RS-232 Command Reference Manual
PDP-505CMX
For PIONEER
Plasma Display Panel
January 2006
Document Version 1.0
Product specifications and functions subject to change.
Please check with your authorized Pioneer dealer or distributor.

Advertisement

Table of Contents
loading

Related Manuals for Pioneer PDP-505CMX

Summary of Contents for Pioneer PDP-505CMX

  • Page 1 RS-232 Command Reference Manual PDP-505CMX For PIONEER Plasma Display Panel January 2006 Document Version 1.0 Product specifications and functions subject to change. Please check with your authorized Pioneer dealer or distributor.

  • Page 2: About The Rs-232C Adjustment Mode

    RS-232C Adjustment Mode 1.0 RS-232C Adjustment Mode This display panel has an RS-232C terminal. It is possible to use a PC to make adjustments and settings. 1.1 About the RS-232C Adjustment Mode 1) Adjustments in the RS-232C adjustment mode: • The adjustments are written to the same memory area as for the integrator mode. Refer to section 5.4.4, “PICTURE, White Balance and SCREEN Position Adjustment Values Memory Area Tables"...
  • Page 3 Also, when extending the RS-232C cable over a long distance, lower the baud rate. 4) Data format Start: 1 bit Data: 8 bit Parity: 0 (no parity) Stop: 1 bit 5) Connection Plasma Display (PDP-505CMX/50MXE10/50MXE11) Control PC (PDP-504CMX/50MXE1/50MXE1-S) (with D25 serial port ) (PDP-434CMX/43MXE1/43MXE1-S) RXD 3 TXD 2 CTS 5 GND 7 * D-sub 9-pin/D-sub 25-pin conversion tables are now available on the market.
  • Page 4 RS-232C Adjustment Mode 1.3 ID Assignment After connecting to a computer, the PC can assign an ID for each plasma display panel. Commands: <IDC> (ID CLEAR) ... Clears the assigned ID <IDS> (ID SET) ... Assigns an ID IDS is only effective when an ID is not assigned. Also, IDs are set starting from the set closest to the PC.

  • Page 5: Combination Connection

    1.4 Combination Connection When performing control and adjustment, it is easiest to connect several panels to one PC. By performing a combination connection and assigning IDs to the displays, it is possible to control and adjust several panels at the same time or separately. Connection method: Connect the panels as shown below.
  • Page 6 RS-232C Adjustment Mode Under the connection conditions shown below, up to 16 panels can be controlled and operated. 1 Length of RS-232C cable connecting PC to PDP-505CMX/PDP-50MXE10/PDP-50MXE11/PDP-504CMX/ Conditions: PDP-50MXE1/PDP-50MXE1-S/PDP-434CMX/PDP-43MXE1/PDP-43MXE1-S: 5 m 2 Combination cable length: 5 m each 3 Wire specifications for linking cable: Mini Din 6-pin straight (7 strand cable)

  • Page 7: List Of Rs-232C Commands

    1.5 List of RS-232C Commands How to read this Table • RS-232C adjustment validity : Indicates whether the RS-232C adjustment mode can be used • Normal validity : Indicates whether the normal-operation mode can be used • Numerical direct validity : With a 3-digit number attached to the end of a command, the command directly sets that adjustment value ‡...
  • Page 8 RS-232C Adjustment Mode Command name AJY (232C integrator) Display CTI: ### CTRS00 CTI: OFF CTRS01 CTI: ON OSD: ON DNR: ###### DNRS00 DNR: OFF DNRS01 DNR: LOW DNRS02 DNR: MIDDLE DNRS03 DNR: HIGH – EDIS01 DVI SELECT:PC EDIS02 DVI SELECT:VIDEO H.
  • Page 9 Command name AJY (232C integrator) Display GRADATION: ####### GRAS01 GRADATION: GAMMA 2.0 GRAS02 GRADATION: GAMMA 1.8 GRAS03 GRADATION: GAMMA 2.2 GRAS04 GRADATION: DRE MID GRAS05 GRADATION: DRE HIGH GRAS06 GRADATION: DRE LOW GRAS07 GRADATION: HIGH CNT. G SIDE MASK LEVEL: ∗∗∗ (GET STATUS OPTIONDATA) (GET STATUS SETUP DATA) (GET STATUS)
  • Page 10 RS-232C Adjustment Mode Command name AJY (232C integrator) Display MIRROR MODE: ### MIRS00 MIRROR MODE: OFF MIRS01 MIRROR MODE: X MIRS02 MIRROR MODE: Y MIRS03 MIRROR MODE: XY MPEG NR: ###### MNRS00 MPEG NR: OFF MNRS01 MPEG NR: LOW MNRS02 MPEG NR: MIDDLE MNRS03 MPEG NR: HIGH...
  • Page 11 Command name AJY (232C integrator) Display ######### SSIS01 INPUT1(SUB) SSIS02 INPUT2(SUB) SSIS03 INPUT3(SUB) SSIS04 INPUT4(SUB) SSIS05 INPUT5(SUB) STANDARD W/B SUB VOLUME: ∗∗∗ ######## SZMS00 Dot by Dot or PARTIAL SZMS01 4 : 3 SZMS02 FULL or FULL1080i SZMS03 ZOOM SZMS04 CINEMA SZMS05 WIDE...

