER4 with a serial printer to print an erase record with details of the process, including the date and time that the drive was erased, the erase mode used, and more. Note: The RS232 serial-based printer port uses 9600 baud. To print a receipt using the RS232 serial port, you need to use a printer that supports the ESC/P printer control language. -
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
