Summary of Contents for Spinfire Pro 2

  • Page 1 Pro 2 Manual...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY WARNINGS ............BEFORE FIRST USE ............ASSEMBLY ................. Packaging ..............BATTERY AND CHARGING ..........Internal Battery ............... External Battery .............. Standard Charger ............Optional Fast Charger ............ AC ADAPTOR ..............CUSTOMER CARE ............. 10-11 Caution ................Maintenance ..............
  • Page 3: Safety Warnings

    SAFETY WARNINGS This tennis ball machine is designed and tested to offer safe playing conditions, provided it is operated in strict accordance with the following safety warnings. Failure to comply with the following instructions may result in serious personal injury or property damage. •...
  • Page 4 • The machine should not be used in wet conditions. • The charger(s) & AC Adaptor are only to be used indoors. DON’T USE IN WET WEATHER! ---------------------------------------------------------------------------------------- • Always use and store the machine in a dry environment. • Do not spray with water.
  • Page 5 • Practice correct lifting techniques. The machine weighs up to 24 kg / 54 lbs (2 person lift) with an internal battery or 18 kg / 40 lbs (1 person lift) with an external battery. The gross weight of the packing box is 29 kg / 64 lbs HEAVY! (2 person lift).
  • Page 6: Before First Use

    BEFORE FIRST USE When you first open your box, you may notice some cosmetic scratches on your machine, particularly in the ball carousel pit at the top of the machine. This is perfectly normal and part of the manufacturing process. You may also notice some yellow ball fluff inside your machine or on the throwing wheels.
  • Page 7: Packaging

    charger, they may also be in the box. You can attach the hopper either upright for play mode, or upside down for portability/storage. To attach the hopper, simply align it correctly and then push down on it until it locks into place. Hopper upside down for portability/storage Packaging...
  • Page 8: External Battery

    The external battery cable includes a 32V 15A fuse built into it (note: 32V is correct for our 12V battery). If you are required to replace this, they can be purchased from local electronic stores or your Spinfire distributor. We also include one spare inside the battery bag’s pocket.
  • Page 9: Standard Charger

    Standard Charger Your machine comes with a standard charger (unless you purchased an AC machine) which charges the machine safely in 11 hours (assumes a 20Ah size battery). This charger is the safest charger to use for your machine and will provide the longest battery life. It is also a “smart” charger, meaning it will not damage your battery if left on for long periods of time.
  • Page 10: Ac Adaptor

    Note, if you do have an internal battery, the AC Adaptor can still be used. It will not damage the internal battery. Your AC Adaptor should only be used in a dry environment. The Spinfire AC Adaptor has been tested to work perfectly with our machine and we do not recommend substituting it with a compatible model.
  • Page 11: Customer Care

    CUSTOMER CARE Caution This machine was designed to be used on a tennis court, platform tennis court or padel court and in no other circumstances. Only tennis balls, platform tennis balls or padel balls must be used, no other balls should be ejected from the machine.
  • Page 12: Storage

    Storage We recommend that your machine is stored inside/under cover in a dry environment and preferably in a Spinfire cover to protect it from debris. Do not leave your machine on court even with the protection of a cover as heavy rain may damage your machine. Do not store your machine in direct sunlight or inside a car (unless in shade) and always keep it upright.
  • Page 13: Usage

    To transport in your car, please make sure the machine is always kept upright. Laying it on its side can cause internal damage and void your warranty. Do not store the machine in your car when external temperatures exceed 30 degrees Celsius (86 degrees Fahrenheit). The machine with a 20Ah SLA battery weighs 24 kg (53lbs) (or 18 kg (40lbs) with an external battery) and should be lifted carefully with the use of the handles.
  • Page 14 Press and hold the POWER button to turn on or off Power: the machine (hold it for approximately 3 seconds). Note, the master switch at the bottom of this control panel must be positioned to the correct power source before you can turn on your machine. It has 3 positions with O being off.
  • Page 15 confirm it’s activated). The maximum interval during the 2 Line Drill - wide setting is 17 and for the 2 Line Drill - medium it’s 19. Note that the balls will not start ejecting from the machine until you press the FEED (start/stop) button.
  • Page 16 Note, you can only adjust the horizontal angle when the menu is not flashing. This allows you to start and stop the feeding of balls Feed start/stop: from the machine. If you would like to have a 15, 30, 45 or 60 second delay before balls start feeding (to give you time to get to the other end of the court), simply hold the FEED button when turning it on.
  • Page 17 such as Horizontal Random or the 2 Line Drill . Note, to use this properly, you must set your machine to fire short balls first (eg, service line), and then activate Vertical Random . Balls will then randomly fire deeper into the court and also at their original short position.
  • Page 18 2 Line Drill - narrow mode which will alternate between hitting you a narrow forehand then a narrow backhand. If you press it again, you will enter the 2 Line Drill - medium mode which alternates between a medium forehand and a medium backhand (slightly more difficult).
  • Page 19: Remote Control

