Thunderbolt™ 3 Dual-4K Docking Station for Laptops -
Windows/Mac - Power Delivery - 6x USB 3.0 + SD
TB3DOCK2DPPD
TB3DOCK2DPPU
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.startech.com
Manual Revision: 10/06/2017
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com TB3DOCK2DPPD
Summary of Contents for StarTech.com TB3DOCK2DPPD
- Page 1 Windows/Mac - Power Delivery - 6x USB 3.0 + SD TB3DOCK2DPPD TB3DOCK2DPPU *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ......................1 Package contents ............................1 Requirements ............................. 1 Product diagram ....................2 Front view ..............................2 Rear view ..............................2 About Thunderbolt 3 ..................3 About DP Alt Mode (DisplayPort Alternative Mode) ..............3 Thunderbolt temperature ........................3 About USB 3.0 and USB 3.1 Gen 1 .............. - Page 4 Technical support ....................10 Warranty information ..................10 Instruction Manual...
-
Page 5: Introduction
• 1 x Thunderbolt 3 cable • 1 x USB-C to DisplayPort cable • 1 x universal power adapter • 2 x power cords (NA/JP and ANZ for TB3DOCK2DPPD or UK and EU for TB3DOCK2DPPU) • 1 x instruction manual Requirements •... -
Page 6: Product Diagram
Product diagram Front view 3.5 mm SD ™ card headset reader port USB 3.0 port (5Gbps) (Battery Charge 1.2 compatible) Rear view USB Type-C™ Port (USB 3.0 - 5Gbps) Thunderbolt 3 DisplayPort USB-C port port* Gigabit USB Type-A ports DC input Thunderbolt RJ45 port port... -
Page 7: About Thunderbolt 3
About Thunderbolt 3 Thunderbolt 3 technology uses the USB-C connector, with a bandwidth of up to 40Gbps. It supports USB 3.1, DisplayPort 1.2, and PCI Express 3.0. Thunderbolt technology supports both video and data throughput. However, it prioritizes video bandwidth to help ensure seamless display performance. The performance of the remaining dock functions depends on your display configuration. -
Page 8: About Usb 3.0 And Usb 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard offers speeds up to 5Gbps. Any mention of USB 3.0 in this manual or on the StarTech.com website for TB3DOCK2DPPD or TB3DOCK2DPPU refers to the 5Gbps USB 3.1 Gen 1 standard. Any mention of USB 3.1 Gen 2 refers to the 10Gbps Gen 2 standard. -
Page 9: Install The Docking Station
Install the docking station The docking station is natively supported when connected to a computer running Windows 10, Windows 8 / 8.1 or macOS operating systems. In these operating systems, the docking station will automatically detect and install the required drivers once connected to a Thunderbolt 3 port on your host laptop. -
Page 10: Configure A Display Device
Charge a device If you’re only using the front USB 3.0 port to charge a device, a connection to a host laptop isn’t required. • To charge a device, connect it to the USB 3.0 port located on the front of the docking station. -
Page 11: Connect Multiple Thunderbolt 3 Displays In A Daisy Chain
(DP2DVIS) DisplayPort to VGA Adapter (DP2VGA2) Visit www.StarTech.com for a range of USB-C video adapters, active DisplayPort adapters and cables. Notes: • The docking station lets you connect two 4K displays. • Video adapters sometimes limit the maximum available resolution. Check the documentation of the video adapter to determine its maximum supported resolution. - Page 12 Supported video resolutions Thunderbolt technology supports both video and data throughput. However, it prioritizes video bandwidth to help ensure seamless display performance. The performance of the remaining dock functions depends entirely on the display configuration you used. The docking station supports the follow maximum resolutions: Number of Ports Maximum Resolution...
-
Page 13: Bandwidth Allocation
Bandwidth allocation Thunderbolt technology carries video and data bandwidth, and it prioritizes video bandwidth to help ensure seamless display performance. The performance of the remaining dock ports (for example, the USB 3.0 ports) depends entirely on the display and I/O (input and output) configuration that you have used. When multiple high-resolution displays are connected, the docking station needs to allocate additional bandwidth to the displays, and the extra bandwidth is reallocated from the other I/O ports on the docking station. -
Page 14: Troubleshooting
Troubleshooting If you are experiencing issues, there are some quick tests that you can complete to narrow down the source of the issue. Update your computer to use Thunderbolt 3 Visit http://thunderbolttechnology.net/updates and look for your computer in the list of affected computers. - Page 15 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
- Page 16 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
