User Manual
StealthTouch-M5 Touchcomputer
compact, fanless, and versatile
StealthTouch-M5 is a 15" All-in-one touchcomputer powered by Intel
Pentium-M technology. Its versatile design allows you to customize the M5
to meet your application requirements and budget. The M5's versatility
makes it an ideal choice for applications in food service, retail,
manufacturing, healthcare, and self-service kiosk.
When configured as fanless and diskless thin client, the M5 will reduce
grease and dust intakes. It also has the power to run demanding
applications in Windows XP or Vista.
M5's benefits:
+ Rugged and slim design.
+ Choice of Resistive touch, Intellitouch, or InfraRed.
+ Blazing network, 10/100/1000BaseT. Wireless (WiFi) optional.
+ 4 Serial, 6 USB ports.
+ PoweredUSB to power up receipt printer, credit card terminal.
+ Integrated magnetic stripe reader and biometric fingerprint reader.
+ 2nd display port for advertisement on LCD or Plasma display.
Specifications
Display
Touchscreen Option
Processor
Memory
Video Memory
Storage
CD/DVD
Operating System
Network/Ethernet
WiFi (wireless)
Serial Port
USB 2.0
Parallel Port
Cashdrawer Port
CF Slot
Speakers
Mounting Options
Security Lock
Bezel Color
Dimensions (with Base)
Weight
Operating Temperature
Operating Humidity
Power Supply
Agency Approvals
Add-ons
15" LCD, Active matrix TFT, 1024x768
Resistive, Intellitouch SAW, InfraRed
Intel Celeron-M 1GHz, upto Pentium-M 2GHz
512MB, upto 2GB DDR2
upto 128MB (shared)
Hard Drive, Solid-state Disk, or Compact Flash
Internal (optional)
XP Prof, WePOS, XP embedded, CE.NET, Linux
10/100/1000 BaseT
RF 802.11 (optional)
4
6 : 4 Standard, 2 powered +12V, 1 powered +24V
1
2 (Epson emulation, 24V)
1 (optional)
2 Watts, Stereo (optional)
Wall or Pole mount, VESA 75mm
Bolted (4mm screw), or Kensington MicroSaver
Dark grey
Width: 14.63" (380mm)
Height: 14.37" (373mm)
Depth: 10.37" (269mm), Wallmount: 3.3" (85mm)
22 lbs / 10 kgs (Wallmount: 10 lbs / 4.6 kgs)
o
o
0
C to 40
C
20% to 80%
External, 120W, AC 100-240V
FCC A, CE, UL
Magnetic stripe or Barcode slot reader
Fingerprint /Biometric reader (DigitalPersona)
Rear customer display or 10" LCD
Barcode scanner (omni-directional)
Proximity RFID reader
Barcode scanner
VESA mount
Rear display
Dual view