    By default, your remote control will control your machine and any other Spinfire ball machine in its proximity. If this is an issue, you can pair your remote to only control your machine and no other. For instructions on how to do this, please visit https://www.spinfiresport.com/kb/using-a-...
  • Page 20 Elevation Up* ---------------------------------------------------------------------------------------- Elevation Down* DOWN *The elevation can only be adjusted in increments of 2-5 units, depending on how fast you press the button (use the control panel if you want finer control). ---------------------------------------------------------------------------------------- Swivel Left LEFT ---------------------------------------------------------------------------------------- Swivel Right RIGHT ---------------------------------------------------------------------------------------- Cancels random settings...
  • Page 21: Single Ball Fire (Sbf)

    Balls can contain an oily coating in the felt which can cause damage to the throwing wheels. Please choose carefully when determining which balls to use in your machine. We recommend the use of Spinfire Touch balls or...
  • Page 22: Low Compression Balls

    - Note, this video shows the process on the v1 machine, but it’s the same steps for the v2. If this resolves your problem, then you can continue to use your machine this way until a permanent solution can be obtained from your Spinfire dealer. Please note that this solution relies on you...
  • Page 23: Padel Software

    performing step 2 above correctly. If you do not set the machine to the correct position before turning on the machine, you will find that the calibration may be off target. You will either need to turn the machine off to try again, or physically point your machine in a direction that will achieve the desired results.
  • Page 24: Troubleshooting

    TROUBLESHOOTING We have many support articles & videos showing you how to troubleshoot the various issues you may face with your machine. These can be found online at https://www.spinfiresport.com/knowledgebase If you cannot find the answer you need by searching our knowledgebase, please feel free to submit a support request at https://www.spinfiresport.
  • Page 25: Warranty

    Spinfire) or its distributor will repair or, (at distributor’s option), replace the defective part free of charge. The warranty period is country specific, please contact the Spinfire distributor in your country or the place of purchase for details. The battery is only warranted for 6 months from the date of purchase.
  • Page 26: Conditions Of Warranty

    Parts installed from other manufacturers’ products will void this warranty. EC DECLARATION OF CONFORMITY We confirm that as at the 7th November 2018, the Spinfire Pro 1 and Pro 2 machines both conform with the Low Voltage Directive 2014/35/ EU, Machinery Directive 2006/42/EC and the Radio Equipment Directive 2014/53/EU.
  • Page 27: Fcc & Ised Rss Warning

    Test standards Report number ---------------------------------------------------------------------------------------- Low Voltage Directive 2014/35/EU: LCS180907024CS EN 60335-1:2012 + A13:2017 EN 62233:2008 ---------------------------------------------------------------------------------------- Machinery Directive 2006/42/EC LCS180907007CS EN 60204-1:2006 + A1:2009 + AC:2010 EN ISO 12100:2010 ---------------------------------------------------------------------------------------- Radio Equipment Directive 2014/53/EU LCS180907091AS RETSI EN 301 489-1 v2.1.1 (2017-02) LCS180907090AEC ETSI EN 300 220-1 V3.1.1 (2017-02) LCS180907090AEB...
  • Page 28 RF exposure statement: This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating with any other antenna or transmitter.
  • Page 29: Manufacturer Details

    (2) This device must accept any interference received, including interference that may cause undesired operation. MANUFACTURER DETAILS The Spinfire Pro series of ball machines are manufactured in China for and on behalf of: Fry Developments Pty Ltd 200 Alexandra Pde, Fitzroy, VIC 3065...
