11. Carefully slide the Upright Crossbar (76)
between the Uprights (84). Attach the Upright
Crossbar with four 5/16" x 3/4" Screws (1). Start
all four Screws, and then tighten them.
12. Raise the Frame (52) to the position shown.
Have a second person hold the Frame until
step 13 is completed.
Orient the Storage Latch (56) so that the decal is
facing away from the treadmill as shown.
Attach the lower end of the Storage Latch (56) to
the bracket on the Upright (84) with a 5/16" x 1
3/4" Bolt (3) and a 5/16" Nut (9).
Raise the Storage Latch (56) to a vertical posi-
tion. Then, remove and discard the tie (F).
11
1
84
12
F
Decal
14
76
1
84
52
56
9
84
3
