Whirlpool OMSK58HU1SX Quick Manual

Quick guide
THANK YOU FOR BUYING A WHIRLPOOL
PRODUCT
In order to receive a more complete
assistance, please register your product on
www . whirlpool . eu/register
CONTROL PANEL DESCRIPTION
1
1. SELECTION KNOB
For switching the oven on by selecting a
function. Turn to position to switch the
oven off.
2. LIGHT
With the oven switched on, press
the oven compartment lamp on or off.
SLIDING RUNNERS AND SHELF GUIDES
Before using the oven remove the protective tape [a] and then remove
the protective foil [b] from the sliding runners.
REMOVING THE SLIDING RUNNERS [c]
Pull the lower part of the sliding runner to uncouple the lower hooks
(1) and pull the the sliding runners upwards, removing them from the
upper hooks (2).
REFITTING THE SLIDING RUNNERS [d]
Hook the upper hooks on the shelf guides (1) then press the lower part
of the sliding runners against the shelf guides, until the lower hooks
are clicking (2).
FIRST TIME USE
1. SETTING THE TIME
You will need to set the time when you switch on the appliance for the
first time: Press until the
start flashing on the display.
Use or to set the hour and press
digits for the minutes will start flashing. Use
minutes and press to confirm.
2 3
3. SETTING THE TIME
For accessing the cooking time settings,
delayed start and timer.
For displaying the time when the oven
is off.
to turn
4. DISPLAY
5. ADJUSTMENT BUTTONS
For changing the cooking time settings.
icon and the two digits for the hour
to confirm. The two
or to set the
Before using the appliance carefully read the Safety
Instruction.
4 5
6. THERMOSTAT KNOB
Turn to select the temperature you require
when activating manual functions.
Please note: Type of knobs may vary from model
type. If the knobs are push-activated, push
down on the center of the knob to release it
from seating.
2
1
REMOVING AND REFITTING THE SHELF GUIDES
1.
To remove the shelf guides, firmly grip the external part of the
guide, and pull it towards you to extract the support and the two
internal pins from the lodging.
2. To reposition the shelf guides, position them near the cavity and
initially insert the two pins into their lodgings. Next, position
the external part near its lodging, insert the support, and firmly
press towards the wall of the cavity to make sure the shelf guide is
properly secured.
Please note: When the icon is flashing, for example following lengthy
power outages, you will need to reset the time.
2. HEAT THE OVEN
A new oven may release odours that have been left behind during
manufacturing: this is completely normal.
Before starting to cook food, we therefore recommend heating the
oven with it empty in order to remove any possible odours. Remove
any protective cardboard or transparent film from the oven and
remove any accessories from inside it. Heat the oven to 250 °C for
about one hour. The oven must be empty during this time.
Please note: It is recommended to ventilate the room after using the
appliance for the first time.
1
2
[c]
EN
6
[d]
