PIONEERPOS StealthTouch M7 Specifications

StealthTouch-M7 Touchcomputer
compact, quiet, and versatile
StealthTouch-M7 is a 17" All-in-one touchcomputer powered by Intel
Pentium-M technology. Its versatile design allows you to customize the M7
to meet your application requirements and budget. The M7's versatility
makes it an ideal choice for applications in healthcare, retail, manufacturing,
self-service kiosk, and hospitality.
When configured as fanless and diskless thin client, the M7 will reduce
grease and dust intakes. It also has the power to run demanding
applications in Windows XP or Vista.
M7's benefits:
+ Rugged and slim design.
+ Choice of Resistive touch, Intellitouch, or InfraRed.
+ Blazing network, 10/100/1000BaseT. Wireless (WiFi) optional.
+ 4 Serial, 6 USB ports.
+ Integrated magnetic stripe reader and biometric fingerprint reader.
+ 2nd display port for advertisement on LCD or Plasma display.
+ Integrated webcam.

Specifications

Display
Touchscreen Option
Processor
Memory
Video Memory
Storage
CD/DVD
Operating System
Network/Ethernet
WiFi (wireless)
Serial Port
USB 2.0
Parallel Port
CF Slot
Audio
Mounting Options
Security Lock
Bezel Color
Dimensions (with Base)
Weight
Operating Temperature
Operating Humidity
Power Supply
Agency Approvals
Add-ons
17" LCD, 1280x1024 (Privacy filter optional)
Resistive, Intellitouch SAW, InfraRed, Capacitive
Intel Celeron-M 1GHz, upto Pentium-M 2GHz
512MB, upto 2GB DDR2
upto 128MB (shared)
Hard Drive, Solid-state Disk, or Compact Flash
Internal (optional)
XP Prof, WePOS, XP embedded, CE.NET, Linux
10/100/1000 BaseT
RF 802.11 (optional)
4
6 (2 poweredUSB +12V, 1 poweredUSB +24V)
1
1 (optional)
2 Watts/channel, Stereo (optional)
Wall or Pole mount, VESA 75mm
Bolted (4mm screw), or Kensington MicroSaver
Dark grey
Width: 15.98" (406mm)
Height: 15.35" (390mm)
Depth: 11.42" (290mm), Wallmount: 3.5" (90mm)
25 lbs / 12 kgs (Wallmount: 12 lbs / 5.5 kgs)
o o
0 C to 40 C
20% to 80%
External, 120W, AC 100-240V
FCC A, CE, UL
Magnetic stripe or Barcode slot reader
Fingerprint /Biometric reader (DigitalPersona)
10" LCD as 2nd display
Barcode scanner (omni-directional)
Proximity RFID reader
Integrated webcam
VESA mount
Webcam
Barcode scanner
Dual view
