DC 13,8V/11A uninterruptible power supply
•
wide AC input voltage range 176÷264V
•
high efficiency 83%
•
controlling of battery charging and maintaining
•
protecting of battery against excessive
discharging (UVP)
•
battery charging current 1A/4A,
changed by jumper
1. Technical description.
1.1. General description.
Buffer-type power supply units are intended for continuous power supply to devices that require stabilised voltage
of 12 V DC (+/-15%). The power supply provides a voltage of U=13,8 V DC with an output current of:
In case of power voltage decay, prompt switching to battery supply occurs. The power supply has the following
protections: short-circuit (SCP), overload (OLP) and overvoltage (OVP).
1.2. Technical parameters.
Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple voltage
Battery charging current
Short-circuit protection SCP
Overload protection (battery) OLP
Overvoltage protection OVP
Excessive discharge protection UVP
Optical signalisation
Output of optical signalization
Operation conditions
Features of the power supply:
1.
Output current of 10A + 1A battery charging.
2.
Output current of 7A + 4A battery charging.
Total device current + battery: 11A max.
<30° C
=40° C
PSB15512110
PSB 13,8V/11A enclosed switch
mode buffer power supply
Edition: 1 z from 10.11.2011
Supercedes edition: ....................
•
battery output is full protected against short-
circuit and reverse connection
•
LED optical signalisation
•
protections:
•
•
•
•
176÷264V AC 50÷60Hz
1,4A@230VAC max.
155W max.
83%
13,8V DC – buffer operation
9,5V÷13,8V DC – battery operation
10A + 1A battery charging
7A + 4A battery charging
10A + 1A battery charging - refer to graph 1.
7A + 4A battery charging - refer to graph 1.
6,7 A + 1A battery charging - refer to graph 1.
3,7 A + 4A battery charging - refer to graph 1.
12÷14V DC
120mV p-p max.
1A max. or 4A max.
electronic
polymer fuse (PTC)
U>115% ÷ 150% of the output voltage, isolation of the
output voltage, atomatic recovery
U<9,5 V (± 5%) – disconnection of battery
green LED- presence of AC voltage
LED AC- presence of AC voltage
LED DC- presence of DC voltage on power supply output
2-nd enviromental class, temperature: -10
relative humidity 20%...90%, without condensation
1
SCP short-circuit protection
OVP overvoltage protection
overvoltage protection (output AC)
overload (OLP)
o
C÷40
EN
o
C
Advertisement
Table of Contents
Related Manuals for Pulsar PSB15512110
Summary of Contents for Pulsar PSB15512110
- Page 1 PSB15512110 PSB 13,8V/11A enclosed switch mode buffer power supply Edition: 1 z from 10.11.2011 Supercedes edition: ……………….. Features of the power supply: • • DC 13,8V/11A uninterruptible power supply battery output is full protected against short- • circuit and reverse connection wide AC input voltage range 176÷264V...
- Page 2 Dimensions (LxWxH) 199 x110 x 50 [mm] Net/gross weight 0,76kg / 0,82kg Protection class PN-EN 60950-1:2007 I (first) - requires a protective conductor (PE) power-supply: Φ0,63÷2,5 I/O PCB : Φ0,41÷1,63 battery output BAT: 6,3F-2,5/40cm, Connectors output of optical signalization: plug 3-pin 5 mm Electrical strength of insulation: - between input (network) circuit and output circuits of power-supply (I/P-O/P)
- Page 3 Battery terminal- negative (-) Fig 1. Description of terminals. Connector of optical signalization 2.4. Dimensions and fitting of the PSB15512110 power supply. Fig. 2. Dimensions of power supply 3. Maintenance. All maintenance procedures can be performed after the disconnection of the power supply from the electrical grid.
- Page 4 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the date of purchase placed on the purchase order. 2. Should such purchase order be missing when the claim is submitted, the three-year guarantee period is counted from the date of the manufacturing of the device.