  • Page 12: Get Commands

    RS-232C Adjustment Mode 1.6 GET Commands What are GET commands? • GET commands are for outputting TXD such as adjustment data from the internal microcomputer of the plasma display to a PC. • Adjustment data and other information is output as ASCII code. Note Command names are given inside brackets <...
  • Page 13 2) <GPI> (GET PICTURE DATA: Gets integrator/PICTURE data.) Order Data contents CONTRAST BRIGHTNESS C. DETAIL R (RED) C. DETAIL Y (YELLOW) C. DETAIL G (GREEN) C. DETAIL C (CYAN) C. DETAIL B (BLUE) C. DETAIL M (MAGENTA) H.ENHANCE V.ENHANCE COLOR TINT SHARPNESS Input function data (main)
  • Page 14 RS-232C Adjustment Mode 5) <GSS> (GET STATUS SETUP: Gets menu and integrator SETUP data.) Order Data contents GRADATION BRT.ENHANCE SUB VOLUME COLOR TEMP. MPEG NR PURECINEMA COLOR DECODING COLOR SYSTEM SIGNAL FORMAT Dummy data Input function data (main) Screen size data Check sum SIGNAL FORMAT •...
  • Page 15 6) <GSO> (GET STATUS OPTION: Gets menu and integrator OPTION data.) Order Data contents ENERGY SAVE ORBITER MASK CONTROL AUDIO OUT SCREEN MASK SIDE MASK MODE R SIDE MASK LEVEL G SIDE MASK LEVEL B SIDE MASK LEVEL 2 x 2 2 x 2 LAYOUT &...
  • Page 16 RS-232C Adjustment Mode 7 Check Sum The Check Sum is data to which 2-Byte ASCII code is added to a data group that is returned by a GET command. PC side GET command 02 (hex) 2 Byte 3 Byte Example) Check Sum value that is added when the GET command [GAA] returns the following 6-Byte data Data group (ASCII) + check sum The data group is put into binary code...

  • Page 17: Screen Burning

    2.0 Screen Burning When the same image is shown for a long time (still image, telop, etc.), the image is burned into to screen and may not be able to be removed. Manage this situation by making necessary changes in the video software, projection method, system configuration, etc.

  • Page 18: Precautions On Connecting Camera Images

    In this case, it is necessary to set the image quality beforehand. For instructions on setting the image quality, contact your PIONEER representative. Pioneer recommends that the ‘ENERGY SAVE’ mode be set to ‘MODE2’ or ‘MODE3’.

  • Page 19: Self-Diagnosis Function

    ¶ An invalid operation was attempted. Check the input signals, connections and settings. ¶ Turn the main power OFF, wait 1 or 2 minutes and turn the power ON again. If the problem still persists, remove the power plug from the outlet and contact a Pioneer service center or dealer. Remedy...

  • Page 20: Maintenance

    5) Readjustment of the White Balance This unit uses phosphor elements as in a CRT display. Phosphor degrades over time, reducing the brightness. Since, green and blue phosphor elements degrade faster than red, Pioneer recommends readjusting the white balance every 1000 hours.
  • Page 21 (this page intentionally left black)

  • Page 22: Plasma Display Panel

    RS-232 Command Reference Manual PDP-505CMX For PIONEER Plasma Display Panel Pioneer Electronics (USA) Inc. 2265 East 220 Street Long Beach, CA 90810 Corporate Website: www.pioneerelectronics.com Industrial Plasma Website: www.pioneerindustrialav.com...
