FIRMWARE UPDATE

!! Please check for any available firmware updates on www.reloop.com/reloop-flux !!
UPDATE INSTRUCTIONS FOR MACOS AND WINDOWS
Before proceeding, please make sure you have installed the latest Java Runtime Environment (JRE). You can download
and install Java from the following link: https://www.java.com/en/download/
Note: If you are using Microsoft EDGE, you may be unable to download the Java (JRE) application. If so, please
use a different browser for the download.
AFTER INSTALLING JAVA (JRE), PERFORM THE FOLLOWING STEPS:
1. Please make sure Serato DJ Pro or any other application is closed before performing the update.
2. Connect the FLUX to your computer via USB.
3. Launch the ReloopFirmwareUpdateApp application*, click "Open" and select the "FLUX_V***.bin" firmware file from
the download package. You will see the currently installed firmware version and the new version displayed inside the
updater.
4. Click "Start" and wait for the update (takes approximately 3~5 minutes).
5. Once finished, click "Close".
The device's firmware has now been updated successfully and the FLUX is ready to use.
Note: In case of an issue or if the update takes longer than 20 minutes, disconnect the device and repeat the
instructions above.
*: If you receive a warning message on macOS, proceed as follows:
1. Go into your system preferences by clicking on the Apple icon and select "System Preferences".
2. Select "Security & Privacy" and make sure the "General" tab is selected.
3. Click "Allow".
The updater application should now open. If not, double-click the ReloopFirmwareUpdateApp application.

TECHNICAL SPECIFICATIONS

POWER:
- USB bus powered: Yes
- Recommended power: 2 A or higher
- Minimum power: 400 mA
- Maximum USB-PD throughput: 60 W
- Maximum USB Hub power output: 2 x 0.8 A = 8 W
- Supported external USB (type A or C) power supply: 5 V/1 A - 20 V/3 A
- Power supply priority: FLUX self-power -> USB Hub -> PD (to PC)
AUDIO:
- S/N Ratio (output reference level 1 kHz, +4 dB):
- Deck In (LINE signal input: 0 dBV): More than 83 dB
- Deck In (PHONO signal input: -32 dBV): More than 73 dB
- THD + N:
- LINE signal input: -4 dBV @1K / Less than 0.03% (1 kHz,+0 dB)
- PHONO signal input: -36 dBV @1K / Less than 0.05% (1 kHz,+0 dB,Inverse RIAA)
- Maximum Gain:
- Deck In (LINE): +4 dB ± 2 dB
- Deck In (PHONO): +36 dB ± 2 dB
- Maximum Input (1 kHz, THD=1%):
- Deck In (LINE): More than +7 dBV
- Deck In (PHONO): More than -25 dBV
- Maximum Output (1 kHz, THD=1%):
- Deck Output: More than +11 dBV
USB:
- USB audio interface with 24 bit/44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
- USB 2.0 high-speed (480 Mbit/s)
- Class-compliant
- USB Power Delivery Protocol 3.0
GENERAL:
- Dimensions (WxDxH): 160 x 120 x 34 mm
- Weight: 0.85 kg
ACCESSORIES:
- User Manual
- 1x USB type C/C cable
- 1x USB type C/A cable
- 2x RCA cables

SERVICE AND SUPPORT

For technical questions or issues, please check our FAQ or request a support ticket: https://www.reloop.com/faqs/
